- Page 1 4-732-890-11(1) Television Operating Instructions HOME Help Guide KD-65X7007F / 55X7007F / 49X7007F / 43X7007F...
-
Page 2: Table Of Contents
Introduction Table of Contents Thank you for choosing this Sony product. Before operating the TV, please read this manual thoroughly and retain it for future reference. Note • Before operating the TV, please read the “Safety Information” (page 2). • Instructions about “Installing the TV to the Wall” are included within this TV’s instructions manual. - Page 3 • Only qualified service personnel should carry out wall-mount installations. • For safety reasons, it is strongly recommended that you use Sony accessories, including: Wall-Mount Bracket: SU-WL450 • Be sure to use the screws supplied with the Wall-Mount Bracket when attaching the Wall-Mount Bracket to the TV set. The...
- Page 4 AC power outlet (mains socket). (not supplied) • Use only Sony supplied AC power cords (mains lead), not those of other brands. • Insert the plug fully into the AC power outlet (mains socket).
-
Page 5: Precautions
If the following problems occur... Turn off the TV set and unplug the AC power cord (mains lead) immediately if any of the following problems occur. Ask your dealer or Sony service centre to have it checked by qualified service personnel. - Page 6 Wireless Function of the unit • Do not operate this unit near medical equipment (pacemaker, etc.), as this may result in the malfunction of the medical equipment. • Although this unit transmits/receives scrambled signals, be careful of unauthorised interception. We cannot be responsible for any trouble as a result.
-
Page 7: Parts And Controls
(Sensors/LED indicator) • Receives signals from the remote control. Parts and Controls Do not put anything over the sensor. Doing so may affect its function. • Lights up in amber when the [Sleep Timer]* or [On Timer]* is set, or the TV is in Photo Frame Mode*. -
Page 8: Remote Control
EXIT Remote Control Return to the previous screen or exit from the menu. When an Interactive Application service is available, press to exit from the service. The remote control shape, location, availability and function of remote control Number buttons buttons may vary depending on your •... - Page 9 +/– (Volume) (Text) (Only on limited region/ country/TV model) Adjusts the volume. In text mode, displays Text broadcast. AUDIO Each time you press , the display changes Select the sound of multilingual source or cyclically as follows: dual sound for the program currently being Text ...
-
Page 10: Connecting Tv To The Internet
Connecting TV to the Internet Watching TV Setting up the Internet Press on the TV or the remote control Connection to turn on the TV. To use the network features of your TV it needs Press ANT/DIGITAL/ANALOG to switch to be connected to the Internet. -
Page 11: Equipment
Viewing Pictures from Connected Equipment Connection Diagram You can connect a wide range of optional equipment to your TV. Note • Depending on TV model, connecting a large USB device may interfere with other connected devices beside it. • When connecting a large USB device, connect only 1 USB jack. Headphone/ Audio HDMI Device... -
Page 12: Additional Information
To Customers: For product protection and safety reasons, Sony strongly recommends that installation of your TV be performed by Sony dealers or licensed contractors. Do not attempt to install it yourself. To Sony Dealers and Contractors: Provide full attention to safety during the installation, periodic maintenance and examination of this product. - Page 13 Make sure that the wall has enough space for the TV and is capable of supporting a weight of at least four times that of the TV. Refer to the following table on installing the TV to the wall. See page 18-19 (Specifications) for the TV’s weight. Standard mounting Slim mounting Screen centre point...
- Page 14 Attach the Attachment parts for Wall-Mount Bracket. Check the Attachment parts by referring to “1” of the Wall-Mount Bracket Installation Guide. Note • If using an electric screwdriver, set the torque at approximately 1.5 N·m {15 kgf·cm}. • Be sure to store the unused parts in a safe place for future use. Retain this manual for future reference. Standard mounting KD-65/55X7007F Pulley ...
- Page 15 Slim mounting Note • You cannot use some of the terminals on the rear of the TV when using this mounting style. KD-65/55X7007F Pulley Spacer (20 mm) Screw (+PSW 6 x 20) Belt KD-49/43X7007F Screw (+PSW 6 x 20) ...
- Page 16 Connect necessary cables to the TV. Note • You cannot access to any terminal after installing the TV to the wall. To detach the Table-Top Stand from the TV. KD-65/55X7007F Install the TV to the Base. Refer to “5” of Installation Guide and “Installing the TV to the Wall”...
-
Page 17: Troubleshooting
Check if the [Duration]* is activated by [On Timer]* If the problem persists, contact your dealer or or [Photo Frame Settings]*. Sony service centre with the number of times Check if the [Idle TV Standby]* is activated. the LED indicator flashes red (interval time is Some input sources cannot be selected three seconds). -
Page 18: Specifications
ARC (Audio Return Channel) (HDMI IN 3 only) Two channel linear PCM: 48 kHz 16 bits, Dolby Specifications Digital, Dolby Digital Plus, DTS DIGITAL AUDIO OUT (OPTICAL) System Digital optical jack (Two channel linear PCM: Panel system 48 kHz 16 bits, Dolby Digital, DTS) LCD (Liquid Crystal Display) Panel, LED backlight AUDIO OUT /... - Page 19 • Design and specifications are subject to change Association. without notice. • “PlayStation” is a registered trademark and Notes on HDR (High Dynamic Range) “PS4” is a trademark of Sony Interactive Entertainment Inc. (Only on limited region/country/TV • For DTS patents, see model) http://patents.dts.com.
- Page 24 Help Guide http://rd1.sony.net/help/tv/fphl2/h_ph/ Customer Support and Contact: © 2018 Sony Visual Products Inc. Printed in Malaysia...
