- Page 1 COLOUR TV RECEIVER OWNER'S MANUAL The Owner's Manual for the Follow Models: Please read this manual carefully 29MT1,29FA18 before operating the unit, and keep it for future reference.
-
Page 2: Table Of Contents
CONTENTS Before Operation War nin g and C aut ion s... 2 Ins tal lat ion ... 3 Ant enn a con nec tio n ... 3 Pre par ati on fo r the r emo te co ntr ol ... 3 Pos iti on of k eys a nd pl ug- ins ... -
Page 3: Warning And Cautions
Warning and Cautions 1. When you clean the TV set, please pull out the power plug from AC outlet. Don't clean the cabinet and the screen with benzene, petrol and other chemicals. 2. In order to prolong the using life of the TV set, please place it on a ventilated place. -
Page 4: Installation
Installation Antenna connection Generally speaking, to enjoy a clearer picture, we recommend that you use a CATV system or an outdoor antenna .In different places, the suitable antenna type and position are different. twin-lead cable Antenna adapter 75 coaxial cable Plug (additional purchase) Note... -
Page 5: Position Of Keys And Plug-Ins
Position of Keys and Plug-ins Front and side panel 29FA18-T 29MT1: NOTE: The side AV terminals are only available for some model. AUDIO VIDEO Audio Input terminal Video Input terminal Audio Input terminal Video Input terminal... -
Page 6: Bac K Pan El
Position of Keys and Plug-ins Video Y input terminal Antenna input socket Video Cb input terminal Video Cr input terminal Audio right channel input terminal Video input terminal Audio left channel input terminal S-VIDEO input terminal Audio right channel output terminal Video output terminal Audio left channel output terminal... -
Page 7: Using The Remote Control
Using the Remote Control DISP TV/AV P.STD MENU VOL- SYSTEM SCAN CALENDAR FAVORITE GAME NOTE: Just see your real set and the instructions on the manual for references. Buttons and Descriptions Mute Button Press to conceal the sound of programs. Sleep Timer Button TV and AV Exchange Button To exchange between TV and... -
Page 8: Power On And Power Off
Power On and Power Off 11-14... -
Page 9: Viewing Tv Programs
Viewing TV Programs The channels amount to 218 . Viewing TV programs How to select the TV program 1. Use the direct-digit choosing button Press the button from 0-9 to select a one digit channel. If you want to select a two-digit channel, press the Digit Select button and change it into two-digit mode, then press the number of the channel. -
Page 10: Program Scan And Screen Display
Viewing TV Programs Program scanning function is to let the television automatically scan all preconcerted channel program(about two seconds per channel). ½ Ú Ä ¿ ä ¯ À À ¼ ° Æ Á Ä » Ï Program scan and screen display SCAN DISP (continued) -
Page 11: Saving Mode.favorite Program
Viewing TV Programs ½ Ú Ä ¿ ä ¯ À À ¼ ° Æ Á Ä » Ï Saving mode.favorite program MENU VOL+ VOL- QSET FAVORITE (continued) Saving mode 1. Using the QSET button Press the QSET button to switch the saving mo de on/off. -
Page 12: Tuning
Tuning There are three ways of searching: automatic search, manual search and MFT (manual fine tune). You may operate it either on the TV or on the remote control. Here is mainly about the remote control. Automatic search MENU VOL+ VOL- MENU VOL+... -
Page 13: Manual Search
Tuning (continued) Manual search MENU VOL+ VOL- Direct-digit Choosing Button 4. Press VOL+/- button to start searching. MENU VOL+ VOL- VOL- button is used to search the lower frquency channel. VOL+ button is used to search the higher frequency channel. Repeat the steps until you find the channel you need. -
Page 14: Mft
Tuning (continued) MENU VOL+ VOL- Direct-digit Choosing Button MENU VOL+ VOL- MFT(manual fine tune) When you can't get a satisfactory picture and audio effect, you can fine tune to obtain. 1. Press MENU button continuously, until select TUN menu. 2. Press CH+/- button to select POS EDIT and VOL+ to enter. -
Page 15: Skip
Tuning (continued) Skip Direct-digit Choosing Button MENU VOL+ VOL- Skip After the programs are presetted, you can skip some programs to select your favorite channels only. 1. Press MENU button continuously, until select TUN menu. 2. Press CH+/- button to select POS EDIT and VOL+ to enter. -
Page 16: Adjusting The Picture And The Sound
Adjusting the Picture and the Sound Multiple picture modes P.STD MENU VOL+ VOL- How to select the picture mode You may select the mode you want from the five preset modes and one individual mode. Press the P. STD button to select a mode you like.DYNAMIC PICTURE, STANDARD PICTURE, MILD PICTURE, MEMORY, PICTURE MUTE and COLOR MUTE,... -
Page 17: Multiple Sound Modes And Setting The Sound
Adjusting the Picture and the Sound (continued) Multiple Sound Modes and Setting the Sound S.STD MENU VOL+ VOL- S.STD How to select the sound mode You can quickly select your most favored sound mode from the following three kinds of modes. Press the S.STD button to select the sound quality that you want.LOW VOL/ NORMAL VOL/ HIGH VOL can be... -
Page 18: C, Aut O Off A Nd Mu Te
Adjusting the Picture and the Sound (continued) S.C.C, auto off and mute MENU VOL+ VOL- How to use the S.C.C(soft change channel) This TV set provides you with the function of S.C. C. When it is set "ON", the picture will fade in and fade out when the channel is changed. -
Page 19: Setting The Timer
Setting the Timer This TV set provides you with three timer functions such as timer on, timer off and sleep off. Timer off MENU VOL+ VOL- MENU VOL+ VOL- Timer off Using this function can turn the TV set automatically into standby status at the preconcerted time. -
Page 20: Sleep Timer And On Timer
Setting the Timer Sleep timer and on timer MENU VOL+ VOL- MENU VOL+ VOL- (continued) Sleep timer Using this function, the TV set can be changed into the standby status after a period of preset time from when this function is activated. 1. -
Page 21: Channels Appointment
Setting the Timer (continued) MENU VOL+ VOL- MENU VOL+ VOL-... -
Page 22: Setting The Other Function
Setting the other Function Æ Á Ä » Ó ï Ñ Ô ¼ ° Æ Á Ä » ± Æ Á Ä » Ó ï Ñ Ô ¼ ° Æ Á Ä » ± 3A filter and screen protection MENU VOL+ VOL- MENU... -
Page 23: Curtain Function,Calendar Display
Setting the other Function Curtain function,calendar display MENU VOL+ VOL- CALENDAR MENU VOL+ VOL- How to use the Curtain function This TV set provides three types of Curtain function for you to select. 1. Press MENU button until select FUN menu. 2. -
Page 24: Channel Exchange
Setting the other Function The function of channel exchange will enable you to exchange any two programs and you can conveniently adjust the order of the programs due to your own need. Channel exchange MENU VOL+ VOL- Direct-digit Choosing Button MENU VOL+ VOL-... -
Page 25: Setting The Lock
Setting the Lock This TV set provides you with the LOCK function, you can choose it due to your need to protect your TV set. Changing your password LOCK MENU VOL+ VOL- Direct-digit Choosing Button Changing your password This TV set can set a four digit password, the original one is 0000, if you want to reset it, please follow the instructions below. -
Page 26: Setting The Lock
Setting the Lock Setting the Lock LOCK Direct-digit Choosing Button MENU VOL+ VOL- (continued) Setting the Lock There are TUNING LOCK, PRESET PROG. ,AV LOCK, CHILD LOCK and MAX.VOLUME five lock setting, you can set it due to your need. 1. -
Page 27: Game Control Buttons And Method Of Playing The Game
Game This TV set provides you with the game, after entering the game, except the buttons that are appointed in the game( for example, the game button, CH+/-and MODE, etc.)and the DC Stand by button, the other buttons cannot be used. -
Page 28: Connecting Additional Equipments
Connecting Additional Equipments Connecting additional equipments You can connect the DVD,VCR and stereo system to the AV output to enjoy a higher quality of picture and sound effect. Signal flow White (Audio left channel) Red (C and audio right channel) Blue (C Green (Y) Yellow (Video) -
Page 29: Troubleshooting
Troubleshooting *To assist in location possible faults use help guide below. BREAKDOWN PHENOMENON SOUND PICTURE Picture with snow Double or Triple Image Disturb Normal No Picture No color Scramble Normal or Weak Volume Color Spot Normal volume Note: 1.If the fault can not be repaired using the above guide consult with your local authorized service center. 2.The TV set must only be repaired by a qualified registered service person. -
Page 30: Specifications
825 (W) x 470 (D) x 596 (H) (mm) Dimension ( 784 (W) x 389 (D) x 593 (H) (mm Working temperature: Working humidity: Environment conditions Storage temperature: Storage humidity: Remote control Owner's manual Accessories Battery(AAA) 29FA18 29MT1 20%-80% 5%-90%... - Page 31 0090505219A...
