Sony HT-CT500 Service Manual

SERVICE MANUAL
Ver. 1.0 2009.05
• HT-CT500 is composed of following models.
As service manuals are issued for each component model,
please refer to them.
COMPONENT MODEL NAME
Active Subwoofer
Speaker System
Speaker Bracket
Note: WS-CT500EB has been described to this service manual.
SPECIFICATIONS
WS-CT500EB
Extension bracket
Dimensions (approx.) 286 mm × 179 mm × 60 mm
(11 3/8 in ×7 1/8 in × 2 3/8 in) (w/h/d)
Mass (approx.) 1.3 kg (2 lb 14 oz)
Rear cover
Dimensions (approx.) 294 mm × 185 mm × 67 mm
(11 5/8 in × 7 3/8 in × 2 3/4 in) (w/h/d)
Mass (approx.) 0.56 kg (1lb 4oz)
General
Power requirements
US, Canadian models: 120V AC, 60 Hz
Other models: 220 – 240 V AC, 50/60 Hz
Power consumption
On: 110 W
Standby mode: 0.3 W (when "CTRL: HDMI"
and "S-AIR STBY" are set to "OFF.")
Power output
(DIGITAL MEDIA PORT) DC OUT: 5 V, 700 mA
Design and specifi cations are subject to change without notice.
• Standby power consumption 0.3 W.
• Halogenated flame retardants are not used in the
certain printed wiring boards.
• Over 85 % power efficiency of amplifier block is
achieved with the full digital amplifier, S-master.
Sony Corporation
9-889-499-01
2009E05-1 Audio&Video Business Group
©
2009.05 Published by Sony Techno Create Corporation
HT-CT500
SA-WCT500
SS-CT500
WS-CT500EB
HT-CT500
Saudi Arabia Model
Unpacking
• Subwoofer (SA-WCT500) (1)
• Speaker (SS-CT500) (1)
• AM loop antenna (aerial) (1)
• FM wire antenna (aerial) (1)
• Speaker cord (1)
• Digital optical cord for a TV (2.5 m) (1)
• Remote commander (1)
• R6 (size AA) batteries (2)
• WS-CT500EB
• Extension bracket (1)
• Rear cover (1)
• Screws for the extension bracket (large, +PSW5 x 12 mm) (7)
• Screws for the rear cover (small, M3 x 8 mm) (4)
• Support belt (1)
• Screw for the support belt (+PSW4 x 20 mm) (1)
• Wood screw for the support belt (M3.8 x 20 mm) (1)
• Operating Instructions (1)
HOME THEATRE SYSTEM
US Model
Canadian Model
AEP Model
UK Model
