a. Ink Tank
Cartridges of ink in various colors.
b. Ink Tank Lock Lever
A lever that locks the Ink Tank in place and protects it. Lift and press down the lever when replacing an Ink Tank.
c. Ink Lamp (Red)
Indicates the state of the Ink Tank as follows when the Ink Tank Cover is opened.
• On
The Ink Tank is installed correctly.
• Off
No Ink Tank is installed, or the ink level detection function is off.
• Flashing Slowly
Not much ink is left.
• Flashing Rapidly
Ink tank is empty.
d. Ink Color Label
Load an Ink Tank that matches the color and name on this label.
iPF6300S
Printer Parts > Printer parts >
Ink Tank Cover (Inside)
