Toshiba Satellite M505-S4972 Specifications

Satellite M505 Detailed Product Specification
Model Name M505-S4972
:
C1 2
Operating System
 Genuine Windows
®
7 Home Premium 32-bit
3
Processor and Graphics
 Intel
® ®
Pentium processor T4300
2.1GHz, 1MB L2 Cache, 800MHz FSB
o
 Mobile Intel
®
GL40 Express Chipset
 Intel
®
Graphics Media Accelerator 4500M with 32MB-1294MB
dynamically allocated shared graphics memory
5
Memory
 Configured with 3GB DDR2 800MHz (max 4GB)
6
Storage Drive
 250GB (5400 RPM) Serial ATA hard disk drive
Fixed Optical Disk Drive
 DVD SuperMulti drive with Labelflash
o Maximum speed and compatibility: CD-ROM (24x), CD-R (24x),
CD-RW (24x), DVD-ROM (8x), DVD-R (Single Layer, (8x)),
DVD-R (Double Layer, (6x)), DVD-RW (6x), DVD+R (Single
Layer, (8x)), DVD+R (Double Layer, (6x)), DVD+RW (8x), DVD-
RAM (5x)
®
o Uses Labelflash media to burn high quality labels directly to disc
8
Display
 14.0" diagonal widescreen TruBrite
native resolution (HD)
o Native support for 720p content
o LED backlight
Sound
 Built-in stereo speakers
Input Devices
 86 key US keyboard (black)
 TouchPad™ pointing device with multi-touch control
 TouchPad™ Enable/Disable button
 Media Control Buttons:
o eco utility button (Energy-saving mode)
o Mute
o Media
o CD/DVD control buttons
o Volume up, volume down
Communications
 Webcam and microphone
 10/100 Ethernet
 Realtek ®
802.11b/g/n wireless LAN
 3G Wireless WAN powered by Gobi™ (HSPA/EvDO)
Expandability
 2 main memory slots. Both slots may be occupied.
 ExpressCard™ slot (ExpressCard/34 and ExpressCard/54)
 Memory Card Reader
Secure Digital, Secure Digital High Capacity, Memory Stick™,
o
Memory Stick PRO™, Multi Media Card, xD Picture Card
[shared slot]
Ports
 Video
RGB (monitor) output port
o
 Audio
S/P DIF output port (shared with headphone port)
o
Microphone input port
o
Headphone output port
o
 Data
3 USB v2.0 ports
o
o 2 x USB v2.0 ports
Part Number: PSMK2U-00F007
4
7
®
supporting 11 formats
®
TFT LCD display at 1366x768
9
10
© Copyright 2009 Toshiba America Information Systems Inc. All Rights reserved.
TAIS shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
This product specification is variable and subject to change prior to product launch.
1
RJ-45 LAN port
o
 Security
Slot for Security Lock
o
Physical Description
 Fusion™ Finish with Sonic Pattern in Black
 Dimensions (W x D x H ): 13.5" x 9.14" x 1.42"/1.55"
 Weight: Starting at 5.18 lbs., depending upon configuration
13
Battery
 4800 mAh (6 cell) Lithium Ion battery pack
 Battery Life (measured by MobileMark™ 2007)
Included 6 cell battery: 4 hours
o
Power Supply
 75W (19V x 3.95 A) Auto-sensing ,100-240V/50-60Hz AC Adapter
 Dimensions (W x D x H): 5.0" x 2.0" x 1.2"
 Weight: starting at .69 lbs.
C1
Software
 Toshiba Software and Utilities
Electronic User's Guide
o
Bluetooth Stack for Windows by Toshiba
o
TOSHIBA Recovery Media Creator
o
TOSHIBA ConfigFree
o
TOSHIBA Disc Creator
o
TOSHIBA DVD Player
o
TOSHIBA Power-saving eco utility
o
TOSHIBA Hard Drive Impact Sensor (3D sensor)
o
TOSHIBA Face Recognition
o
TOSHIBA PC Health Monitor
o
Hard Disc Drive (HDD) Recovery
o
 Third-party Software
Microsoft
o
Microsoft
o
Internet Explorer 8
o
Adobe
o
Google™ Toolbar
o
Google™ Picasa™
o
Dolby
o
Corel
o
®
Sun
o
WildTangent
o
 Trial Software
Norton Internet Security™ 2009, 30-day trial
o
Microsoft
o
 Special Offers
Toshiba Online Backup
o
Skype
o
Intuit
o
Environmental Specifications
 This product is RoHS
 Energy Star 5.0 Qualified
 EPEAT™ Gold Compliant
17
Temperature
Relative Humidity
(non-condensing)
Thermal Gradient
Altitude
(relative to sea level)
Shock
Vibration
Satellite M505-S4972
UPC: 883974308804
o 1 x eSATA/USB combo port with USB Sleep and
11
Charge
15
®
®
Windows Media Player
®
Works 9
® ®
Acrobat Reader
® ®
Sound Room
® ®
DVD MovieFactory for TOSHIBA
Java™ 2 Runtime Environment
®
Orb™ Game Console
®
Office Home and Student 2007 Edition, 60-day trial
®
® ®
Quickbooks Financial Center
16
compatible
Operating
5° to 35° C
20% to 80%
15° C per hour (max)
0 to 3,000 meters
10G
0.5G
12
14
Non-operating
-20° to 60° C
10% to 90%
20° C per hour (max)
0 to 10,000 meters
60G
1.0G
