- Page 1 OWNER’S MANUAL Please read this manual carefully before operating your set and retain it for future reference. 55EA880T *MFL67653166* www.lg.com P/NO : MFL67653166 (1312-REV00)
-
Page 2: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS Always comply with the following precautions to avoid dangerous situations and ensure peak performance of your product. Read these instructions. Keep these instructions. WARNING/CAUTION Heed all warnings. Follow all instructions. RISK OF ELECTRIC SHOCK DO NOT OPEN Do not use this apparatus near water. - Page 3 IMPORTANT SAFETY INSTRUCTIONS Protect the power cord from being walked on or pinched CAUTION concerning the Power Cord particularly at plugs, convenience receptacles, and the point (Can differ by country) where they exit from the apparatus. It is recommended that appliances be placed upon a dedicated circuit;...
- Page 4 If you smell smoke or other odors coming from the TV, Do not attempt to modify this product in any way without unplug the power cord and contact an authorized service written authorization from LG Electronics. Unauthorized center. modification could void the user’s authority to operate this Keep the product away from direct sunlight.
- Page 5 IMPORTANT SAFETY INSTRUCTIONS Dot Defect The Plasma or LCD panel is a high technology product with resolution of two million to six million pixels. In a very few cases, you could see fine dots on the screen while you’re viewing the TV. Those dots are deactivated pixels and do not affect the performance and reliability of the TV.
-
Page 6: Viewing 3D Imaging
Cautions when using the 3D glasses Do not watch 3D contents when you feel fatigue from lack Be sure to use LG 3D glasses. Otherwise, you may not be of sleep, overwork or drinking. able to view 3D videos properly. -
Page 7: Licenses
In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available for download. LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping and handling) upon email request to opensource@lge.com. -
Page 8: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS IMPORTANT SAFETY INSTRUCTIONS MAGIC REMOTE CONTROL FUNCTIONS Viewing 3D Imaging Registering Magic Remote Control How to use Magic Remote Control Precautions to Take when Using the Magic LICENSES Remote Control OPEN SOURCE SOFTWARE NOTICE WATCHING TV Turning the TV on for the First time TABLE OF CONTENTS... -
Page 9: Installation Procedure
INSTALLATION PROCEDURE / ASSEMBLING AND PREPARING INSTALLATION PROCEdURE Open the package and make sure all the accessories are included. Connect an external device to the TV set. Make sure the network connection is available. You can use the TV network functions only when the network connection is made. ASSEMBLING ANd PREPARING Unpacking Check your product box for the following items. - Page 10 ASSEMBLING AND PREPARING Magic Remote Control, Owner’s Manual Cinema 3D Glasses Batteries (AA) The number of 3D glasses may (See p. 28) differ depending upon the model or country. Tag On Tag on Polishing cloth Video call camera Use this to remove dust from the (See p.
-
Page 11: Optional Extras
These devices only work with certain models. The model name or design may be changed manufacturer’s circumstances or policies. AN-MR400 AG-F*** AG-F***DP Magic Remote Cinema 3D Glasses Dual Play Glasses Tag On LG Audio Device Tag On AN-VC5** Video Call Camera... -
Page 12: Parts And Buttons
ASSEMBLING AND PREPARING Parts and Buttons Screen LG Logo Light Remote Control Sensor Smart Touch Button Button Description Turns the power on or off. -
Page 13: Using The Smart Touch Button
Using the Smart Touch Button To Turn the TV On - Gently press the smart touch button just below the LG logo light at the bottom of the TV. To Turn the TV Off - If the touch menu is not displayed on the screen, press the smart touch button for about two seconds. -
Page 14: Lifting And Moving The Tv
ASSEMBLING AND PREPARING Lifting and Moving the TV Setting up the TV When moving or lifting the TV, read the following to prevent the TV from being scratched or damaged and for safe transportation Tidying cables regardless of its type and size. After the wall mount-type product is installed, arrange CAUTION cables as illustrated below:... -
Page 15: Using Video Call Camera
ASSEMBLING AND PREPARING Using Video Call Camera Front Rear Microphones USB Cable Activity Indicator Lens Stand-Arm Stand-Bottom Stand Stand-Cable holder Product Handling Installation Instructions Do not let the camera get wet. Liquid getting into the Make sure you have enough space for connections when camera could cause a short circuit. -
Page 16: Preparing Video Call Camera
ASSEMBLING AND PREPARING Preparing Video Call Camera Insert the video call camera’s cable into the Stand-Cable holder. The camera should be connected to the CAM terminal as shown in the figure. Unfold the stand and put it on the top center of the TV set. Stand-Cable holder Video Call Camera NOTE... -
Page 17: Making Connections
MAKING CONNECTIONS MAKING CONNECTIONS You can connect various external devices to the TV. Supported external devices are: HD receivers, DVD players, VCRs, audio systems, USB storage devices, PC, gaming devices, and other external devices. For more information on external device’s connection, refer to the manual provided with each device. -
Page 18: Connecting To A Hd Receiver, Dvd Player Or Vcr
MAKING CONNECTIONS Connecting to a HD receiver, DVD Player or VCR Connect a HD receiver, DVD Player, or VCR to the TV and select an appropriate input mode. HDMI Connection HDMI is the best way to connect a device. Transmits digital video and audio signals from an external device to the TV. Connect the external device and the TV with the HDMI cable as shown in the following illustration. -
Page 19: Dvi To Hdmi Connection
MAKING CONNECTIONS DVI to HDMI Connection Transmits the digital video signal from an external device to the TV. Connect the external device and the TV with the DVI-HDMI cable as shown in the following illustration. To transmit an audio signal, connect an audio cable. NOTE When using the HDMI/DVI cable, Single link is only supported. -
Page 20: Connecting To A Mobile Phone
MAKING CONNECTIONS Connecting to a Mobile phone Mobile High-definition Link (MHL) is an interface for transmitting digital audio/visual signals from mobile phones to television sets. NOTE Connect the mobile phone to the HDMI / DVI IN 4 (MHL) port to view the phone screen on the TV. This only works with an MHL-enabled phone. -
Page 21: Component Connection
MAKING CONNECTIONS Component Connection Transmits analog video and audio signals from an external device to the TV. Connect the external device and the TV with a component cable as shown in the following illustration. NOTE If cables are installed incorrectly, it could cause the image to display in black and white or with distorted color. Check to ensure the cables are matched with the corresponding color connection. -
Page 22: Composite Connection
MAKING CONNECTIONS Composite Connection Transmits analog video and audio signals from an external device to the TV. Connect the external device and the TV with the composite cable as shown in the following illustration. NOTE If you have a mono VCR, connect the audio cable from the VCR to the AUDIO L/MONO jack of the TV. Check to ensure the cables are matched with the corresponding color connection. -
Page 23: Connecting A Pc
MAKING CONNECTIONS Connecting a PC NOTE It is recommended to use an HDMI connection for the best image quality. Depending upon the graphics card, DOS mode video may not work if a HDMI to DVI Cable is in use. In PC mode, there may be noise associated with the resolution, vertical pattern, contrast or brightness. If noise is present, change the PC output to another resolution, change the refresh rate to another rate or adjust the brightness and contrast on the PICTURE menu until the picture is clear. - Page 24 MAKING CONNECTIONS Method B: dVI to HdMI Connection Choose any HDMI input port to connect. It does not matter which port you use. (*Not Provided) YELLOW (*Not Provided) AUDIO OUT DVI OUT...
-
Page 25: Connecting To An Audio System
MAKING CONNECTIONS Connecting to an Audio System You can use an optional external audio system instead of the built-in speaker. Digital Optical Audio Connection Transmits a digital audio signal from the TV to an external device. Connect the external device and the TV with the optical audio cable as shown in the following illustration. -
Page 26: Connecting Headphones
MAKING CONNECTIONS Connecting Headphones Listening to sound with headphones NOTE AUDIO menu options are disabled when headphones are connected. When changing AV MODE with a headphone connected, the change is applied to video but not to audio. Optical Digital Audio Out is not available when connecting a headphone. Headphone impedance: 16 Ω... -
Page 27: Connecting A Usb Device
MAKING CONNECTIONS Connecting a USB Device Connect a USB storage device such as USB flash memory, external hard drive, or a USB memory card reader to the TV and access the SmartShare menu to use various multimedia files. NOTE To use Time Machine function, make sure your USB drive is connected to the USB IN 1 (USB 3.0 IN) Time Machine Ready port. Some USB Hubs may not work. -
Page 28: Magic Remote Control Functions
MAGIC REMOTE CONTROL FUNCTIONS MAGIC REMOTE CONTROL FUNCTIONS Magic remote control battery is low. Change the battery When the message . is displayed, replace the battery. To install batteries, open the battery cover, replace batteries (1.5 V AA) matching ends to the label inside the compartment, and close the battery cover. Failure to match the correct polarities of the battery may cause the battery to burst or leak, resulting in fire, personal injury, or ambient pollution. -
Page 29: Registering Magic Remote Control
MAGIC REMOTE CONTROL FUNCTIONS Registering Magic Remote Control The Magic Remote Control operates by pairing with your TV. Register the remote as follows. How to register the Magic Remote Control To register automatically, turn the TV on and press Wheel (OK). When registration is completed, the completion message appears on the screen. -
Page 30: Watching Tv
WATCHING TV WATCHING TV NOTE Select Home when prompted. Store mode puts the TV in demo mode. If you select Store, the any customized settings will switch back to the default settings of Store in 5 minutes. Turning the TV on for the First time When the basic settings are complete, When you turn the TV on for the first time, the Initial setting press the... -
Page 31: Using The User Guide
An index of key words present in the User Guide. Provides the detailed information on the functions of LG Smart TV when the Internet is connected. (It may not be available depending upon the country/ language.) -
Page 32: Specifications
0 - 40 °C condition Operating Humidity Less than 80 % Storage Temperature -20 - 60 °C Storage Humidity Less than 85 % 55EA880T MODELS (55EA880T-DC) Dimensions 1230 x 715 x 25.4 (mm) (W x H x D) Weight 12.4 Kg 2.65 A / 265 W... - Page 33 The specifications shown above may be altered without prior notice to improve quality. This product follows Skype Encoding Camera Specification (SECS) 2.1. CAUTION Video calls through an LG TV cannot be made using the following devices: » ASUS Skype Video Phone Touch SV1TS » ASUS Skype Videophone Touch SV1TW »...
- Page 34 SPECIFICATIONS HDMI (DTV) supported mode Component port connecting information Component ports on the Horizontal Frequency Vertical Frequency Resolution (kHz) (Hz) 640 x 480 31.469 / 31.5 59.94 / 60 Video output ports 720 x 480 31.469 / 31.5 59.94 / 60 on DVD player 31.25 720 x 576...
- Page 35 SPECIFICATIONS 3D supported mode Video, which is input as below media contents is switched into the 3D screen automatically. The method for 3D digital broadcast may differ Depending upon the signal environment. If video is not switched automatically into 3D, manually convert the settings to view 3D images. 3D supported mode automatically Horizontal Frequency Vertical Frequency...
- Page 36 SPECIFICATIONS 3D supported mode manually Signal Vertical Input Playable 3D video format Horizontal Frequency Resolution Frequency (kHz) (Hz) HD / SD ATV(CVBS) HD / SD 2D to 3D, S/S (Half), T&B Component 1024 x 768 48.36 1360 x 768 47.71 HDMI-PC 2D to 3D, S/S (Half), T&B, C/B, 1920 x 1080...
-
Page 37: Maintenance
Do not spray liquid onto the surface. If water enters the TV, it may result in fire, electric shock, or malfunction. Power cord Remove the accumulated dust or dirt on the power cord regularly. ExTERNAL CONTROL dEVICE SETUP www.lg.com To obtain the external control device setup information, please visit... -
Page 38: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING Problem Solution Check the remote control sensor on the product and try again. Cannot control the TV with the remote Check if there is any obstacle between the product and the remote control. control. Check if the batteries are still working and properly installed ( Check if the product is turned on. - Page 40 The model and serial numbers of the TV are located on the back and one side of the TV. Record them below should you ever need service. MODEL SERIAL...
