INSTALLATION MANUAL
AIR CONDITIONER (SPLIT TYPE)
Indoor unit
RAS-B05, 07, 10, 13, 16BKVG-E
Outdoor unit
RAS-05, 07, 16BAVG-E
RAS-10, 13BAVG-E1
R32
ENGLISH
ESPAÑOL
FRANÇAIS
ITALIANO
DEUTSCH
PORTUGUÊS
POLSKI
ČESKY
PУCСКИЙ
HRVATSKI
MAGYAR
NEDERLANDS
ΕΛΛΗΝΙΚΑ
SVENSKA
SUOMI
NORSK
DANSK
ROMÂNĂ
БЪЛГАРСКИ
EESTI
LATVISKI
SLOVENČINA
SLOVENŠČINA
LIETUVIŲ
1 1 2 2 9 5 0 1 9 7
Advertisement
Table of Contents
Related Manuals for Toshiba RAS-16BAVG-E
Summary of Contents for Toshiba RAS-16BAVG-E
- Page 1 ENGLISH INSTALLATION MANUAL ESPAÑOL AIR CONDITIONER (SPLIT TYPE) FRANÇAIS ITALIANO DEUTSCH PORTUGUÊS POLSKI ČESKY PУCСКИЙ HRVATSKI MAGYAR NEDERLANDS ΕΛΛΗΝΙΚΑ SVENSKA SUOMI NORSK DANSK ROMÂNĂ БЪЛГАРСКИ EESTI Indoor unit RAS-B05, 07, 10, 13, 16BKVG-E LATVISKI SLOVENČINA Outdoor unit RAS-05, 07, 16BAVG-E SLOVENŠČINA RAS-10, 13BAVG-E1 LIETUVIŲ...
-
Page 2: Table Of Contents
CONTENTS PRECAUTIONS FOR SAFETY ............................1 ACCESSORY PARTS .................................4 INSTALLATION DIAGRAM OF INDOOR AND OUTDOOR UNITS ...................5 Optional Installation Parts ...............................5 INDOOR UNIT ..................................6 Installation Place ................................6 Cutting a Hole and Mounting Installation Plate .......................6 Piping and Drain Hose Installation ..........................6 Indoor Unit Fixing ................................7 Drainage ..................................7 OUTDOOR UNIT .................................8... -
Page 3: Precautions For Safety
PRECAUTIONS FOR SAFETY PRECAUTIONS FOR SAFETY Read the precautions in this manual carefully before This appliance is fi lled with R32. operating the unit. • Before installation, please read these precautions for safety carefully. • Be sure to follow the precautions provided here to avoid safety risks. The symbols and their meanings are shown below. - Page 4 • TO PREVENT OVERHEATING THE INDOOR UNIT AND CAUSING A FIRE HAZARD, PLACE THE UNIT WELL AWAY (MORE THAN 2 M) FROM HEAT SOURCES SUCH AS RADIATORS, HEATERS, FURNACE, STOVES, ETC. • WHEN MOVING THE AIR CONDITIONER FOR INSTALLING IT IN ANOTHER PLACE AGAIN, BE VERY CAREFUL NOT TO GET THE SPECIFIED REFRIGERANT (R32) WITH ANY OTHER GASEOUS BODY INTO THE REFRIGERATION CYCLE.
- Page 5 • For R32 model, use pipes, fl are nut and tools which is specifi ed for R32 refrigerant. Using of existing (R22) piping, fl are nut and tools may cause abnormally high pressure in the refrigerant cycle (piping), and possibly result in explosion and injury.
-
Page 6: Accessory Parts
REQUIREMENT OF REPORT TO THE LOCAL POWER SUPPLIER Please make absolutely sure that the installation of this appliance is reported to the local power supplier before installation. If you experience any problems or if the installation is not accepted by the supplier, the service agency will take adequate countermeasures. -
Page 7: Installation Diagram Of Indoor And Outdoor Units
The fl are connection should be installed outdoors. Wireless remote control Saddle Insulate the refrigerant pipes separately with insulation, not together. RAS-05, 07BAVG-E RAS-16BAVG-E RAS-10, 13BAVG-E1 Extension drain hose (Not available, provided by installer) 6 mm thick heat resisting polyethylene foam... -
Page 8: Indoor Unit
INDOOR UNIT INDOOR UNIT When the installation plate is directly mounted Installation Place on the wall • A place which provides the spaces around the indoor unit as shown in the 1. Securely fi t the installation plate onto the wall by screwing it in the upper and diagram lower parts to hook up the indoor unit. -
Page 9: Indoor Unit Fixing
How to remove the drain hose NOTE • The drain hose can be removed by removing the If the pipe is bent incorrectly, the indoor unit may unstably be set on the wall. screw securing the drain hose and then pulling out After passing the connecting pipe through the pipe hole, connect the the drain hose. -
Page 10: Outdoor Unit
2. Put water in the drain pan and make sure that the water is drained out of CAUTION doors. 3. When connecting extension drain hose, insulate the connecting part of Arrange the drain pipe for proper drainage from the unit. extension drain hose with shield pipe. -
Page 11: Evacuating
Tightening connection Compound pressure gauge Pressure gauge –101 kPa Align the centers of the connecting pipes and tighten the fl are nut as far as (–76 cmHg) Manifold valve possible with your fi ngers. Then tighten the nut with a spanner and torque wrench as shown in the fi... -
Page 12: Electrical Works
ELECTRICAL WORKS ELECTRICAL WORKS Model RAS-B05BKVG-E RAS-B07BKVG-E RAS-B10BKVG-E RAS-B13BKVG-E RAS-B16BKVG-E Power source 50Hz, 220 – 240 V Single phase Maximum running current 5.0A 5.5A 7.5A 8.0A Circuit breaker rating 6.5A 7.0A 9.5A 12.5A Power supply cable H07RN-F or 60245 IEC66 (1.5 mm or more) Connecting cable Indoor unit... -
Page 13: In Case Of Indoor Unit Connect With 1:1 Outdoor Unit
Terminal block (L N 1 2 3) Earth line 50 mm Earth line Connecting 10 mm cable Connecting cable RAS-16BAVG-E 10 mm 70 mm Earth line Earth line Power supply Connecting cable cable Power Supply Input at Outdoor Unit Terminal Block (Optional) - Page 14 Power supply input Wiring Diagram for 1:1 Outdoor Unit Power input at Indoor Terminal Block (Recommend) Indoor Chassis Terminal Block Power input Chassis Outdoor Terminal Block Power input at Outdoor Terminal Block (Optional) Indoor Chassis Terminal Block Chassis Outdoor Terminal Block Power input CAUTION...
-
Page 15: In Case Of Indoor Unit Connect With Inverter Multi System (Ims)
In Case of Indoor Unit Connect With Inverter Multi System (IMS) Indoor Unit Connecting cable Stripping length of the Connecting CABLE connect to L 2 3 Connecting cable Terminal block (L N 1 2 3) Earth line 50 mm 10 mm 10 mm 70 mm Earth line... -
Page 16: Others
OTHERS OTHERS Gas Leak Test Test Operation To switch the TEST RUN (COOL) mode, press [RESET] button for 10 seconds. (The beeper will make a short beep.) Check places for the indoor unit. OPERATION / RESET Button Check places for the outdoor unit.
