4.3.4 Dump (including page length setting, error code, and scanning compensation data)
[Function code 05]
n n
Function
This function prints out the following data:
- Page length setting for recording paper
- Error code
- Scanning compensation data
n n
Operating Procedure
(1) Open the paper compartment cover and hold down the COPY ALL and FEED keys for 15
seconds.
(2) Close the paper compartment cover and press the COPY ALL key.
The machine prints out the following:
- Page length setting for recording paper
PAPER SIZE
PAPER SIZE
- Error code
ERR=xx (where xx denotes the latest error code. For details, refer to Chapter V.)
- Scanning compensation data
a) White level data for green LEDs in CIS0 (66 bytes)
b) White level data for green LEDs in CIS1 (72 bytes
c) White level data for green LEDs in CIS2 (63 bytes)
d) White level data for red LEDs in CIS0 (66 bytes)
e) White level data for red LEDs in CIS1 (72 bytes)
f) White level data for red LEDs in CIS2 (63 bytes)
g) Clamp PWM value (2 bytes)
h) Gain PWM value (12 bytes for green and red images, 6 bytes/color)
i) Compensation coefficient data for background color (12 bytes for green and red
Upon completion of printout, the machine returns to the regular operation mode.
NOTE: If any data is abnormal, its code will be printed in inline style, as shown on the next
page.
NOTE: All bytes of codes in d), e) and f), the last six bytes of codes in h), and the last three
bytes of codes in i) might be printed in inline style as abnormal; however, they can be ignored
for machines not supporting red & black copying. Those compensation data are needed for
red & black copying.
LETTER
A4
LEDs, 2 bytes/color/CIS)
(if the letter size is selected)
(if the A4 size is selected)
IV - 6
