3. Two-stage thread tension mechanism (Option)

4. Stepping foot control mechanism

Stepping foot
control mechanism
G
G
G
Two-stage
thread tension
G
mechanism
G
G
G
BAS-364E, 366E, 370E, 375E
This mechanism is used to enable selection of the
thread tension in two steps when sewing a single
pattern.
It is useful when a different sewing tension is necessary
while sewing a single pattern due to the sewing direction
or differences in the material.
Use the programmer to program the different needle
thread tensions in two steps.
The two-stage thread tension mechanism can be set
to operate or not operate by means of the memory
switch.
If the thickness of the material being sewn changes
when sewing one pattern, an intermittent presser foot
height can be selected without interrupting sewing.
Use the programmer to program the intermittent presser
foot height.
The height of the intermittent presser foot can be
changed in 0.5 mm or 1 mm increments. Operate the
panel and change the memory switch setting to select
the desired mode.
Chapter 8 DEVICES
42
