Canon CN-E30-105mm Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
ENGLISH
The English version is the operation manual for counties other than Japan.
Product Configuration .......................................6
Names of Parts .................................................7
F.B. (Back Focus) Adjustment ...........................8
Available Accessories ..................................... 10
Dimensions of Parts ........................................ 12
Specifications .................................................. 13
Appendix
External view ................................. apx. 2

Advertisement

loading

Related Manuals for Canon CN-E30-105mm

Summary of Contents for Canon CN-E30-105mm

  • Page 1: Table Of Contents

    ENGLISH GENERAL SAFETY INFORMATION ..4 Product Configuration ........6 Names of Parts ..........7 F.B. (Back Focus) Adjustment ......8 Available Accessories ........10 Dimensions of Parts ........12 Specifications ..........13 Appendix External view ......... apx. 2 The English version is the operation manual for counties other than Japan.
  • Page 2 FCC REGULATIONS This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
  • Page 3 Your cooperation in the correct disposal of this product will contribute to the effective usage of natural resources and will avoid incurring administrative sanctions according to art. 50 and following of Italian legislative decree 22/97. For more information regarding return and recycling of WEEE products, please visit www.canon-europe.com/environment. (EEA: Norway, Iceland and Liechtenstein)

  • Page 4: General Safety Information

    This indicates a potentially hazardous manual, contact Canon’s representative or situation which, if not heeded, may result in the dealer who originally supplied the lens. death or serious injury to you or others. Be sure to heed all warning notices to ensure safe operation at all times.
  • Page 5 STORAGE customer’s purpose. 3. Canon shall make no guarantees about the CAUTION results obtained using this product. 4. The product specifications, configuration, 1. Always attach the lens cap (or hood...

  • Page 6: Product Configuration

    Product Configuration Two types of the CN-E30-105mm T2.8 L are available for the positive lock mount (S type) and the Canon EF mount (SP type). Figures in this manual are for the S type lens unless otherwise mentioned. Lens body ...........1 Lens cap .............1...

  • Page 7: Names Of Parts

    Names of Parts Focus drive gear Zoom drive gear Number of teeth: 133 Module: 0.8 metric module Number of teeth: 111 Iris drive gear P.C.D.: 106.4 mm Module: 0.8 metric module Angular rotation: 300° P.C.D.: 88.8 mm Number of teeth: 111 Angular rotation: 93.5°...

  • Page 8: F.b. (Back Focus) Adjustment

    F.B. (Back Focus) Adjustment F.B. (back focus) of this lens can be adjusted in the following procedures. Before starting, select an object with sharp contrast at a distance* that facilitates the adjustment work. Screws x 3 * Recommended object distance range: 6 to 12 ft. Remove three screws and remove the F.B.
  • Page 9 Turn the iris ring to set the iris to fully open (T2.8). Turn the zoom ring to set the lens to the telephoto end, then turn the focus ring to bring the object into focus. Turn the zoom ring to set the lens to the wide angle end, then turn the Use the index...

  • Page 10: Available Accessories

    Available accessories A variety of professional camera accessories are available using Φ15 mm and Φ19 mm rod adaptors. (When using a Φ19 rod, attach the supplied attachment holder to the lens holder.) Be sure to use the lens holder when mounting the lens on a CAUTION camera.
  • Page 11 Mount the S type (EF mount) lens to the camera by following CAUTION the steps below. Attach the lens to the camera tightly so that both mounting surfaces are in complete contact. Refer to the operation manual for the respective camera for the detailed information.

  • Page 12: Dimensions Of Parts

    Dimensions of parts Unit: mm S type (EF mount) SP type (PL mount) Spur gear specifications Focus drive gear Zoom drive gear Iris drive gear Number of teeth Module 0.8 metric module 0.8 metric module 0.8 metric module P.C.D. 106.4 mm 88.8 mm 88.8 mm Angular rotation...

  • Page 13: Specifications

    Specifications CN-E30-105mm T2.8 L S CN-E30-105mm T2.8 L SP Lens Mount Canon EF Focal Length 30 to 105 mm Maximum T-stop T2.8 (f = 30 to 105) Iris Blades 11 pieces Super 35mm Φ27.5 mm / Coverage Image Circle / H x V 24.0 x 13.5 mm...
  • Page 14 Reference Information This lens is a full manual lens for shooting movies. • This lens is developed primarily for movie production, and have a color balance typical for movies. This means that the color reproduction is warmer than that of EF lenses which are basically used to shoot still images.
