E

SOLO TRIM

This parameter enables you to trim the level of the Solo signal in the range of –96 dB to
+12 dB.
F
FADER/SOLO RELEASE
If this check box is checked, you can unsolo the channels by raising the channel faders
that were at the level of –∞ when the Solo function was turned on. If the faders were set
to higher than –∞, the channels cannot be soloed. This setting is not effective in Mix-
down Solo mode and for Output Channels.
Note: When you check the FADER/SOLO RELEASE check box, the Solo setting is tem-
porarily cancelled.
G
SOLO SAFE CHANNEL
For Mixdown Solo mode, Input Channels can be configured individually so that they
are not muted when other Input Channels are soloed (Solo Safe function). Signals from
Input Channels with the SOLO SAFE CHANNEL button turned on are always fed to the
Stereo bus, regardless of the channels' Solo function status. You can clear all Solo Safe
settings by turning on the ALL CLEAR button.
Tip: For example, if you set the internal effects processor's return signal to Solo Safe, you
can monitor the soloed "processed (or wet)" signals.
H
MONITOR TRIM
This parameter enables you to trim the level of the monitoring signal in the range of
–96 dB to +12 dB.
I
MONO
This button switches the Monitor signal into mono.

Using the Monitor

1 Connect a monitoring system to the MONITOR OUT connectors.
To monitor the signal via headphones, connect headphones to the PHONES jack.
2 Press the Monitor Source selector in the MONITOR section to select the mon-
itoring signal source.
To monitor the 01V96's internal signals, turn off the selector (the button should be raised).
To monitor the signals at the 2TR IN connectors, turn on the selector (the button should be
pushed in).
3 Adjust the monitoring level using the MONITOR [MONITOR LEVEL] control
while playing the sound sources.
To adjust the level of the monitoring signal via headphones, turn the [PHONES LEVEL]
control.
Using the Monitor
PHONES
MONITOR
2TR IN
0 10 0 10
LEVEL LEVEL
MONITOR PHONES
OUT
