Haier ESD310 Service Manual

Haier ESD310 Service Manual

Built-in dishwasher
Hide thumbs Also See for ESD310:
Table of Contents

Advertisement

Quick Links

Download this manual
Built-in Dishwasher
SERVICE MANUAL
Features
Energy Star for energy consumption of USA rules
Stainless steel Interior tub
Electronic control
Triple level filter system
Three-spraying, higher cleaning ratio
The capacity for 12 place settings
Models
ESD300/ESD301/ESD302
ESD310/ESD311/ESD312
Part # DW-8888-25

Advertisement

Table of Contents
loading

Related Manuals for Haier ESD310

Summary of Contents for Haier ESD310

  • Page 1 Built-in Dishwasher SERVICE MANUAL Models ESD300/ESD301/ESD302 ESD310/ESD311/ESD312 Features Energy Star for energy consumption of USA rules Stainless steel Interior tub Electronic control Triple level filter system Three-spraying, higher cleaning ratio The capacity for 12 place settings Part # DW-8888-25...

  • Page 2: Table Of Contents

    Serial Number: Version:00.00 Edition: Nov.-23-2005 Built-In Dishwasher Model: ESD300/ESD301/ESD302/310/311/312 Contents 1.Product Code Illumination and Series Introduction ............2 2.Features ..........................2 3.Safety Precaution........................4 4.Net dimension ........................4 5.Installation ...........................5 6.Parts and Features ......................25 7.Control Panel ........................25 8. Start-Upguide ........................26 9.Dishwasher Loading ......................26 10.

  • Page 3: Product Code Illumination And Series Introduction

    Serial Number: Version:00.00 Edition: Nov.-23-2005 Built-In Dishwasher Model: ESD300/ESD301/ESD302/310/311/312 1.Product Code Illumination and Series Introduction Model Identification ESD □□ □ A: Energy Star Dishwasher B: Series of factory design C: Code of Color 0:White 1:Black 2:Stainless steel Examples: ESD300 It represents energy star dishwasher of 300 series, the color of appearance is white. ESD301 It represents energy star dishwasher of 300 series, the color of appearance is black.

  • Page 4: Safety Precaution

    Serial Number: Version:00.00 Edition: Nov.-23-2005 Built-In Dishwasher Model: ESD300/ESD301/ESD302/310/311/312 3.Safety Precaution Page 3 / 47...

  • Page 5: Net Dimension

    Serial Number: Version:00.00 Edition: Nov.-23-2005 Built-In Dishwasher Model: ESD300/ESD301/ESD302/310/311/312 4.Net dimension Page 4 / 47...

  • Page 6: Installation

    Serial Number: Version:00.00 Edition: Nov.-23-2005 Built-In Dishwasher Model: ESD300/ESD301/ESD302/310/311/312 3/4”(1.9 cm) insulation-may be compressed 33-7/8”(86cm) min.with wheels removed 5.Installation 5.1 Tools and materials needed A. pliers B. Phillips screwdriver C. 5/8”open end wrench D. measuring tape or ruler E. 10” adjustable wrench that opens to 1-1/8”(2.9cm) F.
  • Page 7 Serial Number: Version:00.00 Edition: Nov.-23-2005 Built-In Dishwasher Model: ESD300/ESD301/ESD302/310/311/312 5.2 Parts supplied 2 drain hose clamps 1-large 1-small Make sure all these parts are included. See parts list for accessories available for your dishwasher. B. 2 No.ST4.2 X 18 Philips-head screws C.
  • Page 8 Serial Number: Version:00.00 Edition: Nov.-23-2005 Built-In Dishwasher Model: ESD300/ESD301/ESD302/310/311/312 Electrical It is the customer’s responsibility: To contact a qualified electrician. To assure that the electrical installation is adequate and in conformance will all national and local codes and ordinances. You must have: - 120-volt, 60Hz, AC-only, 15- or 20-amp.,fused electrical supply.
  • Page 9 Serial Number: Version:00.00 Edition: Nov.-23-2005 Built-In Dishwasher Model: ESD300/ESD301/ESD302/310/311/312 Drain You must : - Use the new drain hose supplied with your dishwasher. If this is not suitable, use a new drain hose with a maximum length of 12 feet (3.7 m) that meets all current AHAM/IAPMO test standards, is resistant to heat and detergent, and fits the drain connector on your dishwasher.
  • Page 10 Serial Number: Version:00.00 Edition: Nov.-23-2005 Built-In Dishwasher Model: ESD300/ESD301/ESD302/310/311/312 Page 9 / 47...
  • Page 11 Serial Number: Version:00.00 Edition: Nov.-23-2005 Built-In Dishwasher Model: ESD300/ESD301/ESD302/310/311/312 Page 10 / 47...
  • Page 12 Serial Number: Version:00.00 Edition: Nov.-23-2005 Built-In Dishwasher Model: ESD300/ESD301/ESD302/310/311/312 Page 11 / 47...
  • Page 13 Serial Number: Version:00.00 Edition: Nov.-23-2005 Built-In Dishwasher Model: ESD300/ESD301/ESD302/310/311/312 Page 12 / 47...
  • Page 14 Serial Number: Version:00.00 Edition: Nov.-23-2005 Built-In Dishwasher Model: ESD300/ESD301/ESD302/310/311/312 Page 13 / 47...
  • Page 15 Serial Number: Version:00.00 Edition: Nov.-23-2005 Built-In Dishwasher Model: ESD300/ESD301/ESD302/310/311/312 Page 14 / 47...
  • Page 16 Serial Number: Version:00.00 Edition: Nov.-23-2005 Built-In Dishwasher Model: ESD300/ESD301/ESD302/310/311/312 Page 15 / 47...
  • Page 17 Serial Number: Version:00.00 Edition: Nov.-23-2005 Built-In Dishwasher Model: ESD300/ESD301/ESD302/310/311/312 Page 16 / 47...
  • Page 18 Serial Number: Version:00.00 Edition: Nov.-23-2005 Built-In Dishwasher Model: ESD300/ESD301/ESD302/310/311/312 Page 17 / 47...
  • Page 19 Serial Number: Version:00.00 Edition: Nov.-23-2005 Built-In Dishwasher Model: ESD300/ESD301/ESD302/310/311/312 Page 18 / 47...
  • Page 20 Serial Number: Version:00.00 Edition: Nov.-23-2005 Built-In Dishwasher Model: ESD300/ESD301/ESD302/310/311/312 Page 19 / 47...
  • Page 21 Serial Number: Version:00.00 Edition: Nov.-23-2005 Built-In Dishwasher Model: ESD300/ESD301/ESD302/310/311/312 Page 20 / 47...
  • Page 22 Serial Number: Version:00.00 Edition: Nov.-23-2005 Built-In Dishwasher Model: ESD300/ESD301/ESD302/310/311/312 Page 21 / 47...
  • Page 23 Serial Number: Version:00.00 Edition: Nov.-23-2005 Built-In Dishwasher Model: ESD300/ESD301/ESD302/310/311/312 Page 22 / 47...
  • Page 24 Serial Number: Version:00.00 Edition: Nov.-23-2005 Built-In Dishwasher Model: ESD300/ESD301/ESD302/310/311/312 Page 23 / 47...
  • Page 25 Serial Number: Version:00.00 Edition: Nov.-23-2005 Built-In Dishwasher Model: ESD300/ESD301/ESD302/310/311/312 Page 24 / 47...

  • Page 26: Parts And Features

    Serial Number: Version:00.00 Edition: Nov.-23-2005 Built-In Dishwasher Model: ESD300/ESD301/ESD302/310/311/312 6. PARTS AND FEATURES 7. Control Panel Page 25 / 47...

  • Page 27: Start-Upguide

    Serial Number: Version:00.00 Edition: Nov.-23-2005 Built-In Dishwasher Model: ESD300/ESD301/ESD302/310/311/312 8.START-UPGUIDE Before using your dishwasher, remove all packaging materials. Using New Dishwasher 1. Rinse aid is essential for good drying. Be sure to fill the dispenser before you use your new dishwasher.
  • Page 28 Serial Number: Version:00.00 Edition: Nov.-23-2005 Built-In Dishwasher Model: ESD300/ESD301/ESD302/310/311/312 -Load heavy pots and pans carefully. Heavy items can dent the stainless steel interior of the door if they are dropped or bumped. -Make sure pot lids and handles, pizza pans, cookie sheets, etc., do not interfere with the spray arm rotation. -Conserve water, energy and save time over hand rinsing by running a rinse cycle to keep dishes moist if you do not plan to wash them soon.
  • Page 29 Serial Number: Version:00.00 Edition: Nov.-23-2005 Built-In Dishwasher Model: ESD300/ESD301/ESD302/310/311/312 1. Pull the rack forward slightly to access track stops. 2. To release, press the button of the track stop and pull track stop out of the track. 3. After removing both track stops, pull rack out. To replace the top rack 1.

  • Page 30: Dishwasher Use

    Use only detergent specifically made for use in dishwashers. Cascade, Cascade Complete and Electrasol Automatic Dishwashing Detergents have been approved for use in all Haier dishwashers. Keep your detergent fresh and dry. Don't put powder detergent into the dispenser until you're ready to wash dishes.
  • Page 31 Serial Number: Version:00.00 Edition: Nov.-23-2005 Built-In Dishwasher Model: ESD300/ESD301/ESD302/310/311/312 4. Close the dispenser cover. It is normal for the cover to open partially when dispensing detergent. NOTE: Use both sections for cycles with 2 washes . Use only the main wash section for cycles with 1 wash, See the "Cycle Selection Charts "for more details.
  • Page 32 Serial Number: Version:00.00 Edition: Nov.-23-2005 Built-In Dishwasher Model: ESD300/ESD301/ESD302/310/311/312 Page 31 / 47...
  • Page 33 Serial Number: Version:00.00 Edition: Nov.-23-2005 Built-In Dishwasher Model: ESD300/ESD301/ESD302/310/311/312 Page 32 / 47...
  • Page 34 Serial Number: Version:00.00 Edition: Nov.-23-2005 Built-In Dishwasher Model: ESD300/ESD301/ESD302/310/311/312 10.5 Canceling a cycle 10.6 Changing a cycle 10.6 Adding Items During a Cycle Page 33 / 47...
  • Page 35 NSF/ANSI standard 184 for Residential Dishwashers. Certified residential dishwashers are not intended for licensed food establishments. Child Lock(On ESD310/311/312 models) Use Child Lock to prevent un intended use of the dishwasher. You can also use the Child Lock feature to prevent unintended cycle or option changes during a cycle.
  • Page 36 Sanitized glows when cycle has met sanitization condition. The light will remain ON until door is opened. Add Rinse Aid (on ESD310/311/312 models) Fill the Rinse Aid dispenser when Add Rinse Aid is lit. A rinse aid prevents water from forming droplets that dry as spots or streaks.

  • Page 37: Washing System

    Serial Number: Version:00.00 Edition: Nov.-23-2005 Built-In Dishwasher Model: ESD300/ESD301/ESD302/310/311/312 particles from redepositing on the clean dishes. The wash water continuously flows through the filter, trapping food particles. -Two water jets, located under the spray arm, remove the food particles from the filter. -A coarse strainer prevents bones, pits, and other large objects from entering the pump system.

  • Page 38: Washing Special Items And Dishwasher Care

    Serial Number: Version:00.00 Edition: Nov.-23-2005 Built-In Dishwasher Model: ESD300/ESD301/ESD302/310/311/312 14.Washing special items and dishwasher care To clean interior Page 37 / 47...

  • Page 39: Drain Air Gap

    Serial Number: Version:00.00 Edition: Nov.-23-2005 Built-In Dishwasher Model: ESD300/ESD301/ESD302/310/311/312 Make a paste with powdered dishwasher detergent on a damp sponge and clean. Use liquid automatic dishwasher detergent and clean with a damp sponge. See the vinegar rinse procedure in "spotting and filming on dishes" in "Troubleshooting." NOTE: Run a Normal cycle with detergent after cleaning the interior 15.Drain Air Gap Check the drain air gap anytime your dishwasher isn't draining well.

  • Page 40: Function Schedule

    130F Pre-wash First Rinse 150F Main wash Third rinse 161F Sanitize Rinse Drying(If heated dry is selected) 2、Anti-Bacterial wash(Middle and light soil, On ESD310/311/312 models) 130F Pre-wash Rinse 150F Main Wash 161F Sanitize Rinse Drying(if Heated dry is selected 3、Pots and Pans Wash...
  • Page 41 Notice: *:The temp. Should 140 F when selecting Hi-Temp Wash. **:If user select Sanitize Rinse option, the dishwasher would heat water to 161F in this step. 7.Normal Wash (On ESD310/311/312 models, Middle soil level) Rinse Pre-wash warmly *130F Main wash...

  • Page 42: Maintenances Services And Trouble Shooting

    18.Maintenances Services and Trouble Shooting ESD300/301/302 If the s7(Clean) and s8(Ssanitized) indicator flash at same time,the temperature sensor is fault. ESD310/311/312 S6 S7 S1 S2 S3 S4 S5 If the 2-digit 7-segment displayer display Er, it shown that the temperature sensor is fault.
  • Page 43 Serial Number: Version:00.00 Edition: Nov.-23-2005 Built-In Dishwasher Model: ESD300/ESD301/ESD302/310/311/312 Analysis of the common breakdowns. Phenomenon: the cycle and option can not been selected Close the door Is the door closed? Do you put the plug(if Put the plug into the outlet. installed) into the outlet? Is the power switch (if installed)turned on?
  • Page 44 Serial Number: Version:00.00 Edition: Nov.-23-2005 Built-In Dishwasher Model: ESD300/ESD301/ESD302/310/311/312 Phenomenon: the dishwasher is running properly without water in tub Is the water shut-up valve turned on? Turn on the valve The overfill floater is Press the floater The water pressure is too The water pressure is slow,a A booster pump before...
  • Page 45 Serial Number: Version:00.00 Edition: Nov.-23-2005 Built-In Dishwasher Model: ESD300/ESD301/ESD302/310/311/312 Heating trouble Phenomenon: program controller stop turning Whether socket connector is connected well Connect it well Whether thermo limiter is change thermo limiter Whether heater is OK change heater PCB or circuit is broken Page 44 / 47...
  • Page 46 Serial Number: Version:00.00 Edition: Nov.-23-2005 Built-In Dishwasher Model: ESD300/ESD301/ESD302/310/311/312 Power supply trouble Phenomenon: dishwasher cannot work check whether the power connector Connect it properly check whether the power connector is in position is in position check whether the circuit the cable or the controller board between the two terminals should be suspected is open...

  • Page 47: Circuit Diagram

    Version:00.00 Edition: Nov.-23-2005 Built-In Dishwasher Model: ESD300/ESD301/ESD302/310/311/312 19.Circuit Diagram ESD310/ESD311/ESD312 MODELS 1 2 0 V ~ 6 0 H Z D o o r s w it c h G r o u n d D o o r s w it c h...
  • Page 48 Serial Number: Version:00.00 Edition: Nov.-23-2005 Built-In Dishwasher Model: ESD300/ESD301/ESD302/310/311/312 ESD300/ESD301/ESD302 MODELS 120V~ 60HZ Door switch Grounding Door switch User Controller Temp. Limiter Heater Washing motor Capacitor Drain motor Dispenser P2-3 Float switch Inlet Valve P2-2 Thermostat P2-1 Page 47 / 47...
  • Page 49 Serial Number: Version:00.00 Edition: Nov.-23-2005 Built-In Dishwasher Model: ESD300/ESD301/ESD302/310/311/312 Sincere Forever Page 48 / 47...
