Epson PowerLite 7700p User Manual

Epson projector user manual
Hide thumbs Also See for PowerLite 7700p:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
control panel
speaker
handle
foot adjust lever
connector panel
(see below)
A/C power inlet
VGA (video in) connector
S-video
Monitor Out
connector
connector
composite
(RCA)
video
Monitor Out
connector
S-Video
audio
Video
L-Audio-R
connectors
for
Remote
composite
video
optional remote
receiver connector
serial connector for computer
running EMP Link V software
status lights
front infrared
sensor
adjustable
foot
focus ring
zoom ring
rear infrared
sensor
DVI connector
BNC connectors
(for Computer 2
VGA /DVI
or component
switch
video source)
Computer 1
Analog Digital
Computer 2 /Component Video
R/Cr/Pr
G/Y
B/Cb/Pb H/C Sync V Sync
Computer 1
audio
L-Audio-R
Audio(Computer1) Audio Out
(S-Video/BNC)
connector
Control (RS-232C)
Mouse 2
Mouse 1
Audio out
connector
S-Video/BNC
audio
connector
Mouse connectors
EPSON PowerLite 7700p Projector

Projector Specifications

General
Type of display
Size of liquid
crystal panels
Lens
Resolution
Color reproduction 24 bit, 16.7 million colors
Brightness
Contrast ratio
Image size
Projection distance 3.6 to 47.6 feet (1.1 to 14.5 meters)
Projection methods Front, rear, upside-down (ceiling mount)
Internal speaker
system
Optical aspect ratio 4 : 3 (horizontal : vertical)
Zoom ratio
Noise level
Keystone correction
angle
Projection Lamp
Type
Power
consumption
Lamp life
Part number
Remote Control
Range
Batteries
Mouse Compatibility
Supports PS/2, USB, serial, ADB (optional cable required for
serial and ADB)
Remote IR Receiver
Supports EPSON Remote IR Receiver, 10-foot cable (typical
use for rear screen projection)
11/00
EPSON PowerLite 7700p Projector - 1
Poly-silicon Thin Film Transistor (TFT)
Diagonal: 1.3 inches (33.6 mm)
F=1.7 to 2.3, f=49 to 63 mm
1024 768 pixels (native display format)
3000 lumens (ANSI)
400 : 1
22 to 300 inches
3W 3W stereo
1 : 1.3
38 dB
± 30° maximum
UHE (Ultra High Efficiency)
200 W
About 1500 hours
ELPLP12
32.8 feet (10 meters)
Alkaline AA (2)

Advertisement

Table of Contents
loading

Related Manuals for Epson PowerLite 7700p

Summary of Contents for Epson PowerLite 7700p

  • Page 1: Projector Specifications

    Supports PS/2, USB, serial, ADB (optional cable required for serial and ADB) Computer 1 Remote IR Receiver audio connector Supports EPSON Remote IR Receiver, 10-foot cable (typical use for rear screen projection) Mouse 2 Mouse 1 Audio out connector Mouse connectors...
  • Page 2 “native” formats (such as XGA). In addition, the frequencies of some computers may not allow images to display correctly; see your computer’s documentation for details. 2 - EPSON PowerLite 7700p Projector Mode Refresh Rate (Hz) VGACGA...

  • Page 3: Positioning The Projector

    PAL (SVGA) PAL (XGA) SECAM (SVGA) SECAM (XGA) The image is resized so that it displays using one of the projector’s native formats. Computer Video Port Pin Assignments The Computer 1 analog port and the Monitor Out port are female video RGB, 15-pin micro-D-style connectors. Here are...
  • Page 4 Keystone If you place the projector’s lens so it’s level with the top of the screen, the image will be square and you won’t have to adjust it. If you place the lens lower than the top of the screen, you’ll have to tilt the projector upward if you want to fill the whole screen with the image.

  • Page 5: Displaying An Image

    Power the projector to turn it on. The power light flashes green as the projector warms up, and the projection lamp comes on in about 30 seconds. The power light stays green, and you may...

  • Page 6: Projector Status Lights

    If the projected image isn’t square or has a “keystone” shape, do one or more of the following: If your image looks like projector off to one side of the screen, at an angle. Move it directly in front of the center of the screen, facing the screen squarely.

  • Page 7: Using The Control Panel

    Squares up a raised image, correcting up to a ±30° tilt. Adjusts the volume when pressed with the Shift button. (remote control) switch is in the EPSON PowerLite 7700p Projector - 7 position...
  • Page 8 Open the cover just below the button to access these remote control buttons: Menu Comp1 E@sy-MP Auto P in P 8 - EPSON PowerLite 7700p Projector This table summarizes the functions on the remote control. Button Power Power R/C on/off on/off switch Freeze...

  • Page 9: Cleaning The Lens

    (such as an artist’s camel-hair brush). If the dirt is difficult to remove or if the filter is torn, replace it. Contact your dealer or call EPSON at (800) 873-7766 in the United States and Canada to obtain a new one.

  • Page 10: Replacing The Lamp

    Note: You can check to see how many hours the lamp has been used through the About menu. Contact your dealer or call EPSON at (800) 873-7766 in the United States and Canada for a replacement lamp. Request part number...

  • Page 11: Optional Accessories

    DVI to DFP, 10 feet (3 meters) You can purchase these accessories from your dealer or by calling EPSON at (800) 873-7766; or visit the EPSON Store at www.epson.com (U.S. sales only). In Canada, please call (800) 873-7766 for dealer referral.
