Fridge--Freezer / Réfrigérateur--Congélateur / Kühl--Gefrierkombination /
Frigorifero--Congelatore / Køle--Frysskab / Kjøle--Fryseskåp
GEBRAUCHSANWEISUNG
NOTICE D'UTILISATION
Information on how to minimize environmental impacts is given in this manual.
818 18 57--03/1
INSTRUCTION BOOK
ISTRUZIONI D'USO
BRUGSANVISNING
BRUKSANVISNING
ERB3105
GB
DE
NL
IT
FR
DK
NO
Advertisement
Table of Contents
Related Manuals for Electrolux ERB3105
Summary of Contents for Electrolux ERB3105
- Page 1 Fridge--Freezer / Réfrigérateur--Congélateur / Kühl--Gefrierkombination / Frigorifero--Congelatore / Køle--Frysskab / Kjøle--Fryseskåp INSTRUCTION BOOK GEBRAUCHSANWEISUNG ISTRUZIONI D’USO NOTICE D’UTILISATION BRUGSANVISNING BRUKSANVISNING ERB3105 Information on how to minimize environmental impacts is given in this manual. 818 18 57--03/1...
-
Page 2: Table Of Contents
Safety instructions Your new fridge/freezer may have other functions compared to your previous one. For the User · The cabinet is heavy. The edges and projecting parts of the cabinet may be sharp. Be careful · The cabinet is intended for keeping foodstuff in a when moving the cabinet and always use gloves. -
Page 3: Description Of The Appliance
Description of the Appliance Modell ERB3105 1. Glass shelf 2. Bottle shelf 3. Vegetable drawer 4. Butter compartment 5. Door shelf 6. Eggholder 7. Bottle shelf 8. Freezer plate + accumulator 9. Freezer drawer 10. Ventilation grille Control Panel A. Thermometer F. -
Page 4: Before Use
Before use Position and clean the cabinet as explained in the section "Installation". Check that the drain hose at the rear of the cabinet discharges into the drip tray. Before inserting the power plug into the outlet and switching on the cabinet for the first time, leave it standing upright for about 4 hours. -
Page 5: Switching Off
Hints: · Distribute foodstuffs to allow cold air to circulate freely between the products. · Do not place food products directly against the cooling plate on the rear wall since they may freeze in this case. · Also never put warm products into the cabinet. Wait until they have cooled down. -
Page 6: Switching Off
Switching off Turn the control anti-clockwise past the click position to "H". Unplug the power supply plug from the wall socket. Alarms and other features Temperature alarm The warning lamp lights and an alarm sounds if it gets warmer than -10°C. Switching off the audible alarm: Press the switch-off button. -
Page 7: Suitable Storage Periods
Thawing Suitable storage periods It is best to use the fridge to thaw food. Place the Food purchased in frozen condition: Follow the foodstuff on a plate with a raised edge to prevent advice on the maximum storage period indicated on liquids from running out. -
Page 8: Hints And Tips
Hints and Tips Saving energy · Make sure the door gasket is complete and always clean. · Pay careful attention to where the cabinet is placed. See the section "Installation". When Food Storage installed correctly, the cabinet will consume less ·... -
Page 9: Cleaning
Cleaning Clean the cabinet at regular intervals. Don't use detergents, abrasive powders, high perfumed cleaning products, wax polishes or cleaning products containing bleach or alcohol when cleaning the product Disconnect the appliance from electricity supply. Internal Cleaning Clean the inside and accossories with warm water and bicarbonate of soda (5ml to 0,5 litre water) Rinse and dry thoroughly. -
Page 10: To Change The Light Bulb
To Change the Light Bulb The light is switched on automatically when the UV-blocked door is opened. Before replacing the light bulb, disconnect the power plug from the outlet. Cut the packaging around the bulb socket. Keep the packaging on to hold the bulb when setting it into the socket. -
Page 11: Guarantee Conditions
It is too warm inside the freezer. Set a lower temperature. Make sure that the door is completely closed and that the insulating strip is complete and clean. If warm food products have been put inside the freezer, wait for a couple of hours and then check the temperature again. -
Page 12: Customer Care Department
Service and Spare Parts SER:NO (serial number):........In the event of your appliance requiring service, or if oyu wish to purchase spare parts please contact Purchase date............Technical specification ERB3105 Model 189 l Net volume refrigerator 95 l Net volume freezer... -
Page 13: Remove The Transport Supports
Remove the transport supports Remove the tape and the transport supports from · the door sides · inside the door hinges · the shelves Remove the transport support on the glass shelf by pushing the support forward along the edge of the shelf until it stops. -
Page 14: Door Reversal
Door Reversal 1. Close the cabinet and remove the plug from the electrical socket. 2. Remove the ventilation grille. There is a part on the grille that can be removed. Reposition it and put it on the other side. 3. Put the cabinet on a wooden board when it is laid down. - Page 15 qÜÉ=bäÉÅíêçäìñ=dêçìé=áë=íÜÉ=ïçêäÇDë=ä~êÖÉëí=éêçÇìÅÉê=çÑ=éçïÉêÉÇ=~ééäá~åÅÉë=Ñçê=âáíÅÜÉåI=ÅäÉ~åáåÖ=~åÇ=çìíÇççê=ìëÉK jçêÉ=íÜ~å=RR=ãáääáçå=bäÉÅíêçäìñ=dêçìé=éêçÇìÅíë=EëìÅÜ=~ë=êÉÑêáÖÉê~íçêëI=ÅççâÉêëI=ï~ëÜáåÖ=ã~ÅÜáåÉëI=î~Åììã=ÅäÉ~åÉêëI ÅÜ~áå=ë~ïë=~åÇ=ä~ïå=ãçïÉêëF=~êÉ=ëçäÇ=É~ÅÜ=óÉ~ê=íç=~=î~äìÉ=çÑ=~ééêçñK=rpa=NQ=Äáääáçå=áå=ãçêÉ=íÜ~å=NRM=ÅçìåíêáÉë ~êçìåÇ=íÜÉ=ïçêäÇK aáÉ=bäÉÅíêçäìñJdêìééÉ=áëí=ÇÉê=ïÉäíïÉáí=Öê∏≈íÉ=eÉêëíÉääÉê=îçå=Ö~ëJ=ìåÇ=ëíêçãÄÉíêáÉÄÉåÉå=dÉê®íÉå=ÑΩê=ÇáÉ=hΩÅÜÉI=òìã oÉáåáÖÉå=ìåÇ=ÑΩê=cçêëí=ìåÇ=d~êíÉåK=gÉÇÉë=g~Üê=îÉêâ~ìÑí=ÇáÉ=bäÉÅíêçäìñJdêìééÉ=áå=ΩÄÉê=NRM=i®åÇÉêå=ÇÉê=bêÇÉ=ΩÄÉê=RR jáääáçåÉå=mêçÇìâíÉ=EhΩÜäëÅÜê®åâÉI=eÉêÇÉI=t~ëÅÜã~ëÅÜáåÉåI=pí~ìÄë~ìÖÉêI=jçíçêë®ÖÉå=ìåÇ=o~ëÉåã®ÜÉêF=ãáí=ÉáåÉã tÉêí=îçå=êìåÇ=NQ=jêÇK=rpaK fä=dêìééç=bäÉÅíêçäìñ==ÉD=áä=éáìD=Öê~åÇÉ=éêçÇìííçêÉ=ãçåÇá~äÉ=Çá=~éé~êÉÅÅÜá~íìêÉ=éÉê=ä~=ÅìÅáå~I=éÉê=ä~=éìäáòá~=É=Çá ~ííêÉòò~íìêÉ==éÉê=áä=Öá~êÇáå~ÖÖáç=É=éÉê=ìëç=ÑçêÉëí~äÉK=läíêÉ=RR=ãáäáçåá=Çá=éêçÇçííá=ÇÉä=dêìééç=bäÉÅíêçäìñ==E=èì~äá=ÑêáÖçêáÑÉêáI ÅìÅáåÉI=ä~î~Äá~åÅÜÉêá~I=ä~î~ëíçîáÖäáÉI=~ëéáê~éçäîÉêÉI=ãçíçëÉÖÜÉ=É=ê~ë~ÉêÄ~=F=îÉåÖçåç=îÉåÇìíÉ=çÖåá=~ååç=áå=éáìD=Çá=NRM m~Éëá=ÇÉä=ãçåÇç=éÉê=ìå=î~äçêÉ=Çá=ÅáêÅ~=NQ=ãáäá~êÇá=Çá=Ççää~êáK iÉ=dêçìéÉ=bäÉÅíêçäìñ=Éëí=äÉ=éêÉãáÉê=Ñ~ÄêáÅ~åí=ãçåÇá~ä=ÇD~éé~êÉáäë=ÇçãÉëíáèìÉëI=ÇDÉåíêÉíáÉå=Éí=éçìê=äDÉñí¨êáÉìêK mäìë=ÇÉ=RR=ãáääáçåë=ÇÉ=éêçÇìáíë=Çì=dêçìéÉ=bäÉÅíêçäìñ=EíÉäë=èìÉ=ê¨ÑêáÖ¨ê~íÉìêëI=Åìáëáåá≠êÉëI=ä~îÉJäáåÖÉI=~ëéáê~íÉìêëI íêçå´çååÉìëÉëI=íçåÇÉìëÉë=¶=Ö~òçåF=ëçåí=îÉåÇìë=ÅÜ~èìÉ=~åå¨É=éçìê=ìå=ãçåí~åí=ÇDÉåîáêçå=NQ=ãáääá~êÇë=ÇDbìêçë Ç~åë=éäìë=ÇÉ=NRM=é~óë=¶=íê~îÉêë=äÉ=ãçåÇÉK bäÉÅíêçäìñ=dêìééÉå=Éê=îÉêÇÉåë=ëí›êëíÉ=éêçÇìÅÉåí=~Ñ=ÉåÉêÖáÇêÉîåÉ=éêçÇìâíÉê=íáä=â›ââÉåJ=êÉåÖ›êáåÖëJ=çÖ=ìÇÉåÇ›êë ÄêìÖK=aÉê=ë‹äÖÉë=™êäáÖí=çîÉê=RR=ãáääáçåÉê=éêçÇìâíÉê=Ñê~=bäÉÅíêçäìñ=dêìééÉå=EÄä~åÇí=~åÇÉí=â›äÉëâ~ÄÉI=âçãÑìêÉê î~ëâÉã~ëâáåÉêI=ëí›îëìÖÉêÉI=ãçíçêë~îÉ=çÖ=éä‹åÉâäáééÉêÉF=íáä=Éå=î‹êÇá=~Ñ=Å~K=âêK=NMM=ãáääá~êÇÉêK=mêçÇìâíÉêåÉ=ë‹äÖÉë=á ãÉêÉ=ÉåÇ=NRM=ä~åÇÉ=îÉêÇÉå=çîÉêK bäÉÅíêçäìñJâçåëÉêåÉí=Éê=îÉêÇÉåë=ëí›êëíÉ=éêçÇìëÉåí=~î=ÉåÉêÖáÇêÉîåÉ=éêçÇìâíÉê=íáä=âà›ââÉåJI=êÉåÖà›êáåÖJ=çÖ=ìíÉåÇ›êë ÄêìâK==jÉê=Éåå=RR=ãáääáçåÉê=éêçÇìâíÉê=Ñê~=bäÉÅíêçäìñJâçåëÉêåÉí=Eëçã=âà›äÉëâ~éI=âçãÑóêÉêI=î~ëâÉã~ëâáåÉêI=ëí›îëìÖÉêÉI ãçíçêë~ÖÉê=çÖ=ÖêÉëëâäáééÉêÉF=íáä=Éå=îÉêÇá=~î=Å~K=NQ=ãáääá~êÇÉê=rpa=ëÉäÖÉë=™êäáÖ=á=ãÉê=Éåå=NRM=ä~åÇ=îÉêÇÉå=êìåÇíK MARIESTAD DT--AV...
