Summary of Contents for Bosch DKE615Q
- Page 1 Extractor hood DKE615Q [en] Instructions for installation and use...
- Page 3 WARNINGS - COMPONENTS WARNINGS This appliance has been designed for use as either an EXTRACTION (ducting to the outside) or RECIRCULATION (filtering) hood. The measurements contained on the drawings in this booklet refer to two models of cooker hood. Therefore, it is essential that you refer to the cor- rect drawing when taking measurements for installation.
-
Page 4: Installation
INSTALLATION The cooker hood must be installed centrally over a cooking appliance. The minimum distance between the cooking surface and the metal grease filters on the underside of the hood must be at least 650mm. To install the hood proceed as follows: 1) Drill six 8mm diameter holes at X1-X2-J and insert the plastic rawl plugs supplied as illus- trated in fig. -
Page 5: Maintenance
USE - MAINTENANCE The cooker hood functions are controlled by a series of slider or push button switches mounted on the front of the hood and control the worktop lighting and fan motor speeds. This cooker hood will not remove steam. 1) SLIDER SWITCHES - A switch controls the worktop lighting - ON/OFF. - Page 8 Robert Bosch Hausgeräte GmbH Carl-Wery-Straße 34 81739 München Germany www.bosch-home.com *9000999202* 950901 9001147359...
