Chapter 4
System Board
12. Repeat Steps 7-11 to install all of the DIMMs for your memory
configuration.
13. If you have completed the DIMM installation, close the Netserver and
return it to the rack where power can be applied.

Removing DIMMs

You may need to remove a DIMM module to downsize your memory
configuration or to replace a defective DIMM.
1. If the HP Netserver is already installed and working, power down the
Netserver.
Refer to Chapter 1, "Controls, Ports, and Indicators."
2. Disconnect the power cables and all external cables.
If necessary, label each one to support re-assembly.
WARNING
The power supply will continue to provide standby current to
the Netserver until the power cable is disconnected.
3. Remove the Netserver chassis from the rack and lay it on a flat surface.
32
Figure 4-4. DIMM Insertion
Installing Additional Memory
DIMM
0
Slots
1
2
3
