High Static Pressure Ducted
(Type E3)
Model No.
INDOOR UNIT
High Static Pressure Ducted
Type E3
S-180PE3R5B
S-200PE3R5B
S-224PE3R5B
Before operating the unit, read these operating instructions thoroughly and keep them for future reference.
Connectable outdoor unit lineup
●
This booklet is the operating instructions for indoor unit.
Regarding the outdoor unit, see the operating instructions
supplied with the outdoor unit.
OUTDOOR UNIT
Single Split
Refrigerant type :
(R410A)
Type PE2
U-180PE2R8A
U-200PE2R8A
U-224PE2R8A
Panasonic Corporation
1006 Kadoma, Kadoma City, Osaka, Japan
Operating Instructions
Air Conditioner
(3-phase)
(R32)
Type PZH2
U-180PZH2R8
U-200PZH2R8
U-224PZH2R8
ACXF55-23430
Advertisement
Table of Contents
Related Manuals for Panasonic S-180PE3R5B
Summary of Contents for Panasonic S-180PE3R5B
- Page 1 INDOOR UNIT This booklet is the operating instructions for indoor unit. High Static Pressure Ducted Regarding the outdoor unit, see the operating instructions Type E3 supplied with the outdoor unit. S-180PE3R5B OUTDOOR UNIT S-200PE3R5B S-224PE3R5B Single Split (3-phase) Refrigerant type :...
-
Page 2: Table Of Contents
Safety Precautions Thank you for purchasing this Panasonic product. This product is a commercial air conditioner indoor unit. Installation Instructions attached. Contents The following symbols used in this manual, alert you to potentially dangerous conditions to users, service personnel or... - Page 3 WARNING If the refrigerant comes in contact Do not use modified with a flame, it produces a toxic cord, joint cord, gas. extension cord or unspecified cord to prevent For safety, be sure to turn the overheating and fire. air conditioner off and also to disconnect the power before cleaning or servicing.
- Page 4 WARNING CAUTION This appliance is intended to be used by The appliance shall be stored expert or trained users in shops, in light in a room without continuously industry and on farms, or for commercial operating open flames (for use by lay persons. example: an operating gas This appliance is not intended for use appliance) and ignition sources...
-
Page 5: Precautions For Use
Precautions for Use Installation Information for Users on Collection and Disposal of Old Equipment and Used Batteries This air conditioner must be installed properly by qualified installation technicians in accordance with the Installation [Information on Disposal in other Countries Instructions provided with the unit. outside the European Union] Before installation, check that the voltage of the electric These symbols are only valid in the European... -
Page 6: Names Of Parts
Names of Parts INDOOR UNIT Air intake side duct flange (rear) Electrical component box Water drain Air outlet side duct flange Optional Wireless Remote Controller Timer Remote Controller High-spec Wired Remote Controller Model No. Model No. Model No. Model No. CZ-RWS3 CZ-RWRC3 CZ-RTC4... -
Page 7: Maintenance
Maintenance WARNING CAUTION For safety, be sure to turn the air conditioner off and Never use solvents or harsh chemicals. Also, do not disconnect the power before cleaning. (Otherwise, wipe plastic parts using very hot water. (This may cause electric shock or injury may result because the fan is deformation or change in colour.) rotating at high speed.) Some metal edges and fins are sharp. -
Page 8: Troubleshooting
Troubleshooting Check before consulting or requesting services. Symptom Cause / Action Sound like streaming water is heard • Sound of refrigerant liquid flowing inside unit during operation or after operation. • Sound of drainage water through drain pipe Noise Cracking noise is heard during operation •... -
Page 9: Before Requesting Services
Before Requesting Services Symptom Cause Action The air Power failure or after power failure Press the power ON/OFF button on the remote controller. conditioner does • If the breaker is turned off, turn the power on. not operate The operation (power) button is turned off. •... -
Page 10: Specifications
Specifications Indoor unit High Static Pressure Ducted (Type E3) Model Name S-180PE3R5B S-200PE3R5B S-224PE3R5B Power source 230 - 240 V～ 50Hz 18.0 20.0 22.4 Cooling capacity BTU/h 61,400 68,200 76,400 20.0 22.4 25.0 Heating capacity BTU/h 68,200 76,400 85,300 High... - Page 11 MEMO...
- Page 12 © Panasonic Corporation 2018 Panasonic Corporation ACXF55-23430 http://www.panasonic.com Printed in Malaysia DC1218-0...
