Panasonic EXC14CT Quick Start Manual

Common Mode Noise Filters
EXC14CT type
Features
● Small and thin (L 0.85 mm×W 0.65 mm×H 0.45 mm)
● High attenuation at common-mode for noise suppression of harmonic signal components and cellular frequency
● High cut-off frequency and capability of coping with high-speed signals (HDMI)
● Strong multilayer/sintered structure, excellent reflow resistance and high mounting reliability
● RoHS compliant
Recommended applications
● Smartphones, Tablet PCs and DSC
● Noise suppression of high-speed differential data lines such as MIPI, LVDS
Explanation of part numbers
1 2
E X
Product code Dimensions (mm)
Code
Noise filter
0.85×0.65×.045
1
(L)×(W)×(H)
Construction
Ferrite
Ceramics
Inner conductor
Dimensions in mm (not to scale)
Part No.
(inch size)
EXC14CT (0302) 0.65 ± 0.05
Design and specifications are each subject to change without notice. Ask factory for the current technical specifications before purchase and/or use.
Should a safety concern arise regarding this product, please be sure to contact us immediately.
3 4 5
C 1 4
Number of
terminals
4 Terminals
Electrode
C
A
A B
0.85 ± 0.05
6 7 8
C T 9
Code Type Code
Characteristics
High
Coupled
C T
attenuation
type
type
Circuit configuration (No polarity)
※ The pin numbers shown here are for reference purposes only.
D
F
E
B
Dimensions
C D
0.45 ± 0.05 0.10 min.
9 10
0 0
Nominal impedance Code
The first two digits are
significant figure of
impedance value, and
the third one denotes
the number of zeros
following.
4 3
1 2
E F
0.50 ± 0.10 0.27 ± 0.10
11 12
U
Suffix
Packing form
Embossed carrier
taping
U
2 mm pitch,
10,000 pcs
4 3
1 2
Unit : mm
Mass (Weight)
(mg/ pc.)
1.0
20-Jan-23
