Summary of Contents for Beko WMB91242L
- Page 1 Automatic Washing Machine WMB91242LC WMB91242LB...
- Page 2 Your appliance also contains a great amount of recyclable material. It is marked with this label to indicate the used appliances that should not be mixed with other waste. This way, the appliance recycling organised by your manufacturer will be done under the best possible conditions, in compliance with European Directive 2002/96/EC on Waste Electrical and Electronic Equipment.
-
Page 3: Table Of Contents
Ending the program through canceling 22 First Use ......6 Program in rinse hold mode..22 Intended use . -
Page 4: Your Washing Machine
Your Washing Machine Overview 4 - Control Panel 1 - Detergent Drawer 5 - Filter Cap 2 - Door 6 - Height-adjustable feet 3 - Top Lid 4 - EN... -
Page 5: Specifications
1200 1200 Specifications of this appliance may change without notice to improve the quality of the product. Figures in this manual are schematic and may not match your product exactly. Values stated on the machine labels or in the documentation accompanying it are obtained in laboratory in accordance with the relevant standards. -
Page 6: Warnings
Service for repair. supply and water drainage systems are appropriate before calling the • Check water hoses for wear. Do not use Authorised service. If they are not, call a old/used water inlet hoses. These may qualified plumber to have any necessary cause stains on your laundry. -
Page 7: If There Are Children In Your House
If there are children in your your socket, then the plug should be cut off and an appropriate plug fitted. house... Destroy the old plug, which is cut off as a • Electrical appliances may be dangerous plug with a bare cord could cause a shock for the children. Keep children away hazard if inserted into a socket elsewhere in from the machine when it is operating. - Page 8 ‘L’ or coloured red. With the alternative plugs a 13A fuse must be fitted either in the plug or adaptor or in the main fuse box. If in doubt contact a qualified electrician. 8 - EN...
-
Page 9: Installation
Appropriate installation location Install the appliance in environments which have no risk of freezing, in a stable and level position. The floor must be capable of carrying the load on it! If the washing machine and a drier... -
Page 10: Connecting To The Water Supply
Connecting to the drain The water discharge hose can be attached to the edge of a washbasin or waste water system. The drain hose should be firmly fitted into the drain as to not loosen in its housing. • In order to prevent water leakage that Important: may occur at the connection points, • The end of the drain hose can be... -
Page 11: Electrical Connection
The Packaging materials of your machine are end of the hose must be able to take in manufactured from recyclable materials. air. The hose should be pushed into the drainage for more than 15 cm. If it is too Disposing of the old machine long you may have it shortened. -
Page 12: Initial Preparations For Washing
• Do not wash colours and whites together. New, dark coloured cottons Bleach can be Do not use Dry-cleanable Do not may release a lot of dye. Wash them used bleach dry-clean separately. • Tough stains must be treated properly before washing. If you are not sure, check with a dry cleaner. -
Page 13: Loading Door
Bathrobe 1200 the washing Programme. Napkin Never open the detergent dispenser drawer Duvet cover while the washing Programme is running! When using a Programme without pre- Bed Sheet wash, no detergent should be put into the Pillowcase pre-wash compartment (Compartment no. Tablecloth Towel A Programme without pre-wash should be selected if a detergent bag or a dispensing Evening gown ball is going to be used. You can place the Underclothing detergent bag or the dispensing ball directly Men’s overalls... - Page 14 Liquid detergent When using liquid or gel washing detergents, please note the following: • The liquid detergent may leave stains on your laundry if time delay feature is selected. • Do not use liquid detergent if you want to wash using the time delay feature. • Do not use liquid detergent for the main wash in a cycle with pre-wash.
-
Page 15: Selecting A Program And Operating Your Machine
Selecting a Program and Operating Your Machine Control panel 5 - On/Off Button 1 - Spin Speed Adjustment Button Display 6 - Time Delaying Button (+/-) 3 - Temperature Adjustment Button 7 - Auxiliary Function Buttons 4 - Program Selection Knob 8 - Start/Pause/Cancel Button Display symbols - Spin Symbol - Spin Speed Indicator c – Water cut-off symbol (According to... -
Page 16: Turning The Machine On
• Dark Care (such as shirts, blouses, synthetic/cotton Use this programme to wash your dark blended garments, etc.). For curtains and coloured laundry, or the coloured laundry lace, the “Synthetic 40” program with pre- that you do not want them get faded. This wash and anti-creasing functions selected 16 - EN... -
Page 17: Special Programs
To change the temperature, press the You can use “Refreshing” program to temperature button. Temperature decreases remove odors from laundry that are used in 10° increments. only for once and do not have any spots or Cold selection is shown with “-” symbol. dirt on them. • Eco Clean You can use this program, which is more sensitive to environment and natural resources, to wash lightly soiled and unspotted cotton laundry (max 3.5 kg) -
Page 18: Spin Speed Selection
Rinse hold is shown with “ ” and no spin is shown with “ ” symbols. If you are not going to unload your clothes immediately after the cycle, you may use rinse hold function in order to prevent your clothes become wrinkled when there is no water in the machine. -
Page 19: Program And Consumption Table
• • : Selectable * : Automatically selected, not cancellable. ** : Energy Label programme (EN 60456) *** If maximum spin speed of your machine is lower, selection may be made until maximum spin speed. - : See program description for maximum load. The auxiliary functions in the table vary according to the model of your machine. Water and power consumption and program duration differ from the table subject to... -
Page 20: Auxiliary Functions
If an auxiliary function that should not be water and program completes. selected together with a previously selected If you want to spin your laundry that you left function is chosen, the first selected function in water: will be cancelled and the last auxiliary - Adjust the spin speed. -
Page 21: Starting The Program
Changing the delay time end of the program, all symbols will If you want to change the time during the remain lit up. The symbol that lights up countdown: at the far right of the series of symbols 1. Press “Start/Pause/Cancel” button. “... -
Page 22: Changing The Selections After The Program Has Started
Changing the selections after the In this case, no change can be made in the running program. program has started Your machine can be turned on and The selected spin speed and program off with On/Off button while the child- temperature fade out. An empty frame proof lock is activated. In this case, your appears. -
Page 23: End Of Program
The program continues and only drains the water. End of program When the program is finished, the symbols of the relevant steps will remain lit up and the auxiliary function, spin and temperature data selected at the start-up of the program will remain selected. “End” will appear on the display. -
Page 24: Quick Instructions For Daily Use
– adjust the spin speed, which is lit up. – set the time delay, If you wish to spin when the machine is in 4. Close the loading door. this mode: 5. Press “Start/Pause/Cancel” button. 1. Adjust the spin speed. The display shows the time remaining for 2. Press “Start/Pause/Cancel” button. The... - Page 25 3. Turn the water tap off. 4. Remove any folds in the rubber seal on the loading door and check for debris. 5. Leave the loading door and detergent drawer open to dry. 25 - EN...
-
Page 26: Cleaning And Care
These will damage the painted and plastic parts. Inlet water filters There is a filter at the end of each water If more than a normal amount of water intake valve at the back side of the machine and softener mixture starts to gather in... -
Page 27: Draining Any Remaining Water And Cleaning The Pump Filter
If your product is not supplied with an emergency drain hose, do the following as shown in the figure below: If it is composed of one piece, hold it from both sides and open it by pulling out. You can remove the filter cover by slightly pushing the kick plate downwards with a screwdriver, through • Place a large container in front of the... - Page 28 • Loosen pump filter (anticlockwise) until water starts to flow out of it. Direct the flowing water into the container you have placed in front of the filter. You can use a piece of cloth to absorb any spilled water. • When there is no water left, turn the pump filter until it is completely loose and remove it.
-
Page 29: Solution Suggestions For Problems
This is from the quality It is not harmful to your machine. control process and is normal. There is water coming from the bottom of the machine. - Make sure that the seals of the water inlet hoses are securely fitted. There might be problems with hoses or the - Tightly attach the drain hose to the tap. - Page 30 Washing time takes longer than the time specified in the manual - The machine will wait until there is sufficient amount of water, which will lengthen the washing time to avoid poor washing results due to insufficient water.
- Page 31 - The machine will wait until there is sufficient amount of water to avoid poor washing results due In the case of a paused countdown while to lack of water. Then the timer will start to count taking in water: down. - Timer will not countdown until the...
- Page 32 - Washing performance is poor: Oily stains appear on laundry. - Washing performance is poor: Bad odour - Such odours and bacteria layers are formed on the drum as a result of continuous washing at lower temperatures and/or in short Programmes. - Oily accumulations on the drum may - Leave the detergent dispenser drawer as well have stuck to the laundry. as the loading door of the machine ajar after each - Oily accumulations on the drum may washing.
- Page 33 Clothes do not smell like the softener. - If the water hardness is higher, using insufficient amount of detergent can cause the laundry to become stiff in time. Use appropriate amount of detergent according to the water hardness. - Insufficient amount of detergent used.
- Page 34 Machine does work. Nothing is displayed on the screen. The plug might not be plugged in the mains outlet. Check the plug. Fuse may have blown. Check the fuse. Electricity may be cut off. Check the supply power. The “On/Off” button might have not been Press this button. pressed. The machine did not start after the program was selected and the «Start/Pause/Cancel» button was pressed. The front door may be ajar.
-
Page 35: Guarantee
Guarantee Your new Beko product is guaranteed is recommended for all Washing against the cost of breakdown repairs for Machines, Dishwashers and Electric twelve months from the date of the original Cookers purchase. • Gas Cookers must only be installed by a CORGI (or BORD GAIS) registered What is covered? Gas Installer. • Repairs necessary as a result of faulty • The guarantee is given only within the materials, defective components or boundaries of the United Kingdom and manufacturing defect. -
Page 36: Service
Service Please keep your purchase receipt or other Should you experience any difficulty in proof of purchase in a safe place; you will obtaining service please contact the Beko need to have it should the product require Customer Help-Line. attention under guarantee. Tel: 0845 600 4911 e-mail:service@beko.co.uk You should also complete the details below; it will help us assist you when requesting service. (The model number is printed on the Instruction Booklet and the serial number is printed on the Rating Label... - Page 37 37 - EN...
- Page 38 38 - EN...
- Page 39 39 - EN...
