- Page 1 EN User Manual | Dishwasher FSX52927Z aeg.com\register...
-
Page 2: Table Of Contents
Welcome to AEG! Thank you for choosing our appliance. Get usage advice, brochures, trouble shooter, service and repair information: www.aeg.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................4 3. INSTALLATION....................6 4. PRODUCT DESCRIPTION................7 5. - Page 3 • Children of less than 3 years of age should be kept away from the appliance unless continuously supervised. • Children should be supervised to ensure that they do not play with the appliance. • Keep detergents away from children. •...
-
Page 4: Safety Instructions
• If the appliance has ventilation openings in the base, they must not be covered e.g. by a carpet. • The appliance is to be connected to the water mains using the new supplied hose-sets. Old hose sets must not be reused. - Page 5 discontinued: motor, circulation and drain pump, heaters and heating elements, including heat pumps, piping and related equipment including hoses, valves, filters and aquastops, structural and interior parts related to door assemblies, printed circuit boards, electronic displays, pressure switches, thermostats and sensors, software and firmware including reset software.
-
Page 6: Installation
3.1 Building in www.youtube.com/electrolux www.youtube.com/aeg How to install your AEG/Electrolux 60 cm Sliding Door Dishwasher 3.2 Safety caps If the furniture panel is not installed, open the appliance door carefully to avoid the risk of injury. -
Page 7: Product Description
4. PRODUCT DESCRIPTION Ceiling spray arm Lower basket Upper spray arm Upper basket Lower spray arm Cutlery drawer Filters Rating plate The graphic is a general overview. For Salt container more details, refer to other chapters or documents provided with the appliance. Air vent Rinse aid dispenser Detergent dispenser... -
Page 8: Control Panel
5. CONTROL PANEL On/Off button / Reset button ExtraPower option button Delay start button AUTO Sense program button Indicators MY TIME program selection bar 5.1 Indicators Indicator Description ECO programme indicator. It indicates the most environmentally friendly programme selec‐ tion for a normally soiled load. Refer to "Programme selection". Rinse aid indicator. - Page 9 B. 90min is a programme suitable for the temperature and quantity of water as well dishwashing and drying normally soiled as the wash duration. items. 6.3 Options C. ECO is the longest programme offering the most efficient use of energy and water You can adjust the programme selection to consumption for crockery and cutlery with your needs by activating options.
-
Page 10: Basic Settings
Programme Dishwasher Degree of soil Programme phases Options load Machine Care For cleaning the appliance interior. Not applicable • Cleaning 70 °C Refer to "Care and Cleaning". • Intermediate rinse • Final rinse • AirDry Automatic door opening during the drying phase. Refer to "Basic settings". Consumption values Water (l) Energy (kWh) - Page 11 Number Settings Values Description 1) Auto door open On (default) Activate or deactivate the AirDry. Key tones On (default) Activate or deactivate the sound of the buttons when pressed. For more details, refer to the information provided in this chapter. You can change the basic settings in setting mode.
- Page 12 4. Press OK to confirm the setting. negative effect on the washing results and on • The new setting is saved. the appliance. • The appliance returns to the setting The higher the content of these minerals, the selection. harder your water is. Water hardness is 5.
- Page 13 7.3 The rinse aid empty notification Water softener level Amount of water (l) The rinse aid helps to dry the dishes without streaks and stains. It is automatically released during the final rinse. When the rinse aid chamber is empty, the rinse aid indicator turns on.
-
Page 14: Before First Use
CAUTION! Do not try to close the appliance door When AirDry opens the door, Beam-on- within 2 minutes after automatic opening. Floor might not be completely visible. To This can cause damage to the appliance. see if the programme is complete, look at the control panel. -
Page 15: Daily Use
8.2 How to fill the rinse aid CAUTION! dispenser Only use rinse aid designed specifically for dishwashers. 1. Press the release button (D) to open the lid (C). 2. Pour the rinse aid in the dispenser (A) until the liquid reaches the fill level 'max'. 3. - Page 16 9.6 How to cancel the delay start 3. Close the appliance door to start the while the countdown operates programme. 9.3 How to activate ExtraPower Press and hold for about 3 seconds. The appliance returns to the programme 1. Select a programme using MY TIME selection bar.
-
Page 17: Hints And Tips
9.10 End of the programme All buttons are inactive except for the on/off button. When the programme is complete, the Auto Off function switches the appliance off automatically. 10. HINTS AND TIPS 10.1 General – Follow the instructions in the chapter "Care and cleaning". -
Page 18: Care And Cleaning
1. Set the highest level of the water • Do not wash the following materials in the softener. dishwasher: wood, horn, pewter, copper, 2. Make sure that the salt and rinse aid aluminium, delicate ornamented porcelain containers are full. and unprotected carbon steel. This can 3. - Page 19 2. Remove any foreign objects manually. How to start the Machine Care 3. Reassemble the filters as instructed in programme this chapter. 11.4 External cleaning Before starting the Machine Care • Clean the appliance with a moist soft programme, clean the filters and spray cloth.
- Page 20 4. Wash the filters. CAUTION! An incorrect position of the filters can cause bad washing results and damage to the appliance. 11.6 Cleaning the lower spray arm We recommend to clean the lower spray arm regularly to prevent soil from clogging the holes.
- Page 21 1. Release the stoppers on the sides of the sliding rails of the cutlery drawer and pull 3. To install the spray arm back, press it the drawer out. downwards. 11.7 Cleaning the upper spray arm 2. Move the upper basket to the lowest level to reach the spray arm more easily.
-
Page 22: Troubleshooting
5. To install the spray arm (C) back, insert the mounting element (B) in the spray arm and fix it in the delivery tube (A) by turning it clockwise. Make sure that the mounting element locks into place. 6. Install the cutlery drawer on the sliding rails and block the stoppers. - Page 23 Problem and alarm code Possible cause and solution The appliance does not drain the • Make sure that the sink spigot is not clogged. water. • Make sure that the interior filter system is not clogged. • The lights related to MY TIME •...
- Page 24 Problem and alarm code Possible cause and solution The level of water inside the appli‐ • Switch the appliance off and on. ance is too high. • Make sure that the filters are clean. • The lights related to MY TIME •...
- Page 25 12.1 The dishwashing and drying results are not satisfactory Problem Possible cause and solution Poor washing results. • Refer to "Daily use", "Hints and tips" and the basket loading leaf‐ let. • Use more intensive washing programme. • Activate the ExtraPower option to improve the washing results of a selected programme.
-
Page 26: Technical Information
Problem Possible cause and solution Limescale deposits on the tableware, • The level of salt is low, check the refill indicator. on the tub and on the inside of the • The cap of the salt container is loose. door. •... -
Page 27: Environmental Concerns
13.2 Link to the product information manual and all other documents provided sheet - for the UK only with this appliance. For more detailed information about the The QR code on the energy label supplied energy label, visit www.theenergylabel.eu. with the appliance provides a web link to the product information sheet. - Page 28 156825610-A-442023...
