Panasonic U-8ME2R8 Installation Instructions Manual
Hide thumbs
Also See for U-8ME2R8:
- Operating instructions manual (8 pages) ,
- Operating instructions manual (8 pages)
Table of Contents
Advertisement
Quick Links
INSTALLATION INSTRUCTIONS
Air Conditioner
This air conditioner uses the refrigerant R410A.
Model No.
Outdoor Units
Type Outdoor Unit Type
ME2 2WAY System
* 1
Should you wish to use as space saving combination, read this Installation Instructions.
* 2
Salt-air damage resistant
• To be connecting Indoor Unit
Indoor Units
Type
Indoor Unit Type
D1
1-Way Cassette
L1
2-Way Cassette
U1
4-Way Cassette
Y2
4-Way Cassette 60 × 60
K1
Wall-Mounted
K2
Wall-Mounted
T2
Ceiling
F2
Low Silhouette Ducted
M1 Slim Low Static Ducted
P1
Floor Standing
R1
Concealed Floor Standing
Z1
Slim Type Ducted
Type
Indoor Unit Type
D1
1-Way Cassette
L1
2-Way Cassette
U1
4-Way Cassette
K1
Wall-Mounted
T2
Ceiling
F2
Low Silhouette Ducted
E1
High Static Pressure Ducted
P1
Floor Standing
R1
Concealed Floor Standing
Z1
Slim Type Ducted
Type
Indoor Unit Type
E1
High Static Pressure Ducted
E2
High Static Pressure Ducted
Read through the Installation Instructions before you proceed with the installation. In particular, you will need to read under
the " IMPORTANT ! " section at the top of the page.
* 1
* 1
8 HP
10 HP
U-8ME2R8
U-10ME2R8
* 2
* 2
U-8ME2R8E
U-10ME2R8E
22
S-28MD1E5
S-22ML1E5
S-28ML1E5
S-22MU1E5A S-28MU1E5A S-36MU1E5A S-45MU1E5A S-56MU1E5A S-60MU1E5A
S-22MY2E5A S-28MY2E5A S-36MY2E5A S-45MY2E5A S-56MY2E5A
S-22MK2E5A S-28MK2E5A S-36MK2E5A
S-22MF2E5A S-28MF2E5A S-36MF2E5A S-45MF2E5A S-56MF2E5A S-60MF2E5A
S-22MM1E5A S-28MM1E5A S-36MM1E5A S-45MM1E5A S-56MM1E5A
S-22MP1E5
S-28MP1E5
S-22MR1E5
S-28MR1E5
S-22MZ1H4A S-28MZ1H4A S-36MZ1H4A S-45MZ1H4A S-56MZ1H4A S-60MZ1H4A
73
S-73MD1E5
S-73ML1E5
S-73MU1E5A S-90MU1E5A S-106MU1E5A S-140MU1E5A S-160MU1E5A
S-73MK1E5A
S-73MT2E5A
S-73MF2E5A S-90MF2E5A S-106MF2E5A S-140MF2E5A S-160MF2E5A
S-73ME1E5
S-71MP1E5
S-71MR1E5
S-73MZ1H4A
Rated Capacity
180
S-224ME1E5 S-280ME1E5
S-180ME2E5
S-224ME2E5 S-280ME2E5
Rated Capacity
* 1
* 1
12 HP
14 HP
U-12ME2R8
U-14ME2R8
* 2
U-12ME2R8E
U-14ME2R8E
Rated Capacity
28
36
S-36MD1E5
S-45MD1E5
S-36ML1E5
S-45ML1E5
S-45MK1E5A S-56MK1E5A
S-36MT2E5A S-45MT2E5A S-56MT2E5A
S-36MP1E5
S-45MP1E5
S-36MR1E5
S-45MR1E5
Rated Capacity
90
106
S-106MK1E5A
S-106MT2E5A S-140MT2E5A
S-106ME1E5 S-140ME1E5
224
280
* 1
16 HP
18 HP
U-16ME2R8
U-18ME2R8
* 2
* 2
U-16ME2R8E
U-18ME2R8E
45
56
S-56MD1E5
S-56ML1E5
S-56MP1E5
S-56MR1E5
140
160
20 HP
U-20ME2R8
* 2
* 2
U-20ME2R8E
60
ACXF60-36621
