Page 2: Important Safety Information
● Under no circumstances should you attempt to repair the machine yourself. Repairs carried out by inexperienced persons may cause injury or serious malfunctioning. Contact your local Service Force Centre. Always insist on genuine Electrolux spare parts. -
Page 3: Table Of Contents
Contents For the User Important Safety Information Your New Washer Dryer Description of the Appliance Detergent dispenser drawer Child safety feature The Control Panel Programme Information Operating sequence Washing only Load the laundry Measure out the detergent and the fabric softener Jetsystem wash Switch the machine on Select the required programme... -
Page 4: Your New Washer Dryer
Your New Washer-Dryer Your new washer-dryer fitted with the Electrolux “NEW JET SYSTEM”, meets all modern requirements for effective treatment of laundry with low water, energy and detergent consumption. Even small loads are washed “economically” because the amount of water used is regulated automatically according to the load and type of fabric. -
Page 5: Description Of The Appliance
Description of the Appliance 1 Detergent dispenser drawer 2 Programme guide 3 Control panel 4 Door opening handle 5 Filter 6 Adjustable feet Detergent dispenser drawer Prewash Main wash Fabric softener The programme chart is in the interior part of the drawer. -
Page 6: The Control Panel
The Control Panel 1 Detergent dispenser drawer The programme chart is in the interior part of the drawer. light AINS This light comes on when the ON/OFF button is pressed, and goes out when it is pressed again. 3 ON/OFF button Press this button to switch the machine on. - Page 7 6 “Quick wash” button This option can be used for lightly soiled cotton, synthetic or delicate items hat have been used or worn for a short time. This option is not available with the (Wool) /Handwash programme, the Energy saving programmes (E60°...
- Page 8 Reset/cancellation of the programme If the programme selector dial is turned to Off position, three blinking dashes are displayed. Now you can select a new programme. (If the programme selector dial has not been turned to Off position at the end of the previous washing cycle, when you press the ON/OFF button to switch the machine on, the display will show a blinking zero.)
-
Page 9: Programme Progress Display
End of programme When the programme has finished a flashing zero is displayed. The door can be opened when pilot light has gone out and if the Rinse hold Night Cycle option has not been selected. 13 Programme progress display By selecting the wash programme, the pilot lights corresponding to the various phases making up the programme come on. -
Page 10: Programme Information
Interrupting a programme Depress the Start/Pause button to interrupt a programme which is running: the corresponding light starts to flash. Depress the same button to restart the programme. Opening the door after the programme has started You can open the door, after having set the washer-dryer to PAUSE, provided the following conditions exist: •... -
Page 11: Operating Sequence
Operating Sequence Washing only Before the first wash, we recommend that you run a cotton cycle at 95°C, without any laundry in the machine, to remove any manufacturing residue from the drum and tub. Pour 1/2 a measure of detergent into the main wash compartment of the dispenser drawer and start the machine. -
Page 12: Select The Spin Speed Or Rinse Hold Option
5. Select the Spin speed or Rinse Hold option Depress the spin speed button to choose the required speed or Rinse Hold option : the corresponding light comes on. 6. Select the required options The light corresponding to the depressed button illuminates. -
Page 13: Drying Only
Switch the machine off by pressing the ON/OFF button. Remove the laundry from the drum and carefully check that the drum is empty so as to avoid any forgotten items being damaged in a subsequent wash (e.g. shrinking) or their colour running into a load of whites. If you do not intend to carry out another wash, close the water tap. -
Page 14: Washing And Drying Hints
Washing and Drying Hints Do NOT overload the machine. Weigh the laundry the first few times you use the appliance. The average weights of the most common items are listed below as a guide: 1000g = 1 kg Sheet Pillow case Tablecloth Serviette Tea towel... -
Page 15: Which Detergent
Which detergent?... To ensure you obtain the best wash results from your appliance, it is important to use the right detergent in your everyday wash, and only detergents recommended for use in automatic machines. To maintain the appearance of your clothes and household textiles and to make them last longer you should use different types of detergent for different washes, whether for whites, colours or delicates. -
Page 16: Wash Care Symbols
Wash Care Symbols Wash care labels inside garments recommend how to launder your clothes with the best results. The care labelling code is in line with care labelling used in the rest of Europe. The symbols used make it easy to select the correct programme on your washing machine. -
Page 17: Washing And Special Programmes
Washing Programmes ype of Section Temp. fabric 95° Whites OTTON Whites E60° OTTON Economy Whites and 60° OTTON Fast coloureds E40° Coloureds OTTON CONOMY Non-fast 30°-40° OTTON coloureds Synthetics 60° YNTHETICS E60° Synthetics YNTHETICS CONOMY Synthetics YNTHETICS 30°-40° Cold 30°-40° Delicates ELICATES (Cold) -
Page 18: Special Programmes
Special Programmes Selector dial position/ Programme description Programme Rinses 3 rinses with liquid additive if required Long spin Drain For emptying out the last rinse water in programmes with the “rinse hold” or “night cycle” option. Spin Separate long spin at 1400 rpm max Easy Iron Wash at 40°C... -
Page 19: Drying Programmes
Drying Programmes Degree of drying Type of fabric Extra dry Cotton and linen Ideal for (bathrobes, bath towelling towels, etc.) materials Cotton and linen (towels, T-shirts, bathrobes) Store dry (*) Suitable for items to put away without ironing Synthetics and mixed fabrics (jumpers, blouses, underwear, household linen) -
Page 20: Maintenance And Cleaning
Maintenance and Cleaning Before any maintenance or cleaning is carried out you must DISCONNECT the appliance from the electricity supply. Descaling The water we use normally contains lime. It is a good idea to periodically use a water softening powder in the machine. -
Page 21: The Dangers Of Freezing
Unscrew and remove the filter. Clean carefully under a fast running tap. Warning When the appliance is in use and depending on the programme selected there can be hot water in the filter. Never remove the filter during a wash cycle, always wait until the appliance has finished the cycle, and is empty. -
Page 22: Something Not Working
Something Not Working Certain problems are due to lack of simple maintenance or oversights, which can be solved easily without calling out an engineer. Before contacting your local Service Force Centre, please carry out the checks listed below. IMPORTANT: if you call out an engineer to a fault listed below, or to repair a fault caused by incorrect use or installation, a charge will be made even if the appliance is under guarantee. -
Page 23: Service And Spare Parts
5. The purchase date. Customer Care For general enquiries concerning your Electrolux appliance or for further information on Electrolux products, please contact our Customer Care Department by letter or telephone at the address below or visit our website at www.electrolux.co.uk... -
Page 24: Guarantee Conditions
Standard guarantee conditions We, Electrolux, undertake that if, within 24 months of the date of the purchase, this Electrolux appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option,... -
Page 25: Installation Instructions
Installation Instructions It is dangerous to alter the specifications or attempt to modify this product in any way. Care must be taken to ensure that the appliance does not stand on the electrical supply cable. Any electrical work required to install this appliance should be carried out by a qualified electrician or competent person. -
Page 26: Unpacking
Unpacking All transit bolts and packing must be removed before using the appliance. You are advised to keep all the packaging for re-use in case the machine is to be transported again. Using a spanner unscrew and remove the rear right bolt. Lay the machine gently on its back, making sure that the hoses are not squashed. -
Page 27: Water Drainage
If you cannot make the cold water connection direct from the rising mains, you may be able to operate the appliance from your cold water storage system. There should be a minimum distance of 5.02m (16.5 ft) between the appliance’s inlet and the bottom of the water storage tank. -
Page 28: Levelling
The drain hose may be extended to a maximum of 4 metres. An additional drain hose and joining piece is available from your local Service Force Centre. The joining piece must have an internal diameter of 18mm. Important Before connecting up the machine to new pipework or to pipework that has not been used for some time, run off a reasonable amount of water to flush out any debris that may have collected in the pipes. -
Page 29: Electrical Connection
Electrical connection Any electrical work required to install this appliance should be carried out by a qualified electrician or competent person. WARNING: THIS APPLIANCE MUST BE EARTHED. The manufacturer declines any liability should this safety measure not be observed. Before switching on, make sure the electricity supply voltage is the same as that indicated on the appliance’s rating plate. -
Page 30: Building-In
Building-in This appliance has been designed to be built into the kitchen furniture. The recess should have the dimensions shown in picture A. When installing the appliance into the kitchen furniture ensure, if possible, the hoses are placed in either of the two recesses on the back of the appliance. - Page 31 If the door has to be opened from left to right, invert the position of the plates (7), the magnet (4) and the plate (5) (Fig. B and E). Mount the countermagnet (6) and the hinges (1) as previously described. Recommendations regarding the construction and fitting of a base when the installation requires an...
