Colour Television
OWNER'S MANUAL
Please read this manual carefully before operating your set.
Retain it for future reference.
Record model number, serial number and manufactured
of the set.
See the label attached on the back cover and quote this
information to your dealer when you require service.
SALES MODEL:
21FD1RG / 21FB5RG/21FC1RG/21FC2RG
Model number :
21FD1RG-TH / 21FB5RG-TH/21FC1RG-TH
21FC2RG-TH
Serial number :
Manufactured :
For informations of Guarantee and Service Center / Parts,
please refer to your Warranty Card.

Advertisement

Table of Contents
loading

Related Manuals for LG 21FD1RG

Summary of Contents for LG 21FD1RG

  • Page 1 Record model number, serial number and manufactured of the set. See the label attached on the back cover and quote this information to your dealer when you require service. SALES MODEL: 21FD1RG / 21FB5RG/21FC1RG/21FC2RG Model number : 21FD1RG-TH / 21FB5RG-TH/21FC1RG-TH 21FC2RG-TH Serial number :...

  • Page 2: Table Of Contents

    Contents Installation Location and function of controls Remote control handset Battery installation / Front panel Basic operation On and off / Programme selection Volume adjustment / Quick view Mute function On screen language selection (option) On screen menus Menu selection Setting up TV stations Auto programme tuning Manual programme tuning...

  • Page 3: Installation

    Installation Power This set operates on an AC mains supply, the voltage is as indicat- ed on the label on the back cover. Never apply DC power to the set. In the event of thunderstorms or powercuts, please pull out the aer- ial and mains plugs.

  • Page 4: Location And Function Of Controls

    Location and function of controls All the functions can be controlled with the remote control handset. Some functions can also be adjusted with the buttons on the front panel of the set. Remote control handset Before you use the remote control handset, please install the bat- teries.
  • Page 5 Location and function of controls 10. MUTE switches the sound on or off. 11. TV/AV selects TV or AV mode. switches the set on from standby. 12. I/II/ (option) selects the language during dual language broadcast. (option) selects the sound output. 13.
  • Page 6 Location and function of controls Front panel 21FD1/4 series 21FX6 series MENU 21FX4 series 15/21FC2 series 1 2 3 4 @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ e ? @ @ h ? @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @ e ? @ @ @ @ @ @ @ @ ? e @ @ @ @ @ @ @ @...
  • Page 7 Location and function of controls Front panel 1. MAIN POWER (ON/OFF) 21FC1 series switches the set on or off. 2. POWER/STANDBY INDICATOR MENU illuminates brightly when the set is in standby mode. dims when the set is switched on. 17/21FA3 series 3.

  • Page 8: Basic Operation

    Basic operation On and off 1. Press the main power button to switch the set on. 2. If the set is in standby mode, press the POWER, , TV/AV or NUMBER buttons on the remote control handset to switch it on fully.

  • Page 9: On Screen Menus

    On screen menus The dialogue between you and your set takes place on screen with an operator menu. The buttons required for the operating steps are also displayed. Menu selection 1. Press the MENU button and then button to display each menu. 2.

  • Page 10: Setting Up Tv Stations

    Setting up TV stations Up to 100 TV stations can be stored by programme numbers (0 to 99). AutoOprog. Once you have preset the stations, you will be able to use the Manual or NUMBER buttons to scan the stations you programmed. Prog.Oedit Favourite Stations can be tuned using automatic or manual modes.

  • Page 11: Manual Programme Tuning

    Setting up TV stations Auto programme scan AutoOprog. To automatically scan the pictures of stored programmes, press Manual Prog.Oedit ( ) or ( ) button for about 3 seconds. The picture of stored Favourite programmes appears on the screen one by one. To stop auto programme scanning, press any button except VCR buttons.
  • Page 12 Setting up TV stations Assigning a station name AutoOprog. 1. Repeat the ‘Manual programme tuning’ steps 1 to 3. Manual Prog.Oedit 2. Press the button to select Name Favourite 3. Press the button on the Name pull-down menu. 4. Press the button.

  • Page 13: Programme Edit

    Setting up TV stations Programme edit AutoOprog. Manual Prog.Oedit This function enables you to delete or skip the stored programmes. Favourite Also you can move some stations to other programme numbers or insert a blank station data into the selected programme number. 1.

  • Page 14: Favourite Programme

    Setting up TV stations Favourite programme AutoOprog. Manual Prog.Oedit Favourite This function lets you select your favourite programmes directly. 1. Press the MENU button to select the Station menu. 2. Press the button and then button to select Favourite ) O} {OOKOMENU 3.

  • Page 15: Calling The Programme Table

    Setting up TV stations Calling the programme table You can check the programmes stored in the memory by displaying the programme table. Displaying programme table Press the LIST button to display the Programme table menu. The programme table appears on the screen. One programme table contains ten programmes as below.

  • Page 16: Picture Adjustment

    Picture adjustment Note: Picture menu options are not available for RGB input source. TurboOPic. PSM (Picture Status Memory) Contrast 1. Press the MENU button and then button to select the Brightness Colour Picture menu. Sharpness 2. Press the button to select 3.

  • Page 17: Turbo Picture Selection (Option)

    Picture adjustment Eye (option) Eye is an optional function. Only a set with eye option can perform this function. In some models, the set will automatically adjust the picture accord- ing to the surrounding conditions. This will enable you to enjoy the most suitable picture according to the surroundings.

  • Page 18: Sound Adjustment (Option)

    Sound adjustment (option) Sound adjustment is an optional function only a set with sound adjustment can perform this function. TurboOSnd. SSM (Sound Status Memory) Balance Woofer Treble You can select your preferred sound setting; Flat, Music, Movie or Bass X-WAVE Speech and you can also adjust the sound frequency of equalizer.

  • Page 19: X-Wave (Wireless Sound) (Option)

    Sound adjustment (option) X-WAVE (Wireless Sound) (option) TurboOSnd. You can also listen to the sound through the FM receiver. Balance Woofer 1. Press the MENU button and then button to select the Treble Sound menu. Bass X-WAVE 2. Press the button and then button to select X-WA VE...

  • Page 20: Sound Output Selection (Option)

    Sound adjustment (option) Sound output selection (option) In AV mode, you can select output sound for the left and right loud- speakers. Repeatedly press the I/II/ button to select the sound output. Audio signal from audio L input is sent to left loud-speaker and audio signal from audio R input is sent to right loud- speaker.

  • Page 21: Time Setting

    Time Setting Setting the clock Clock Offotime 1. Press the MENU button and then button to select the Onotime Time menu. Autoooff 2. Press the button to select Clock 3. Press the button and then button to adjust the hour. Clock Clock -i-o:o-i-...

  • Page 22: Other Functions

    Other functions TV and AV modes Language Input Blue oback Inputs can be set for TV or AV mode. AV mode is used when a video Childolock cassette recorder (VCR), or other equipment is connected to the set. Note : When a VCR is connected via the aerial socket the set is used in TV mode.
  • Page 23 Other functions Child lock Language Input Blue oback The TV can be set so that the remote control handset is needed to Childolock control it. This feature can be used to prevent unauthorized view- ing. 1. Press the MENU button and then button to select the ) O} {OOKOMENU...
  • Page 24 Other functions Games (option) Language Input Blue oback Game is an optional function, only a set with game can perform this Childolock function by using the remote control handset. 1. Press the MENU button and then button to select the Special menu.

  • Page 25: Connection Of External Equipment

    Connection of external equipment You can connect additional equipment, such as VCRs, camcorders etc. to your set. Here shown may be somewhat different from your set. ANT IN COMPONENT DVD INPUT (480i) VIDEO (L/MONO) AUDIO (R) Aerial socket 1. Connect the RF out socket of the VCR to the aerial socket on the back of the set.

  • Page 26: S-Video/Audio In Sockets (S-Av) (Option)

    Connection of external equipment S-video / Audio in sockets (S-AV) (option) When connecting the S-video socket of the VCR to the S-VIDEO socket of the set, the picture quality will be further improved. ANT IN 75Ω VIDEO (L) - AUDIO - (R) 1.

  • Page 27: Troubleshooting Check List

    Troubleshooting check list Symptoms No picture, no sound Sound OK, poor picture Picture OK, poor sound Picture blurred Lines or streaks in picture Poor reception on some channels No colour Poor colour Remote control does not work Check these items and try to adjust these The mains plug-(plugged in and switched on)
