Common Mode Noise Filters
2 Mode Noise Filters
EXC14CP type
Features
● Small size and low-profile : 0302 inch size (L 0.85 mm×W 0.65 mm×H 0.45 mm)
● Burst/radiation noise filtering for audio circuits
● The optimally magnetic-coupled ferrite beads allow for the filtering of both common and normal mode noises
● The strong multi-layer structure provides high resistance to reflow soldering heat and a high mounting reliability
● RoHS compliant
Recommended applications
● Smart phones, Tablet PCs, DSC and Portable Music Player
● Noise suppression of burst noise of Receiver/Microphone and D-class power amplifier
Explanation of part numbers
1 2
E X C
Product code Code Dimensions (mm)
Noise filter
0.85×0.65×.045
1
(L)×(W)×(H)
Construction
Inner conductor
Dimensions in mm (not to scale)
Part No.
(inch size)
EXC14CP (0302) 0.65 ± 0.05
Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use.
Should a safety concern arise regarding this product, please be sure to contact us immediately.
3 4 5
1 4
Number of
terminals
4 Terminals
Ferrite
Electrode
C
A
A B
0.85 ± 0.05 0.45 ± 0.05
6 7 8
C P 2
Code Type Code
Characteristics
Coupled Low DCR
C P
type type
Circuit configuration (No polarity)
4
1
※ The pin numbers shown here are for reference purposes only.
Confirm the actual pin number arrangement with the exchanged
specification documents.
F
D
E
B
Dimensions
C D
0.10 min.
9 10 11
2 1 U
Code
Nominal impedance
The first two digits are
significant figure of
U
impedance value, and
the third one denotes
the number of zeros
following.
3 4
2 1
E F
0.50 ± 0.10 0.27 ± 0.10
12
Suffix
Packing form
Embossed carrier
taping
2 mm pitch,
10,000 pcs
3
2
Unit : mm
Mass (Weight)
(mg/ pc.)
1.2
1-Apr-20
