GO
3.12 GO EXECUTE USER PROGRAM
GO [<addr>]
Use the GO command (alias G) to initiate target code execution. All previously set breakpoints
are enabled. If an address is specified, it is placed in the target PC. Execution starts at the target
PC address.
The sequence of events is:
1. An address is specified and loaded into the target PC
2. If a breakpoint is set at the target PC address, the instruction is traced at the target PC
(executed in trace mode)
3. All breakpoints are inserted in the target code
4. Target code execution resumes at the target PC address
There are several methods for returning control to CPU32Bug:
Execute the .RETURN TRAP #15 function
Press the ABORT switch or RESET switch of the M68300PFB Platform Board
Encountering a breakpoint with 0 count
Generation of an unexpected exception
EXAMPLE The following program resides at $4000.
CPU32Bug>MD 4000;DI<CR>
00004000 2200
00004002 4282
00004004 D401
00004006 E289
00004008 66FA
0000400A E20A
0000400C 55C2
0000400E 60FE
CPU32Bug>RM D0<CR>
M68CPU32BUG/D REV 1
Go Execute User Program
MOVE.L
CLR.L
ADD.B
LSR.L
BNE.B
LSR.B
SCS.B
BRA.B
3-23
DEBUG MONITOR COMMANDS
D0,D1
D2
D1,D2
#$1,D1
$4004
#$1,D2
D2
$400E
GO
