Vacuum cleaner User manual SS60K60**** Series / SS60M60**** Series • Before operating this unit, please read the instructions carefully. • For indoor use only.
Contents PREPARATION MAINTENANCE Safety information Maintaining the vacuum cleaner Disassembling / Assembling the dustbin INSTALLATION Cleaning the dustbin Cleaning the sponge filter Name of the parts Cleaning the air intake OPERATIONS APPENDICES Using the vacuum cleaner Notes and cautions Charging the stick vacuum cleaner Battery usage Assembling and Disassembling a battery Operation...
PREPARATION Safety information • Before operating the appliance, please read this manual thoroughly and retain it for your reference. • Because these following operating instructions cover various models, the characteristics of your vacuum cleaner may differ slightly from those described in this manual. Caution/Warning symbols used WARNING Indicates that a danger of death or serious injury exists.
Page 4
General • Read all instructions carefully. Before switching on, make sure that the voltage of your electricity supply is the same as that indicated on the rating plate on the bottom of the cleaner. • WARNING : Do not use the vacuum cleaner when rug or floor is wet. •...
Page 5
• Do not use to suck up water. • Do not immerse in water for cleaning. • Please contact the manufacturer or service agent for a replacement. • For information on Samsung’s environmental commitments and product specific regulatory obligations e.g. REACH (WEEE, Batteries) visit: samsung.com/uk/aboutsamsung/samsungelectronics/ corporatecitizenship/data_corner.html...
Page 6
• Do not mutilate or incinerate batteries as they will explode at high temperatures. • Do not attempt to open the charger. Repairs should only be carried out by a qualified customer care centre. • Do not expose the charger to high temperatures or allow moisture or humidity of any kind to come into contact with the charger.
Page 7
Power related WARNING • Do not bend the power cord with excessive force or do not put heavy object on the power cord. – Otherwise, electric shock or fire may occur. • If there is dust, water, etc. on the pin or contact point of the power plug, wipe them carefully.
Page 8
• Do not use a charger for other purposes. – Otherwise, fatal damage to the charger or fire may occur. • Do not vacuum liquid, blade, pin, ember, etc. during the cleaning. – Otherwise, abnormal operation or product damage may occur. •...
Page 9
CAUTION • Before using the stick vacuum cleaner, check that the handy vacuum cleaner is assembled to the main body correctly. – When the handy vacuum cleaner is not assembled to the main body, the stick vacuum cleaner does not work. •...
Page 10
• When cleaning the exterior of the product, turn off the product first and then wipe it with dry towel. Do not spray water directly onto the product or wipe it with volatile materials such as benzene, thinner or alcohol. –...
OPERATIONS Using the vacuum cleaner Charging the stick vacuum cleaner NOTE • Assemble the battery into the charger completely. • Battery level indicator blinks while the battery is charging. LED display 01 Battery level indicator 02 Turbo mode indicator SS60K60**** Series SS60M60**** Series Assembling and Disassembling a battery CAUTION...
Using the stick vacuum cleaner Power on/off The stick vacuum cleaner starts operating in Turbo mode. Press the button to convert operation mode. (Normal/Turbo) Using the Turbo mode Using the handy vacuum cleaner Disassembling the handy vacuum cleaner from the main body Power on/off The handy vacuum cleaner starts operating in Turbo mode.
Using the crevice tool and dusting brush Dusting brush When removing fine dust on curtain, furniture, sofa etc. Crevice tool When removing fine dust on groove of window frames, chink, corner etc. Using the Long Reach Tool (option) When cleaning a place which is narrow and deep or hard to reach by hand such as under furniture or a ceiling English...
MAINTENANCE Maintaining the vacuum cleaner CAUTION • Before cleaning the stick vacuum cleaner, turn off the vacuum cleaner. Disassembling / Assembling Cleaning the sponge filter the dustbin Cleaning the dustbin Cleaning the air intake NOTE • Emptying the dustbin in a simple way English 15...
APPENDICES Notes and cautions Battery usage • Use a battery with genuine logo ) only. NOTE • Before assembling the battery into a charger or a vacuum • When a vacuum cleaner does not work after charging a battery, cleaner, check that the battery is placed in the correct direction.
Maintenance CAUTION • After the handy vacuum cleaner NOTE is assembled to the main • Sometimes the wheel of air intake body, the stick vacuum cleaner may scratch floor. Therefore, operates. before using the stick vacuum • After using the handy vacuum cleaner, check the wheel status of cleaner, assemble it to the main air intake.
Troubleshooting If the requested service is proved as not product malfunction, the service fee will be charged. Therefore, please read the user manual carefully. Problem Solutions • Check the battery level and charge the battery. • Check that the product is turned off and press the power The stick vacuum cleaner does not button to turn on.
Page 20
If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. Country Customer Care Center Web Site 0330 SAMSUNG (7267864) www.samsung.com/uk/support DJ68-00745S-04...
