Sony XAV-601BT Installation/Connections

4-419-668-52(1)
AV Center
Installation/Connections
XAV-601BT
  
  
× 8
× 2

a b c
Equipment used in illustrations (not supplied)
Front speaker iPod
Rear speaker Rear view camera
Power amplifier Monitor
Subwoofer Smartphone
Cautions Connection example
 Run all ground (earth) leads to a common ground
Notes (-A)
(earth) point.  Be sure to connect the ground (earth) lead before connecting the amplifier.
 This unit is designed for negative ground (earth) 12 V  The alarm will only sound if the built-in amplifier is used.
DC operation only. Notes (-B)
 Do not disassemble or modify the unit.  You cannot use multiple auxiliary devices simultaneously, even if they
are connected to different terminals.
 Do not install in locations which interfere with airbag
 To connect an iPod via RC-202IPV, make sure to connect the video
operation.
output plug to AUX1 IN.
 Do not get the leads under a screw, or caught in moving
parts (e.g. seat railing).
 Before making connections, turn the car ignition off to Connection diagram
avoid short circuits.
 Connect the yellow and red power supply leads only
 To a common ground (earth) point
after all other leads have been connected.
 Be sure to insulate any loose unconnected leads with First connect the black ground (earth) lead, then connect the yellow
and red power supply leads.
electrical tape for safety.
 To the power antenna (aerial) control lead or the
 Do not press on the LCD when installing the unit.
power supply lead of the antenna (aerial) booster
 Install the unit with the monitor facing straight forward;
Notes
do not install it at a slanted angle.
 It is not necessary to connect this lead if there is no power antenna
Notes on the power supply lead (yellow) (aerial) or antenna (aerial) booster, or with a manually-operated
telescopic antenna (aerial).
 When connecting this unit in combination with other
 If your car has a built-in FM/AM antenna (aerial) in the rear/side
stereo components, the amperage rating of the car
glass, see "Notes on the control and power supply leads."
circuit to which the unit is connected must be higher
To AMP REMOTE IN of an optional power
than the sum of each component's fuse amperage rating.
amplifier
 If no car circuits are rated high enough, connect the unit
This connection is only for amplifiers. Connecting any other system
directly to the battery.
may damage the unit.
 To a car's illumination signal
Be sure to first connect the black ground (earth) lead to a common
Parts list
ground (earth) point.
 To the +12 V power terminal which is energized
when the ignition switch is set to the accessory
 The numbers in the list correspond to those in the
position
instructions.
Notes
 The bracket  is attached to the unit before shipping.
 If there is no accessory position, connect to the +12 V power
Before mounting the unit, use the release keys  to
(battery) terminal which is energized at all times.
remove the bracket  from the unit. For details, see
Be sure to first connect the black ground (earth) lead to a common
"Removing the bracket ()" on the reverse side of the ground (earth) point.
 If your car has a built-in FM/AM antenna (aerial) in the rear/side
sheet.
glass, see "Notes on the control and power supply leads."
 Keep the release keys  for future use as they are
 To the +12 V power terminal which is energized
also necessary if you remove the unit from your
at all times
car.
Be sure to first connect the black ground (earth) lead to a common
 Assemble the parts of the microphone  before use. For
ground (earth) point.
details, see "Installing the microphone ()" on the  To the parking brake switch cord
reverse side.
 To an auxiliary device such as a portable media
Caution player, game console, etc. (not supplied)
Handle the bracket  carefully to avoid injuring your
Tip
fingers. You can use an RCA cord (not supplied) to connect auxiliary devices.
 To the +12 V power terminal of the car's rear lamp
lead (only when connecting the rear view camera)
Notes on the control and power supply leads
 REM OUT lead (blue/white striped) supplies +12 V DC when you turn on
the tuner.
 If your car has built-in FM/AM antenna (aerial) in the rear/side glass,
connect REM OUT lead (blue/white striped) or the accessory power
supply lead (red) to the power terminal of the existing antenna (aerial)
booster. For details, consult your dealer.
 A power antenna (aerial) without a relay box cannot be used with this
unit.
Memory hold connection
When the yellow power supply lead is connected, power will always be

supplied to the memory circuit even when the ignition switch is turned off.
Catch
Note
Before installing, make sure that the catches on both sides of the bracket
 are bent inwards 3.5 mm ( 5 / in). If the catches are straight or bent
32
outwards, the unit will not be installed securely and may spring out.
A
FRONT AUDIO
OUT
REAR OUT
Z×Z L / R
SUB OUT
REAR AUDIO
OUT
B
AUX AUDIO
IN
Video camera*
AUX IN
( VIDEO )
CAMERA
AUX1 IN
( VIDEO )
* not supplied
RC-202IPV*
Notes on speaker connection
 Before connecting the speakers, turn the unit off.
 Use speakers with an impedance of 4 to 8 ohms, and with adequate
power handling capacities to avoid damage.
 Do not connect the speaker terminals to the car chassis, or connect the
terminals of the right speakers with those of the left speakers.
 Do not connect the ground (earth) lead of this unit to the negative (–)
terminal of a speaker.
 Do not attempt to connect the speakers in parallel.
 Connect only passive speakers. Connecting active speakers (with
built-in amplifiers) to the speaker terminals may damage the unit.
 To avoid a malfunction, do not use the built-in speaker leads installed in
your car if they feature a common negative (–) lead for the right and left
speakers.
 Do not connect the unit's speaker leads to each other.
Notes on connection
 If "Output connection failure." appears in the display, make sure the
speaker and amplifier are connected correctly.
 To use the monitor for the rear seats, connect the parking brake switch
cord to the ground (earth).
Black Orange/white striped
REM OUT Blue/white striped Red
Max. supply current: 0.4 A
Yellow
Light green
White/black striped
Gray/black striped
* 4
Green/black striped
Purple/black striped
AUX2 AUDIO
IN
AUX2 IN

AUX1 IN
EXT
REMOTE IN* 7
CAMERA
From car antenna (aerial)
Fuse (10 A)
MIC IN* 3
 REAR OUT
ZxZ L / R* 6

*
2
* 4
REVERSE IN
FRONT
AUDIO OUT
AUX1 AUDIO
IN
*
4
*
4
REAR SUB OUT
AUDIO OUT
ILLUMINATION
PARKING BRAKE
*
5
White
Left
Gray
Right
*
1
Green
Left
Purple
Right
* 8
* 4
* 4
* Speaker impedance: 4 – 8 ohms × 4
1
* 2 For details on installing the microphone, see "Installing the microphone
()" on the reverse side.
* 3 Whether in use or not, route the microphone input cord such that it does
not interfere with driving. Secure the cord with a clamp, etc., if it is
installed around your feet.
* 4 RCA pin cord (not supplied)
* For details on connecting to the parking brake switch cord, see
5
"Connecting the parking brake lead ()" on the reverse side.
* 6 The sound is output from this terminal only when ZONE x ZONE is
activated. This terminal outputs a fixed level regardless of the volume
control of the unit.
* A separate adaptor may be required.
7
* 8 Not supplied.
