Sealey SDC01 Quick Start Manual

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to Wear eye
instruction protection
manual
1. INTRODUCTION
Perform a risk assessment of the task to be undertaken before beginning.
‰
WARNING! Wear approved safety eye protection.
‰
Wear appropriate protective clothing.
9
Familiarise yourself with the applications, limitations and potential hazards of the job at hand.
9
Maintain the drain unblocker in good condition and kept clean.
9
Maintain correct balance and footing. Ensure the floor is not slippery and wear non-slip shoes.
9
2. INTRODUCTION
Hand-fed 7.6m hand-fed coiled wire rod with rotating handle to clear stubborn blockages and residue. Locking mechanism retains wire
rod once fed back into unit. Ø14mm tip and Ø6mm rod ideal for clearing of small diameter pipework as well as sinks, showers, baths
and drains.
3. FEATURES
Extendable, hand fed spiral rod with straight auger. (fig1.1)
Rotating handle. (fig1.2)
Ergonomic pistol grip handle. (fig1.3)
Worm screw for removing stubborn blockages and clearing drains and PVC pipes.(fig1.4)
Locking Screw (fig1.5)
4. INSTRUCTIONS
WARNING! Put on your PPE. Drain clearing is a messy and unpleasant job, so it's crucial that you protect yourself from any spray or
‰
splashes that may occur.
4.1. Locate the pipe and unscrew the drain unblocker lock screw (fig1.5). Pull out appropriate length of worm screw (fig1.4) and insert into
the pipe as far as you can until you feel like you may have reached the blockage.
4.2. Tighten lock screw (fig1.5) and rotate handle (fig1.2) in a clockwise rotation.
4.3. Continue to rotate the worm screw handle (fig1.2) and wiggle the rod in and out of the drain slightly to see if it loosens any of the
blockages.
4.4. Keep an eye on the water level to see if it starts to drop at all.
4.5. When the water level drops, remove the worm screw (fig1.4) by turning anti clockwise and continue to seek other parts of the pipe
which may still be blocked.
4.6. Re-insert the worm screw (fig1.4)and continue to wiggle in and out until the blockage is completely removed and the water level drops
completely.
4.7. Once you're happy that the blockage has been removed and the water level
is as it should be,remove the worm screw and clean.
4.8. Loosen locking screw (fig1.5) and push back worm screw into its casing
then tighten locking screw.
© Jack Sealey Limited
DRAIN UNBLOCKER
MODEL NO:
Wear protective Wear protective
gloves clothing
SPECIFICATION
Original Language Version
SDC01
Wear a mask
2
1
4
5
3
fig.1
SDC01 V1 Issue:1 19/10/22
