67 blower mounting kit

Advertisement

Quick Links

Note: When installing bearing,
apply #609 Loctite to bearing be-
fore pressing into collar.
Ref.
Part No.
No.
1
67-005-0152 Mounting Frame
2
67-005-0141 Mounting Pin
3
67-004-1161 Lower Mounting Pin
4
01-282-0600 PTO Assembly
5
67-005-0241 Belt Guard
6
67-005-2151 Pulley Shaft
7
67-005-0251 Bearing Mount
*
67-002-0051 Bearing Mount Assembly
(Incl. Ref. #6,7,13,17,38,39)
8
67-005-0131 Lower Support Arm
9
67-005-0121 Upper Support Arm
10
67-004-1371 Upper Support Arm Brace
11
321-6
Capscrew - Hex Hd.
12
67-004-0401 Upper Support Hinge Rod
13
3253-3
Lock Washer
14
01-264-0350 Belt
15
01-260-0060 Sheave
16
01-260-0150 Sheave
17
3256-2
Flat Washer
18
01-159-0010 Presto Pin
19
01-650-0110 All Thread
MODEL NO. 44527
67 BLOWER MOUNTING KIT
for 200 SERIES GROUNDSMASTER
PARTS LIST
No.
Description
Used
1
2
1
1
1
1
1
1
1
1
1
2
1
3
1
1
1
5
4
1
The TORO Company - 1994
©
All Righ ts Re se rve d
FORM NO. 01-502-1300.1
Ref.
Part No.
No.
20
3217-9
Hex Nut
21
3253-7
Lock Washer
22
3256-6
Flat Washer
23
82-004-1171 Key
24
3296-39
Lock Nut
25
325-6
Capscrew - Hex Hd.
26
01-506-0040 Decal - Danger
27
01-260-0240 Bushing
28
01-163-0030 Socket Head Set Screw
29
323-13
Capscrew - Hex Hd.
30
3217-7
Hex Nut
31
3256-4
Flat Washer
32
3272-11
Cotter Pin
33
3217-5
Hex Nut
34
01-506-0130 Decal - Danger
35
323-8
Capscrew - Hex Hd.
36
3253-5
Lock Washer
37
01-506-0550 Decal - Grease
38
01-100-0340 Bearing (see note)
39
321-4
Capscrew - Hex Hd.
PARTS LIST &
ASSEMBLY
INSTRUCTIONS
®
(Prior '89)
67-002
No.
Description
Used
4
2
1
3
1
1
1
2
1
1
6
3
2
2
1
2
2
1
1
1

Advertisement

loading

Summary of Contents for Toro 44527

  • Page 1 3253-5 Lock Washer 01-260-0150 Sheave 01-506-0550 Decal - Grease 3256-2 Flat Washer 01-100-0340 Bearing (see note) 01-159-0010 Presto Pin 321-4 Capscrew - Hex Hd. 01-650-0110 All Thread The TORO Company - 1994 © All Righ ts Re se rve d...
  • Page 2 ASSEMBLY INSTRUCTIONS 67 BLOWER MOUNTING KIT 1. Mount the bearing mount assembly (A) to the belt has a 3/16" deflection with 5 lbs. of force when rear housing as shown in Fig. 1. Fasten the bottom properly adjusted. Tighten both 1/2" nuts on the bolt with a 1/2"...
