English–14
– "Odometer": Display of the total distance traveled with
the eBike (cannot be reset)
– " NuVinci Cadence/Gear": This menu item is dis-
played only in conjunction with a Nu Vinci H|Sync auto-
matic transmission.
If you press the "i" button for longer than 1 s, you will ac-
cess the NuVinci menu item from any menu item in the
information menu.
To switch from the " NuVinci Cadence" mode to the
" NuVinci Gear" mode, press the "i" button for 1 s.
To switch from the " NuVinci Gear" mode to the " Nu-
Vinci Cadence" mode, all you have to do is briefly press
the "i" button.
The default setting is " NuVinci Cadence".
Range
– "Gear": This menu item appears only in conjunction
with a Shimano-Di2 gear hub. The currently engaged
gear of the transmission is shown on the display. The
newly engaged gear will be shown briefly on the display
whenever the gear is shifted.
– " Autom. Gear Selection": This menu item appears
only in conjunction with an SRAM automatic trans-
mission.
Range
By pressing the "i" button for more than 1 s, you can
switch back and forth between the " Autom. ""Gear
Selection" automatic mode and the " Gear" manual
mode.
If you are in first gear in manual mode, you can also press
the "–" 12 button to go to the " Autom. Gear Selec-
tion" mode. By pressing the "–" 12 button again, you
can switch back to the manual mode. It is also possible
to access the manual mode by pressing the "+" 13 but-
ton.
– "Trip distance": Distance covered since the last reset
0 276 001 USAen | (17.6.15)
Odometer NuVinci Cadence
(1 s)
(1 s)
NuVinci Gear
Odometer Gear: Auto
(1 s)
(1 s)
Gear
To switch between the indication functions, press the "i"
button 1 on the on-board computer or the "i" button 11 on
the operating unit until the desired function is displayed.
To reset "Trip distance", "Trip time" and "Avg. speed",
switch to any of the three functions and then press and hold
the "RESET" button 6 until the indicator is set to zero. This
also resets the values for the other two functions.
To reset the "Max. speed", switch to this function and then
press and hold the "RESET" button 6 until the indicator is
set to zero.
To reset "Range", switch to this function and then press
the "RESET" 6 button until the display is reset to the value
of the factory setting.
When the on-board computer is removed from the holder
4, all function values remain stored and can be viewed.
Displaying/Adapting Basic Settings
The basic settings can be displayed and changed regard-
less of whether the on-board computer is inserted in the
holder 4 or not. Some settings are visible and changeable
only when the operating computer is inserted. Some menu
items may be missing depending on the equipment of your
eBike.
To access the basic settings menu, press and hold the
"RESET" button 6 and the "i" button 1 until "Configura-
tion" is displayed in text indicator d.
To switch between the basic settings, press the "i" but-
ton 1 on the on-board computer until the desired basic set-
ting is displayed. When the on-board computer is inserted
in holder 4, you can also press the "i" button 11 on the op-
erating unit.
To change the basic settings, press the On/Off button 5
next to the "–" indicator to decrease the value or scroll
(1 s)
down, or the light button 2 next to the "+" indicator to in-
crease the value or scroll up.
When the on-board computer is inserted in holder 4, you
can also change the values with the "–" button 12 or the
"+" button 13 on the operating unit.
To exit the function and store a changed setting, press the
"RESET" button 6 for 3 s.
