Air Conditioner Features
(continued)
TO OPERATE ON FAN ONLY:
PRESS MODE
CHOOSE FAN
TO USE THE ENERGY SAVER
FEATURE:
PRESS MODE
ENERGY SAVER
TIMER: DELAY STOP / START
FEATURE
DO THIS:
PRESS
TIMER BUTTON
SZ000728(En)-Yaokong 7
YOU WILL SEE:
DO THIS:
BUTTON
ONLY
YOU WILL SEE:
DO THIS:
BUTTON
CHOOSE
YOU WILL SEE: TIMER SETTING
LIGHT On
Note: Use this function only when cooling is not desired, such
as for room air circulation or to exhaust stale air(on some
models). (Remember to open the vent during this function, but
keep it closed during cooling for maximum cooling efficiency.)
You can choose any fan speed you prefer.
During this function, the display will show the actual room
temperature, not the set temperature as in the cooling mode.
LIGHT On
Note: In this mode, the fan will continue to run for 3 minutes
after the compressor shuts off. The fan then cycles on for 2
minutes at 10 minute intervals until the room temperature is
above the set temperature, at which time the compressor turns
back on and cooling stars.
LIGHT On
Note: For Delay Stop, the unit must be in the On position.
Note: For Delay Start, the unit must be in the Off position.
To adjust timer setting, tap or hold the UP arrow(
arrow( ) to change delay timer at .5 hour increments, up to 10
hours, then at 1 hour increments up to 24 hours. The control will
count down the time remaining until start (8, 7.5, 7, etc.). The Delay
Start mode automatically selects cooling with maximum Fan Speed.
The temperature maintained will be the same as previously set. To
change the set temperature, press "COOL" then Up or Down ar-
rows until the desired temperature is indicated on the display. After
5 seconds, the control will automatically change the display back
to the hours remaining until the unit will start/stop. Turning the unit
"ON" or "OFF" at any time will cancel the Delay Start/Stop function.
The Delay Start/Stop Feature will work until the unit either starts or
stops. Once that happens the above steps have to be repeated
again.
