OWNER’S MANUAL Full HD Media Player Please read this manual carefully before operating your set and retain it for future reference. DVX689H P/NO : MFL67007101...
Getting Started Getting Started Safety Informaion CAUTION CAUTION: This product employs a Laser System. RISK OF ELECTRIC SHOCK To ensure proper use of this product, please read DO NOT OPEN this owner’s manual carefully and retain it for future CAUTION: TO REDUCE THE RISK OF ELECTRIC reference.
Page 4
DVDs, CDs and other materials may subject you to civil and/or criminal LG Electronics hereby declares that this/ liability. these product(s) is/are in compliance with the essential requirements and other rel-evant provisions of Directive 2004/108/EC, 2006/95/EC, and 2009/125/EC.
Table of Contents Table of Contents Operating On-Screen display – Displaying content information on- screen Getting Started General Playback – Playing Disc Safety Informaion – Playing USB Device Introduction General operation – Symbols Used in this Manual Advanced Playback – About the “7” Symbol Display –...
Getting Started Introduction Playable Discs DVD-VIDEO (8 cm / 12 cm disc) Discs such as movies that can be Symbols Used in this Manual purchased or rented. A section whose title has one of the following DVD±R (8 cm / 12 cm disc) symbols are applicable only to the disc represented - Video mode and finalized only by the symbol.
Getting Started Front panel a Disc Tray e D (Play) I (Stop) b R (Open / Close) Y/U (Skip) c Remote sensor 1 (Power) d Display window f USB Port Rear panel a Power Cord e Component Video Out (Y P B P R ) b Video Out (CVBS) f Digital Audio Out (COAXIAL) c 2CH Audio Out (Left/Right)
Getting Started Remote control b (ENTER): Confirm menu selection. x (RETURN): Press to move backwards or exit the menu. DVD MENU: Access or exit the DVD menu. [ (AUDIO): Select an audio language or audio channel. ] (SUBTITLE): Select a subtitle language. } (ANGLE): Select a DVD camera angle if it is available on the disc being played.
Connecting Connecting to your TV Connecting Video (CVBS) / Rear of the Unit Audio cable Component Connect the VIDEO/AUDIO OUT on the unit to Cable VIDEO/AUDIO IN on TV with AV cable, such as VIDEO with yellow, AUDIO Left/Right with white/ red.
Connecting Connecting COAXIAL (digital y Not all HDCP-compatible HDMI or DVI devices will work with this unit. audio) cable - The picture will not be displayed properly Connect the COAXIAL (digital audio out) on the with non-HDCP device. unit to Digital Audio IN (COAXIAL) on amplifier with - This unit does not playback and TV screen is COAXIAL cable.
System Setting System Setting Setup Sample Freq. (Frequency) Selects the sampling frequency of the audio signal between [48KHz] and [96KHz]. When the unit is turned-on at the first time, you have to select the desired language. (optional) DRC (Dynamic Range Control) Adjust the settings To adjust the volume level by itself when Audio level reaches to more than the specific level (Dolby...
System Setting [Slide] Menu [Other] Menu Select and set the Transition mode and Interval Time DivX(R) VOD of sliding on photo mode you prefer or appropriate. ® ABOUT DIVX VIDEO: DivX is a digital video format [Parental control] Menu ® created by DivX,Inc.
Operating Operating On-Screen display General Playback You can display and adjust various information on- Playing Disc screen about the loaded disc and USB Device. 1. Press B, and place a disc on the disc tray. Displaying content information 2. Press B to close the disc tray. on-screen ry 3.
Operating Advanced Playback General operation Movie ry Do this Do this Display disc Press DVD MENU (DVD Only) Playback Press z menu Pause Press M Play Press REPEAT during playback. Stop Press Z repeatedly Press REPEAT repeatedly. Skip to the Press C or V during y DVD: CHAPTER/ TITLE /OFF next or...
Operating Music tu Photo i Do this Do this View the Photo Press the DISPLAY to see the Play repeatedly Press REPEAT during playback. information contained file information, Press REPEAT repeatedly. [Type], [File], [Camera], y F (REPEAT ONE) /f [Resolution], and [Date].. (REPEAT ALL) / REPEAT Off Rotate a photo Press ws to rotate the photo Create or...
Troubleshooting Troubleshooting Troubleshooting Symptom Cause Solution No power. The power cord is disconnected. Plug the power cord. The unit does not An unplayable disc is inserted. Insert a playable disc. (Check the disc type and start playback. regional code.) The rating level is set. Change the rating level.
Appendix Appendix Area Code List Choose an area code from this list. Area Code Area Code Area Code Area Code Afghanistan Fiji Monaco Singapore Argentina Finland Mongolia Slovak Republic Slovenia Australia France Morocco Austria Germany Nepal South Africa Belgium Great Britain Netherlands South Korea Bhutan...
Appendix Language code List Use this list to input your desired language for the following initial settings: [Disc Audio], [Disc Subtitle] and [Disc Menu]. Language Code Language Code Language Code Language Code Afar 6565 French 7082 Lithuanian 7684 Sindhi 8368 Singhalese 8373 Afrikaans...
Appendix Specifications Trademarks and Licenses Power AC 200 - 240 V, 50/60 Hz requirements Power 14.5 W consumption Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol Dimensions Approx. are trademarks of Dolby Laboratories. (W x D x H) (430 x 233 x 51) mm Net Weight 1.9 kg...
