Page 1: Network Camera
A-EN2-100-12 (1) Network Camera User’s Guide Before operating the unit, please read this manual thoroughly and retain it for future reference. Software Version 1.11 SNC-CX600W/CX600 © 2013 Sony Corporation... -
Page 2: Table Of Contents
Setting the Camera Image and Audio Table of Contents — Video / Audio Menu ........23 Picture Tab ............23 Video codec Tab ..........24 Audio Tab ............25 Overview Superimpose Tab ..........25 Features ..............4 Privacy masking Tab .........26 How to Use This User’s Guide ......5 Streaming Tab ...........27 System Requirements .......... -
Page 3: Table Of Contents
Setting the CLOUD service — CLOUD Menu ..............53 Setting Tab ............53 Others Glossary ..............55 Index ..............57 Table of Contents... -
Page 4: Overview
Overview NOTICE TO USERS © 2013 Sony Corporation. All rights reserved. This manual or the software described herein, in whole or in part, may not be reproduced, translated or reduced to Features any machine readable form without prior written approval from Sony Corporation. -
Page 5: How To Use This User's Guide
The illustrations of the camera and menu display in the Web Browser User’s Guide show the SNC-CX600W as an example. Windows Internet Explorer Ver. 7.0, Ver. 8.0, Ver. 9.0, Ver. 10.0* Printing the User’s Guide Firefox Ver.19.0... -
Page 6: Accessing The Camera Using The Web Browser
The live viewer window appears (in SSL Accessing the Camera communication). Using the Web Browser After the IP address has been assigned to the camera, check that you can actually access the camera using the Web browser installed on your computer. Start the Web browser on the computer and type the IP address of the camera in the URL address bar. - Page 7 The software is optimized for Internet Explorer using medium font. To display the viewer correctly To operate the viewer correctly, set the security level of Internet Explorer to Medium or lower, as follows: Select Tools from the menu bar for Internet Explorer, then select Internet Options and click the Security tab.
-
Page 8: Basic Configuration By The Administrator
Make the setting for sending the monitor image attached to an e-mail. Mail Transfer Tab (page 48) Set the user access right for the camera. User Tab (page 34) Use Wi-Fi to make the setting for connecting the camera (SNC-CX600W) Wi-Fi Tab (page 30) Basic Configuration by the Administrator... -
Page 9: Operating The Camera
Operating the Camera Administrator and User This network camera identifies those who log in as the Administrator or User. This section explains how to monitor the image from the The Administrator can use all the functions of this camera using your Web browser. network camera, including camera settings. -
Page 10: Logging In To System
Plug-in free viewer Logging in to System This viewer enables a browser other than Internet Explorer to display images. Notes Logging in as a user • If Automatic configuration is enabled in the Local Area Network (LAN) Settings of Internet Explorer, Start the Web browser on your computer and type the camera image may not be displayed. -
Page 11: Configuration Of Live Viewer
Control panel section Configuration of Live You can drag the panels to the monitor screen and Viewer configure them. To return to the operation panel, drag the panel and This section explains the functions of the parts and configure the operation panel. controls of the live viewer. -
Page 12: Camera Control Panel
Capture Camera control panel Click to capture a still image shot by the camera and to store it in the computer. Click to open the folder to be saved. Note In the case of Windows VISTA, Windows 7 or Windows 8, if “Enable Protected Mode”... -
Page 13: Monitor Image
Monitor screen Monitor image There are two modes for on-screen pan/tilt/zoom operation using a mouse: Area zoom mode and Vector dragging mode. A control bar is displayed on the screen. In the Area zoom mode, click to adjust the camera direction to the center of the image. -
Page 14: Controlling Via The Control Panel (Operation Common To Area Zoom Mode And Vector Dragging Mode)
Zoom control Plug-in free viewer ActiveX Click to zoom out, and click to zoom in. viewer JPEG MJPEG Zooming continues while the button remains pressed. Operation from × × Note control panel The four edges of the image may be dark depending on Area zoom the zoom position. -
Page 15: Panning And Tilting By Dragging The Screen (Vector Dragging Mode Only)
Panning and tilting by dragging the Switching Transmission screen (Vector dragging mode Mode only) When you click on the starting point on the image and You can change the transmission mode for video/audio drag to the end point, the camera pans/tilts in the data. -
Page 16: Playback Viewer
Note Playback viewer When connecting via a proxy server, neither Unicast nor Multicast can be selected. You can play, save or delete the movies recorded in the memory card. This function is available only in the following users. • Administrator •... -
Page 17: Search Panel
Search panel Control panel (Basic) Specify the search period. You can play, pause, stop, fast forward or jump the selected movie on the search results list. Also you can Start specify the start position for playback. Select the start time for searching. If you click the button, the control panel (detail) is displayed. -
Page 18: Monitor Image
Fast forward Click this button to fast forward the moving being played. Next record Jump to the next movie. Still image capture Save the capture of a recorded movie as a still image file to your computer. Click to open the folder in which the movie is to be saved. -
Page 19: Administrating The Camera
Example: “Date & time” tab of “System” menu Administrating the Camera This section explains how to set the functions of the See page 20 for details of the menu tabs and setting camera by the Administrator. options. For details about monitoring the camera image, see “Operating the Camera”... -
Page 20: Configuring The System - System Menu
Security Configuring the System Displays the Security menu for setting the login user name and password to specify which computer(s) can — System Menu connect to the camera. (“Setting the Security — Security Menu” on page 34) When you click System in the Administrator menu, the PTZ control... -
Page 21: Installation Tab
Adjust • The stabilizer may not respond, depending on the amount of vibration. Select how to set the day and time. • Be sure to set this function during the installation. Keep current setting: Select if you do not need to set •... -
Page 22: System Log Tab
Click Reload to reload the latest data. browser to specify the folder and save the setting data of the camera. The file name preset at the factory is “snc-cx600w.cfg” for SNC-CX600W. Restore setting Loads the stored setting data of the camera. -
Page 23: Setting The Camera Image And Audio
Visibility Enhancer Setting the Camera Using the Visibility Enhancer function will make the darker part of a camera image brighter as well as Image and Audio automatically correct brightness and contrast to show bright parts clearly without overexposure. — Video / Audio Menu Backlight compensation When you click Video / Audio... -
Page 24: Video Codec Tab
Metal halide lamp: Sets a white balance suitable for Image codec photography under a metal halide lamp. Select H.264, JPEG or Off. Note that Image 1 cannot be White LED: Sets a white balance suitable for set to Off. photography under the light of white LEDs.When you use the camera's integrated LED light, the ATW Note setting is recommended. -
Page 25: Audio Tab
Auto rate control Audio Tab Select the checkbox to enable automatically adjusting the most suitable bitrate for video playback. This setting Audio sending is recommended in the case of unstable network connection or wireless network interference. Make settings for sending audio from the microphone. You can set the codec individually for Video 1, Video 2 and Video 3. -
Page 26: Privacy Masking Tab
Preview screen Transparent Preview the image, and adjust the superimposed image. Select the background color transparent of the You can move the position of superimposed image superimposed text. When you select Off, transparent is displayed on the preview screen by drag and drop. not available. -
Page 27: Streaming Tab
Clear all specified here and an odd number with 1 added to the specified number) are used for audio data Click the button to delete all privacy mask. communication and control. When operating multi- transmission at the same time, a different port number Setting a privacy mask will be used in every transmission based on the port Operate according to the following procedure to set a... -
Page 28: Rtsp Setting
Multicast streaming RTSP multicast audio port number Specify the audio transmission port number used for Set whether the camera uses multicast streaming for RTSP multicast streaming. The default setting is 59000. H.264 video data and audio data or not. It reduces the Specify an even number from 1024 to 65534. -
Page 29: Configuring The Network - Network Menu
DHCP server camera and the computer. Select Obtain an IP address automatically The Network menu consists of the following tabs: (DHCP). SNC-CX600W: Network, Wi-Fi and QoS The IP address, subnet mask, default gateway are SNC-CX600: Network and QoS assigned automatically. Note... -
Page 30: Wi-Fi Tab
This function is not available in a multi-prefix environment. The transmission may not work Wi-Fi Tab properly. Supported models: SNC-CX600W To specify the IPv6 address manually Use this tab to set the connection of the Wi-Fi network. Deselect Obtain IP address automatically. Type... -
Page 31: Manual Setting Of A Wi-Fi Network
Signal WEP (Deprecated) Type a WEP key (encryption key) of alphanumeric Displays the signal strength. If it is lower than 60%, characters. improve the installation environment as follows: Communication contents may be intercepted because the security of WEP is weak. This setting is not Change the installation position of the camera. -
Page 32: Connection Status
Click Connect to start the connection by PIN To specify the IP address manually method. It takes up to two minutes to connect to Deselect Obtain an IP address automatically WPS. (DHCP). Type the address in the IP address, Subnet mask and Default gateway boxes. Host When the connection is complete, the status will be name and Domain suffix are not available. -
Page 33: Qos Tab
Secondary DNS server Type the IP address of the secondary DNS server, if Used when registering on the QoS table. necessary. QoS is set according to the following procedure: Select No. from No. and enter the necessary OK/Cancel conditions for Network address, Subnet, Protocol See “Buttons common to every menu”... -
Page 34: Setting The Security - Security Menu
Light: In addition to the View mode, the user can select Setting the Security the image size of the live viewer, select codec and capture a still image. — Security Menu View: The user can only monitor the camera image. For the functions available for each viewer mode, see When you click Security... -
Page 35: Ssl Tab
Display the viewer in SSL connection. Note Refer to “Using the SSL function” on page 6 for You can access the camera even from a computer having connection. an IP address whose access right is set to Deny, if you enter the user name and password set for the After confirming that SSL connection is possible, Administrator boxes in the User menu. - Page 36 For reasons of security, we recommend using this – Use an external certificate is selected and the mode only when there is no problem even if perfect private key password included in the certificate is security is not saved. not specified correctly. –...
-
Page 37: How To Install The Ca Certificate
Notes Note • When using the client authentication, the personal When you set SSL client authentication to Enable and certificate must be successfully installed on the PC to click OK, the camera will immediately operate to enable use it. If this preparation cannot be performed, do not client authentication. -
Page 38: To Remove An Installed Ca Certificate
Click Installation Certificate..To remove an installed CA The Certificate Import Wizard appears. certificate In Internet Explorer, click in the order Tools, Internet options, Content tab and Certificates. The Certificates dialog appears. Click Next. Select the certificate you want to remove. The CA certificate is usually stored in Trusted Root Certification Authorities. -
Page 39: 802.1X Tab
Select Certificates from the list, then click Add. Authenticator Certificate Snap-in is displayed. An authenticator forwards certificate request data or response data that the supplicant or authentication server Select Computer account as the certificate issues to the other party. Normally a hub, router or administrated in this Snap-in, then click Next. -
Page 40: Client Certificate
TLS: By this method, the supplicant and the server To delete the client certificate authenticate each other using a certificate. This Click Delete, and the client certificate stored in the enables secure port authentication. camera will be deleted. PEAP: By this method, an EAP password is used for the supplicant authentication and a certificate is used for Private key password server authentication. -
Page 41: Setting The Ptz Control - Ptz Control Menu
Setting the PTZ control Setting the Camera tampering detection/ — PTZ control Menu Motion detection When you click PTZ control in the Administrator menu, the PTZ control menu appears. — Action input Menu The PTZ control menu consists of the Solid PTZ tab. When you click Action input in the Administrator menu,... -
Page 42: Camera Tampering Detection Tab - Set The Camera Tampering Detection
Motion detection: The alarm is triggered by the motion Motion detection Tab — Set the detection function. motion/VMF detection VMF: The alarm is triggered by the VMF function. Face detection: The alarm is triggered by the face Motion detection responds to moving objects in the detection function. -
Page 43: Setting Items For Motion Detection
Passing VMD settings A passage line is determined, and when a moving object passes the setting line, an alarm sounds. Detection area Specify the effective scope of motion detection. Left object When a moving object has been left in the designated area, an alarm sounds. -
Page 44: Vmf Settings
After the deletion, the cursor will return to its Detection size original form. To exit this operation, click this Specify the minimum detection size and maximum button again. detection size for motion detection. To specify the It is the same function as the button displayed under detection size, you can either enter values or drag the VMF settings. -
Page 45: Filter Settings
Time until left/removed object is detected Passing Enter the time you want to elapse before the alarm is triggered. This setting is available only when the filter type is set to Left object or Removed object. Filter settings Settings for each filter can be edited here. The inspection line and active window are set to default values. -
Page 46: Trigger Size
Left object Trigger size Specify the minimum trigger size and maximum trigger size of motion. To specify the size, you can either enter values or drag the vertexes of the area. This criterion is for whether a moving object has been left in the trigger area. -
Page 47: Face Detection Tab - Set The Face Detection
Trigger speed VMF status indicator of Matching decision Specify the minimum and maximum speeds to be detected. The indicator is on when the set filter type conditions are met. Full-screen display button Click to display the ActiveX area in full screen. Clicking again will show the normal display. -
Page 48: Network Disconnection Tab - Monitoring The Connection Of A Specified Ip Address
Detection area Setting the Action Specify the effective scope of face detection. You can set the area in the same way as the detection area setting in output — Action output VMD settings. (page 43) A maximum of ten detection areas can be set. Similar to Menu the detection area setting in VMD settings, a trigger area and vertexes can also be moved. -
Page 49: Event Triggered Execution
Authentication Address Select whether authentication is required when you send an e-mail. Recipient e-mail address 1, 2, 3 Type the recipient e-mail address using up to 64 None: No authentication is required when an e-mail is characters. sent. You can specify up to three recipient e-mail addresses. SMTP: Select when SMTP authentication is required. -
Page 50: Edge Storage Tab - Setting The Edge Storage Movie And Still Image Function
None: The name of the sent file will be the image file Edge Storage Tab — Setting the name. Edge Storage movie and still image Date & time: The date & time suffix is added to the image file name. function The date &... -
Page 51: Edge Storage Movie
Overwrite Edge Storage movie Select On to overwrite the file when there is insufficient memory space. Recording status When you select the checkbox, overwrite is enabled. Display the current recording status. Old records will be overwritten in chronological order. The recording status will not be updated until the screen When you deselect the checkbox, overwrite is is refreshed. -
Page 52: Voice Alert Tab
Test audio upload tool from the following URL. Perform the lighting test of the White LED. http://www.sony.net/ipela/snc When you press the execute button, the LED lights up with the illuminator level you set. When you press the Voice alert 1, 2, 3 stop button, the LED turns off. -
Page 53: Setting The Schedule - Schedule Menu
The CLOUD service is not available in some regions. When you click the Schedule tab, the setting menu for For details, contact an authorized Sony dealer. each action is displayed. You can set the schedule of the Mail Transfer (Event),... - Page 54 Site code The registered site code appears. Connection status The connection status to the CLOUD service appears. OK/Cancel See “Buttons common to every menu” on page 19. Setting the CLOUD service — CLOUD Menu...
-
Page 55: Glossary
DNS server Others Acronym for Domain Name System server. As an IP address required for connecting to the device on an IP network is numerical and difficult to remember, the Domain Name System was established. A domain name Glossary is alphabetic and is easier to remember. When a client computer uses a domain name to connect to another computer, it asks a DNS server to translate the name into ActiveX control... -
Page 56: Network Bandwidth
Network bandwidth Bit rate that can be used for networking. Acronym for Transmission Control Protocol. A standard protocol used for Internet connection. Compared with the other protocol, UDP, TCP provides reliable NTP server communication but communication speed is slower. Network time server that transmits and receives time information over the networks. -
Page 57: Index
Color ..........26 Filter type ........44 Index Common setting ....30 Format SD memory card....21 Connection status ......32 Frame rate ......11 Connection to the CLOUD Full-screen display button ....47 server..........53 Numerics Content........... 49 802.1X Tab........39 Contrast .......... - Page 58 mode of operation ......12 Recording data........51 Time zone ........21 Model Name........20 Recording status ......51 Token ..........53 Monitor image......13 Recording target ......51 Transmission Mode ......15 Monitor screen .......13 Recording time .......51 Transparent ........26 Monitored IP address .....48 Refresh ...........31 Trigger size........46 Motion detection Tab .....42 Registered information ....53 Trigger speed ........47...
