- Page 1 329L EN-US Operator's manual 2-18 ES-MX Manual del usuario 19-36 FR-CA Manuel d’utilisation 37-54 A05328CSHV...
-
Page 2: Table Of Contents
Contents Introduction..............2 Troubleshooting............17 Safety................4 Transportation, storage and disposal......17 Assembly................ 8 Technical data.............. 18 Operation................ 9 Accessories..............18 Maintenance..............14 Introduction Product description Intended use The product is a grass trimmer with a combustion The product is used with a trimmer head to cut grass. engine. - Page 3 Symbols on the product Refuelling. WARNING! This product is dangerous. Injury or death can occur to the operator or The rating plate shows the bystanders if the product is not used serial number. yyyy is the carefully and correctly. To prevent injury to production year, ww is the yyyywwxxxx the operator or bystanders, read and obey...
-
Page 4: Safety
California Proposition 65 WARNING The engine exhaust from this product contains chemicals known to the State of California to cause cancer, birth defects or other reproductive harm. Safety Vibration safety • Obey the instructions in this manual. Obey the safety symbols and the safety instructions. - Page 5 physician and medical implant manufacturer before • Do not operate the product if there are persons in you operate the product. the work area. Stop the product if a person goes into the work area. • Do not let a child operate the product. Do not let a person without knowledge of the instructions operate •...
- Page 6 • If the safety devices are defective, speak to your The cutting attachment guard prevents a loose object to Husqvarna servicing dealer. eject in the direction of the operator. Throttle trigger lockout The throttle trigger lockout locks the throttle trigger.
- Page 7 Examine the cutting attachment guard for damage and • Do not start the product if the engine has a leak. replace if it is damaged. Only use the approved guard Examine the engine for leaks regularly. for the cutting attachment. •...
-
Page 8: Assembly
Assembly Introduction To attach the trimmer head 1. Make sure that the cutting attachment guard (A) is WARNING Before you assemble the To assemble the attached to the product. Refer to product, you must read and understand the cutting attachment guard on page 8 . safety chapter. -
Page 9: Operation
5. Shake the fuel mixture to mix the contents. Premixed fuel 6. Fill the fuel tank. • Use Husqvarna premixed alkylate fuel of a good To add fuel quality, for best performance and extension of the engine life. This fuel contains less harmful chemicals •... - Page 10 To start a warm engine 2. Pull the choke control up. 1. Push the air purge bulb 10 times. 2. Pull the starter rope handle slowly until you feel some resistance. When you feel resistance, pull the starter rope handle 3 times quickly and with force. Note If the product does not start and operate, refer To start a cold engine on page 9 .
- Page 11 To trim the grass 4. Use full throttle when you move the product from side to side to cut grass. Make sure that the grass 1. Hold the trimmer head immediately above the trimmer line is parallel to the ground. ground at an angle.
- Page 12 To replace the trimmer line 6,0 m 10 cm 4" 3,05 m 1293 - 001 - 18.09.2019...
- Page 13 15 cm 6" 1293 - 001 - 18.09.2019...
-
Page 14: Maintenance
"Click" Maintenance Introduction • Clean the external surfaces of the carburetor and its adjacent areas. • Clean the cooling system. WARNING Before you do maintenance, you To do • Examine the spark arrester screen. Refer to must read and understand the safety maintenance on the spark arrester screen on page chapter. - Page 15 To examine the spark plug 1. Turn the idle adjustment screw clockwise until the cutting attachment starts to turn. CAUTION Use the recommended spark plug. Make sure that the replacement is the same as the manufacturer supplied part. An incorrect spark plug can cause damage to the product.
- Page 16 1. Remove the air filter cover and remove the air filter. 2. Put the air filter in a plastic bag. 3. Put the air filter oil in the plastic bag. 4. Push the plastic bag to make sure the oil supplies equally across the air filter.
-
Page 17: Troubleshooting
Troubleshooting The engine does not start Check Possible cause Procedure Stop switch. The stop switch is in the stop position. Set the stop switch to the start position. Starter pawls. The starter pawls cannot move freely. Remove the starter cover and clean around the starter pawls. -
Page 18: Technical Data
Technical data Technical data 329L A05328CSHV Engine Cylinder displacement, cu.in/cm 1.68/27.6 Idle speed, rpm 2800 - 3200 Recommended max. speed, rpm 8000 Power / Max. engine output, acc. to ISO 8893, kW/hp @ rpm 0.9/1.2 @ 8000 Catalytic converter muffler... - Page 19 Contenido Introducción..............19 Solución de problemas..........34 Seguridad..............21 Transporte, almacenamiento y eliminación de residuos................ 35 Montaje................. 25 Datos técnicos.............. 35 Funcionamiento............26 Accesorios..............36 Mantenimiento.............. 32 Introducción Descripción del producto Uso específico El producto es una recortadora de césped con un motor El producto se utiliza con un cabezal de corte para de combustión.
- Page 20 Símbolos en la máquina Recarga de combustible. ADVERTENCIA: Este producto es peligroso. El operador o las personas que se La placa de característi- encuentran cerca pueden sufrir lesiones o la cas muestra el número de muerte si el producto no se utiliza con serie.
