INSTALLATION
iNSTRUCTIONS
FOR YOUR NEW
FREEoSTANDING ELECTRIC NGE
Before
you begin.
Read
these
instructions
completely
end carefully.
nMPORTANT.
Save
these
instructions
for local
inspector's
use.
IMPORTANT
- OBSERVE
ALL GOVERNB_G
CODES
AND
ORDINANCES.
Note
to HnstaHer
. Be sure to leave
these
instructions
with
the Consumer.
Note
=o Consumer.
Keep
t_ese
instructions
with
your
Use and Care
Book
for future
reference.
CAUTION: For personal safety remove
house fuse or open circuit breaker
|
before beginning instaMation. Failure
|
to do so could result in serious injury
|
°re'e, de h. .................
J
All rough-in and spacing dimensions must be met for safe
use of your range Electricity to the range can be
disconnected at the outlet without moving the range if the
outlet is in the preferred location (remove lower drawer)
To reduce the risk of bums or fire when reaching over hot
surface elements, cabinet storage space above the
cooktop should be avoided If cabinet storage space is to
be provided above the cooktop, the risk can be reduced
by installing a range hood that sticks out at least 5" beyond
the front of the cabinets Cabinets installed above a
cooktop may" be no deeper than 73"
Be sure your appliance is properly installed and grounded
by a qualified technician
WARNING: To reduce the ri_k of
tipping the appliance,
the appliance
must be secured by properly iestafied
anti.tip
device packed _Jith the
appliance,
• Flat blade screwdriver
• I 7/15"open end OF
• 5/t6" hex head screwdriver
adjustable wrench
• Drill with 7/8" bit
• !/4" Hex Head
• Phillips head screwdriver
screwdriver
• Unlessproperly installed,the range
':
could be tipped by steppingor sitting on
::
hot liquids or from the rangeitself
• Thisrange has been designed to meet
all normalconditions
, fnstatfAnti-tip Devicepacked withrange .. [
.SeeInstallationInstructions
Fig. 1
ADJACENTCABINET ORFINAL
LOCATIONOF_NGE
WAll
REAR
LEVELING L EG
Installationinstructionsare provided for wood and concrete
in eitherfloor or wall Any othertype of construction may
require special installationtechniques as deemed neces-
sary toprovide adequate fasteningof the ANTI.TIP
bracket to the floor and wall
Theuse of this bracket does not preclude tipping of the
range whennot properly installed
NOTE: Theinstallationof the ANTI.TIP bracket must
meet all local codes for securing appliance
Step 1 - Locating
#_e bracket
1. Locate the bracket against the rear wall and either the
right or left cabinet. If the countertop overhangs the
cabinet, offset the bracket from the cabinet by the
amount of overhang, tf there is no adjacent cabinet.
position the edge of the bracket at the desired location
of the range side panel
continued...
31-10301-1
229C4o53P'!
04,,2
I
N D 348_02
