QuickSpecs

Overview

HP ProDesk 600 G1 Small Form Factor Desktop Business PC
1.
Power button and PC status LED
2.
3.5" external drive bay
3.
Slimline drive bay supporting an optical disk drive (located behind removable bezel)
4.
(2) USB 3.0 ports, (2) USB 2.0 ports
5.
3.5mm headphone output and microphone jack
Not Shown
Slots
(1) PCI Express x16 graphics connectors
(3) PCI Express x1 accessory connectors
Bays
(1) 2.5" internal storage drive bay
(1) 3.5" internal storage drive bay
Rear I/O
(2) USB 3.0 ports; (4) USB 2.0 ports
(1) VGA video port; (2) DisplayPort with multi-stream video ports
(1) RJ-45 network connector
(1) RS-232 serial port
3.5mm audio in/out jacks
PS/2 keyboard and mouse ports
DA - 14654 North America — Version 1 — June 17, 2013
HP ProDesk 600 G1 Business Series Desktop
Page 1

Advertisement

Table of Contents
loading

Related Manuals for HP ProDesk 600

Summary of Contents for HP ProDesk 600

  • Page 1 QuickSpecs HP ProDesk 600 G1 Business Series Desktop Overview HP ProDesk 600 G1 Small Form Factor Desktop Business PC Power button and PC status LED 3.5" external drive bay Slimline drive bay supporting an optical disk drive (located behind removable bezel) (2) USB 3.0 ports, (2) USB 2.0 ports...
  • Page 2 QuickSpecs HP ProDesk 600 G1 Business Series Desktop Overview HP ProDesk 600 G1 Tower Business PC Power button and PC status LED Slimline drive bay supporting an optical disk drive (located behind removable bezel) 5.25" half height external drive bay (located behind removable bezel) 3.5"...
  • Page 3 PC chassis and all internal components and modules are manufactured with low halogen content HP developed and engineered UEFI BIOS for better security, manageability and software image stability Intel® Q85 chipset supporting Intel 4th generation Core processors, featuring integrated Intel HD Graphics and Intel® Standard Manageability Technology Intel®...

  • Page 4: Operating System

    QuickSpecs HP ProDesk 600 G1 Business Series Desktop Standard Features and Configurable Components (availability may vary by country) OPERATING SYSTEM Preinstalled When Windows 8 Pro (64-bit)* Windows 8 (64-bit)* Purchased Windows 7 Ultimate (32-bit)** (LAR only) Windows 7 Ultimate (64-bit)**...
  • Page 5 QuickSpecs HP ProDesk 600 G1 Business Series Desktop Standard Features and Configurable Components (availability may vary by country) PROCESSOR SFF/TWR Intel® 4th Generation Core™ i7 Processors Intel® Core™ i7-4770 Processor Up to 3.9 GHz Max. Turbo Frequency (3.4 GHz base frequency)
  • Page 6 QuickSpecs HP ProDesk 600 G1 Business Series Desktop Standard Features and Configurable Components (availability may vary by country) HP Parallel Port Adapter STORAGE Hard Drive SFF/TWR 500 GB, 7200 rpm, SATA 6.0 Gb/s, SMART IV, 2.5" 500 GB, 7200 rpm, SATA 6.0 Gb/s, SMART IV, 3.5"...
  • Page 7 QuickSpecs HP ProDesk 600 G1 Business Series Desktop Standard Features and Configurable Components (availability may vary by country) PERFORMANCE Intel® Smart Response Technology Disk Cache Modules* SFF/TWR 32GB SATA Solid State Disk Cache * Not available at launch. NETWORKING/COMMUNICATIONS Ethernet (RJ-45)
  • Page 8 Business PC into the enterprise, such as PXE, remote configuration, remote control, and F10 Setup support for 12 languages. Stability - HP BIOS supports the HP stable product roadmap by releasing only critical BIOS changes to the factory and advanced change notification.
  • Page 9 QuickSpecs HP ProDesk 600 G1 Business Series Desktop Standard Features and Configurable Components (availability may vary by country) S5 Max Power Savings setting supports EU Lot6 requirement and allows the computer to power down below 1W is S5 (when turned off). When S5 Max Power Savings feature is enabled power to slots is turned off along with WOL functionality.
  • Page 10 QuickSpecs HP ProDesk 600 G1 Business Series Desktop Standard Features and Configurable Components (availability may vary by country) PORTS I/O Ports - Standard SFF/TWR USB 2.0 2 (front) 4 (rear) USB 3.0 2 (front) 2 (rear) Serial (RS-232 PS/2 1 keyboard (purple...
  • Page 11 24 x 7. Three-year onsite and labor are not available in all countries. Service offers terms up to 5 years by choosing a Care Pack. To choose the right level of service for your HP product, visit HP Care Pack Central: www.hp.com/go/cpc...

  • Page 12: Operating Systems

    Windows ® XP Professional (32-bit) For all Test & Document operating systems HP will perform functional testing of the operating system on the HP business PC platform. Any issues found will be documented in an Engineering Advisory and/or Service Advisory and posted to www.hp.com.
  • Page 13 Service is limited, check with Absolute for availability outside the U.S. Available via download Requires an Internet connection to HP web-enabled printer and HP ePrint account registration (for a list of eligible printers, supported documents and image types and other HP ePrint details, see www.hp.com/go/eprintcenter).Requires optional DA - 14654 North America —...
  • Page 14 QuickSpecs HP ProDesk 600 G1 Business Series Desktop Technical Specifications – Operating Systems, Software and eDocumentation broadband module. Broadband use requires separately purchased service contract. Check with service provider for coverage and availability in your area. Separately purchased data plans or usage fees may apply. Print times and connection speeds may vary DA - 14654 North America —...
  • Page 15 INTEL 4th GENERATION CORE vPRO PROCESSORS All HP ProDesk 600 G1 Business PC models include processors that are part of the Intel 2013 Stable Image Platform Program (SIPP) designed to ensure the stability promise inherent in the value proposition of the ProDesk 600, thus making these models the most stable, secure, and manageable platforms available to enterprises today.
  • Page 16 QuickSpecs HP ProDesk 600 G1 Business Series Desktop Technical Specifications - Graphics Intel HD Graphics VGA Controller Integrated DisplayPort Multimode capable; supports HDCP, Display Port Audio (2 streams), HBR2 link rates and Multi-Stream Technology for a maximum of 3 displays (including the integrated panel)
  • Page 17 QuickSpecs HP ProDesk 600 G1 Business Series Desktop Technical Specifications - Graphics Resolution Refresh Rates 800x600 60 Hz 1024x768 60 Hz 1152x864 60 Hz 1280x600 60 Hz 1280x720 60 Hz 1280x800 60 Hz 1280x960 60 Hz 1280x1024 60 Hz 1360x768...
  • Page 18 HP ProDesk 600 G1 Business Series Desktop Technical Specifications - Graphics Supported Display Resolutions and Refresh Rates Note: other resolutions may be available but are not recommended as they may not have been tested and qualified by HP Resolution Refresh Rates...
  • Page 19 Drives two analog display at resolutions up to 1920 × 1200 at 60 Hz using DisplayPort to VGA cable adaptors Supported Display Resolutions and Refresh Rates Note: other resolutions may be available but are not recommended as they may not have been tested and qualified by HP Resolution DisplayPort to VGA...
  • Page 20 Display Output Integrated 400 MHz RAMDAC Supported Display Resolutions and Refresh Rates NOTE: other resolutions may be available but are not recommended as they may not have been tested and qualified by HP Resolution Maximum Refresh Rates (Hz) Analog Connection...
  • Page 21 Up to 2 displays in the following configurations Supported Display Resolutions and Refresh Rates NOTE: other resolutions may be available but are not recommended as they may not have been tested and qualified by HP Resolution Maximum Refresh Rates (Hz) by Connection...
  • Page 22 Digital 1920 x 1200 Analog 2048 x 1536 Supported Display Resolutions and Refresh Rates NOTE: other resolutions may be available but are not recommended as they may not have been tested and qualified by HP Analog Connection Digital Connection 640 x 480...
  • Page 23 Digital 2560 x 1600 Analog 2048 x 1536 Supported Display Resolutions and Refresh Rates NOTE: other resolutions may be available but are not recommended as they may not have been tested and qualified by HP Analog Connection Digital Connection 300 x 200...
  • Page 24 PC. This offers you the additional benefits of dedicated bandwidth, the ability to more easily identify device failures and scalability. The HP ProDesk 600 G1 Series Business PC supports the latest SATA 6.0Gb/s specification.
  • Page 25 Advanced Host Controller Interface (AHCI) Revision 1.2. The specification includes a description of the hardware/software interface between system software and the host controller hardware. HP 500-GB 7200 RPM SATA 2.5" Self-Encrypting (SED) Hard Disk Drive Capacity 500,107,862,016 bytes Rotational Speed...
  • Page 26 3.951 +0.008 / -0.010 in (100.35 +0.20 / -0.25 mm) Weight 0.254 lb/115 g (max) Operating Temperature 32° to 140° F (0° to 60° C) HP 500 GB SATA 6G 2.5" 8GB Solid State Hybrid Drive (SSHD) (Coming Soon) Formatted Capacity 500 GB Spindle Speed 5,400 rpm +/- 0.2%...
  • Page 27 QuickSpecs HP ProDesk 600 G1 Business Series Desktop Technical Specifications - Hard Disk and Solid State Storage HP 120 GB Solid State Drive Unformatted Capacity 120 GB Architecture Multi Level Cell (MLC) NAND Flash with wear leveling 10 channel controller Interface Serial ATA 2.0 (3.0 Gb/s)
  • Page 28 QuickSpecs HP ProDesk 600 G1 Business Series Desktop Technical Specifications - Hard Disk and Solid State Storage Environmental Operating Temperature: 32° to 158° F (0° to 70° C) (all conditions, non-condensing) Relative Humidity (operating): 5% to 95% Shock: 1,500 G/1.0 msec...
  • Page 29 QuickSpecs HP ProDesk 600 G1 Business Series Desktop Technical Specifications - Hard Disk and Solid State Storage HP 256 GB SATA 2.5" Self-Encrypting (SED) Solid State Drive Unformatted Capacity 256,186,209,271 bytes Architecture Self-Encrypting (SED) Solid State Drive with 25nm MLC NAND Flash and SATA interface Interface Serial ATA 2.0 (3.0 Gb/s)
  • Page 30 QuickSpecs HP ProDesk 600 G1 Business Series Desktop Technical Specifications - Hard Disk and Solid State Storage HP 1-TB 7200 rpm SATA 6.0Gb/s 3.5" Hard Disk Drive Capacity 1,000,204,886,016 bytes Rotational Speed 7,200 rpm Interface Serial ATA 3.0 (6.0 Gb/s)
  • Page 31 QuickSpecs HP ProDesk 600 G1 Business Series Desktop Technical Specifications - Removable Storage HP Slim SuperMulti DVD Writer Drive Height 12.7mm height Orientation Either horizontal or vertical Interface type SATA/ATAPI Disc recording capacity Up to 8.5 GB DL or 4.7 GB standard Dimensions (W x H x D) 5.0 x 0.5 x 5.0 in (128 x 13.6 x 129 mm)
  • Page 32 QuickSpecs HP ProDesk 600 G1 Business Series Desktop Technical Specifications - Removable Storage DC Power Requirement 5 VDC ± 5%-100 mV ripple p-p 12 VDC ± 5%-200 mV ripple p-p Power DC Current 5 VDC (< 1000 mA typical, 1600 mA maximum) 12 VDC (<...
  • Page 33 QuickSpecs HP ProDesk 600 G1 Business Series Desktop Technical Specifications - Removable Storage BD-R Up to 4x Up to 4x BD-RE Up to 4x Not supported Single-layer Double-layer BD-ROM Up to 6x Up to 6x BD-R Up to 6x Up to 6x...
  • Page 34 QuickSpecs HP ProDesk 600 G1 Business Series Desktop Technical Specifications - Removable Storage HP Slim DVD-ROM Drive Height 12.7mm Orientation Either horizontal or vertical Interface type SATA/ATAPI Dimensions (W x H x D) 5.0 x 0.5 x 5.0 in (128 x 13.6 x 129 mm) Weight (max) 0.42 lb (190 g)
  • Page 35 System Memory Support The HP ProDesk 600 G1 Business PC supports 4rd generation Intel® Core™ processor families. Based on a new PC micro-architecture, the processor is designed for a two-chip platform consisting of a processor and Platform Controller Hub (PCH). Unlike previous generations, the processor includes an integrated memory controller (IMC).
  • Page 36 QuickSpecs HP ProDesk 600 G1 Business Series Desktop Technical Specifications - Communications Intel® I1217LM GbE Network Connection (integrated) Connector RJ-45 System Interface Integrated on PCA Controller Intel I217LM GbE platform LAN connect networking controller Memory 24 KB FIFO packet buffer memory...
  • Page 37 QuickSpecs HP ProDesk 600 G1 Business Series Desktop Technical Specifications - Communications Data Rates 802.11b: 1, 2, 5.5, 11 Mbps 802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11n: 66 possible data rates, ranging from 6 Mbps to 300 Mbps, depending on the combination of Bandwidth, Modulation Coding Scheme, and Guard Interval used, as defined in IEEE 802.11n...
  • Page 38 QuickSpecs HP ProDesk 600 G1 Business Series Desktop Technical Specifications - Communications Microsoft Windows XP Microsoft Windows Win 7 Configuration Utility Microsoft Windows XP Wireless Network Intel IHV extensions for Win7 Connection Manager available to support Cisco Intel PROSet for Microsoft Windows XP (required...
  • Page 39 QuickSpecs HP ProDesk 600 G1 Business Series Desktop Technical Specifications - Audio High Definition Audio Type Integrated HD Stereo Codec Realtek 2-channel ALC221 codec Audio I/O Ports Front microphone-In (150-K ohm Input Impedance) Rear Line-In/Microphone input (150-K ohm Input Impedance, function is configurable by audio...
  • Page 40 QuickSpecs HP ProDesk 600 G1 Business Series Desktop Technical Specifications – Keyboards and Pointing Devices HP USB Keyboard Keys 104, 105, 106, 107, 109 layout (depending upon country) Dimensions Physical characteristics 18.12 x 6.47 x 0.96 in (46.03 x 16.43 x 2.44 cm)
  • Page 41 QuickSpecs HP ProDesk 600 G1 Business Series Desktop Technical Specifications – Keyboards and Pointing Devices Keyboard Installation Guide Kit contents Warranty Card Safety and Comfort Guide HP PS/2 Keyboard Keys 104, 105, 106, 107, 109 layout (depending upon country) Dimensions 18.22 x 6.47 x 1.1 in (46.28 x 16.43 x 2.79 cm)
  • Page 42 HP USB Smart Card (CCID) Keyboard Protects against unauthorized access with smart card technology Delivers even greater security when combined with a HP ProtectTools smart card and the HP ProtectTools Security Software Combination of username and password or pin with a smart card or security token...
  • Page 43 QuickSpecs HP ProDesk 600 G1 Business Series Desktop Technical Specifications – Keyboards and Pointing Devices Non-operating temperature -22° to 140° F (-30° to 60° C) Operating humidity 10% to 90% (non-condensing at ambient) Non-operating humidity 20% to 80% (non-condensing at ambient)
  • Page 44 QuickSpecs HP ProDesk 600 G1 Business Series Desktop Technical Specifications – Keyboards and Pointing Devices Power consumption 50-mA maximum (with three LEDs ON) System interface USB Type A plug connector Electrical CE level 4, 15-kV air discharge EMI - RFI Conforms to FCC rules for a Class B computing device Microsoft®...
  • Page 45 QuickSpecs HP ProDesk 600 G1 Business Series Desktop Technical Specifications – Keyboards and Pointing Devices HP Wireless Keyboard and Mouse Dimensions (H x L x W) 1.09 x 18.1 x 6.47 in (27.87 x 460.3 x 164.3 mm) Keyboard Weight – Without Two AA 1.94 lb (880 g)
  • Page 46 QuickSpecs HP ProDesk 600 G1 Business Series Desktop Technical Specifications – Keyboards and Pointing Devices HP PS/2 Mouse Dimensions (H x L x W) 1.46 x 2.48 x 4.53 in (3.70 x 6.29 x 11.50 cm) Weight 3.53 oz (100g; +10g/- 5 g) Operating temperature -32°...
  • Page 47 QuickSpecs HP ProDesk 600 G1 Business Series Desktop Technical Specifications – Keyboards and Pointing Devices Maximum rotation force 50 gf-cm Scroll wheel Switch type Light force micro-switch Switch life 1 million operations Mechanical life Minimum 200,000 revolutions Regulatory Approvals UL/cUL, FCC, CE Mark, TUV/GS, VCCI, KCC, BSMI, C-Tick...
  • Page 48 QuickSpecs HP ProDesk 600 G1 Business Series Desktop Technical Specifications – Keyboards and Pointing Devices HP USB PS/2 Washable Mouse Dimensions (H x L x W) 1.56 x 2.44 x 4.61 in (3.95 x 6.21 x 11.7 cm) Weight 4.44 oz (126 g) Operating temperature –32°...

  • Page 49: Power Supply

    QuickSpecs HP ProDesk 600 G1 Business Series Desktop Technical Specifications – Power Unit Environment and Operating Conditions General Unit Operating Guidelines Keep the computer away from excessive moisture, direct moisture and the extremes of heat and cold, to ensure that unit is operated within the specified operating range.
  • Page 50 QuickSpecs HP ProDesk 600 G1 Business Series Desktop Technical Specifications – Power *High efficiency power supply is a requirement for ENERGY STAR® qualification in conjunction with a select range of processors and modules DA - 14654 North America — Version 1 — June 17, 2013...
  • Page 51 QuickSpecs HP ProDesk 600 G1 Business Series Desktop Technical Specifications – Weights & Dimensions Weights & Dimensions (configured with 1 HDD & 1 ODD) Chassis (W x H x D) 13.3 x 3.95 x 14.9 in 6.7 x 15.7 x 17.4 in...

  • Page 52: Serviceability Features

    HP PC Hardware Diagnostics UEFI: This utility enables hardware level testing outside the operating system on many components. The diagnostics can be invoked by pressing F2 at POST, and is available as a download from HP Support System/Emergency ROM Flash ROM...
  • Page 53 QuickSpecs HP ProDesk 600 G1 Business Series Desktop Technical Specifications – Miscellaneous Features Additional Features Description Towerable Orientation Product can be oriented as either a desktop or a tower Implementation of the industry standard ATA Security feature set. When enabled, it...
  • Page 54 HP DMS-59 to Dual DisplayPort Adapter XP688AA Data Storage Drives and Accessories SFF/TWR Part Number HP 500-GB 7.2K rpm SATA 6.0Gb/s 3.5” Hard Disk Drive QK554AA HP 1-TB 7.2K rpm SATA 6.0Gb/s 3.5” Hard Disk Drive QK555AA HP 128-GB SATA 3.0Gb/s Solid State Drive QV063AA HP 500-GB SATA 3.0Gb/s Solid State Hybrid Drive...
  • Page 55 HP USB Keyboard and Mouse Kit B1T09AA HP USB Washable Keyboard VF097AA HP USB and PS/2 Washable Mouse BM866AA HP USB and PS/2 Washable Keyboard and Mouse Kit BU207AA HP PS/2 Mouse QY775AA HP USB Mouse QY777AA HP USB 1000dpi Laser Mouse...
  • Page 56 QuickSpecs HP ProDesk 600 G1 Business Series Desktop Options and Accessories (sold separately) Stands and Accessories SFF/TWR Part Number HP Integrated Work Center Stand (SFF) SFF only QP897AA HP SFF Tower Stand SFF only VN569AA HP 600/800 Tower Bezel Kit...
  • Page 57 HP products are set forth in the express limited warranty statements accompanying such products. Nothing herein should be construed as constituting an additional warranty. HP shall not be liable for technical or editorial errors or omissions contained herein. Microsoft, Windows and Windows 7 are registered trademarks or trademarks of Microsoft Corporation in the U.S.
