Summary of Contents for Electrolux EUN1270
- Page 1 G e f r i e r s c h r a n k / p a k a s t i n k a a p p i / f r y s s k å p / c o n g e l a d o r м...
-
Page 2: Table Of Contents
CONTENTS Instructions for the User Instructions for the Installer Important Safety Instructions Technical specifications Description of the appliance Installation Positioning Electrical connection Door reversal Cleaning the interior Instructions for totally built-in appliances Control panel Starting up Temperature regulation Quick freezing Warning light Acoustic alarm Freezing calendar... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS It is most important that this instruction book should be retained with the appliance for future reference. Should the appliance be sold or transferred to another owner, or should you move house and leave the appliance, always ensure that the book is supplied with the appliance in order that the new owner can be acquainted with the functioning of the appliance and the relevant warnings. -
Page 4: Description Of The Appliance
ventilation must be as shown in the relevant If the appliance has been transported horizontally, paragraph. it is possible that the oil contained in the Attention: keep ventilation openings clear of compressor flows in the refrigerant circuit. It is obstruction. advisable to wait at least two hours before connecting the appliance to allow the oil to flow If the appliance is transported horizontally, it is... -
Page 5: Use
The freezer is marked with the symbol, which means that the compartment is suitable for freezing fresie food and long-term storage of frozen food. Cleaning the interior Before using the appliance for the first time, wash the interior and all internal accessories with lukewarm water and some neutral soap so as to remove the typical smell of a brand-new product, then dry thoroughly. -
Page 6: Quick Freezing
Quick freezing a small amount of food, use the top compartment. In the top compartment, products must only be stacked up to the mark on the cabinet wall so as to Activate fast freeze by depressing the fast freeze ensure that air circulation is not obstructed. switch . -
Page 7: Tips
TIPS Tips for freezing fresh foods Tips for storage of commercially frozen food To help you get the best out of the freezing process, here are a few hints: To get the best out of your freezer, in the case of Freeze only good-quality, fresh and well-cleaned storage of commercially frozen food you should foods. -
Page 8: Periodic Cleaning
To carry out complete defrosting proceed as follows: 1. Remove any stored food, wrap it in several layers of newspaper and put it in a cool place. 2. Turn the thermostat control knob to the « » setting. 3. Leave the door open. 4. -
Page 9: Something Not Working
SOMETHING NOT WORKING If the appliance is not functioning properly, check that: Malfunction Remedy Appliance does not function, no pilot light is illuminated. - Appliance is not switched on; switch appliance on. - Mains plug is not inserted or is loose; insert mains plug. - Fuse has blown or is defective;... -
Page 10: Installation
INSTALLATION lf this appliance featuring magnetic door seals is Door reversal to replace an older appliance having a spring lock (latch) on the door or lid, be sure to make that The appliance’s door has been locked in position for spring lock unusable before you discard the old transport by means of pins on both sides. -
Page 11: Instructions For Totally Built-In Appliances
Instructions for totally built-in appliances Dimensions of the recess Height of housing mm 880 Depth of housing mm 550 Width of housing mm 560 D132 Apply joint the sealing strip as shown in figure. PR 32 1. It is necessary that the niche is provided with a conduct of ventilation having the following dimensions: Depth 50 mm... - Page 12 PR266 PR167 6. Separate parts A, B, C, D as shown in the figure. 9. Open the appliance door and the furniture door at 90°. Insert the small square (B) into guide (A). Put together the appliance door and the furniture door and mark the holes as indicated in the figure.
- Page 13 Electrolux HemProdukter AB S-105 45 Stockholm www.electrolux.se ELECTROLUX HOME PRODUCTS OPERATIONS EUROPE...
