Panasonic TX-PR50VT50 Service Manual

Panasonic TX-PR50VT50 Service Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
TX-P50VT50B
Model No.
TX-P50VT50Y
TX-PR50VT50
GPF15D-E Chassis
© Panasonic Corporation 2012.
Unauthorized copying and distribution is a violation
of law.
ORDER NO.PCZ1204080CE
Plasma Television

Advertisement

Table of Contents
loading

Related Manuals for Panasonic TX-PR50VT50

Summary of Contents for Panasonic TX-PR50VT50

  • Page 1 ORDER NO.PCZ1204080CE Plasma Television TX-P50VT50B Model No. TX-P50VT50Y TX-PR50VT50 GPF15D-E Chassis © Panasonic Corporation 2012. Unauthorized copying and distribution is a violation of law.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS PAGE PAGE 1 Safety Precautions -----------------------------------------------3 1.1. General Guidelines ----------------------------------------3 1.2. Touch-Current Check--------------------------------------3 2 Warning --------------------------------------------------------------4 2.1. Prevention of Electrostatic Discharge (ESD) to Electrostatically Sensitive (ES) Devices ----------4 2.2. About lead free solder (PbF) ----------------------------5 3 Service Navigation------------------------------------------------6 3.1.

  • Page 3: Safety Precautions

    1 Safety Precautions 1.1. General Guidelines 1. When conducting repairs and servicing, do not attempt to modify the equipment, its parts or its materials. 2. When wiring units (with cables, flexible cables or lead wires) are supplied as repair parts and only one wire or some of the wires have been broken or disconnected, do not attempt to repair or re-wire the units.

  • Page 4: Warning

    2 Warning 2.1. Prevention of Electrostatic Discharge (ESD) to Electrostatically Sensitive (ES) Devices Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called Electrostatically Sensitive (ES) Devices. Examples of typical ES devices are integrated circuits and some field-effect transistors and semiconductor [chip] components.

  • Page 5: About Lead Free Solder (Pbf)

    2.2. About lead free solder (PbF) Note: Lead is listed as (Pb) in the periodic table of elements. In the information below, Pb will refer to Lead solder, and PbF will refer to Lead Free Solder. The Lead Free Solder used in our manufacturing process and discussed below is (Sn+Ag+Cu). That is Tin (Sn), Silver (Ag) and Copper (Cu) although other types are available.

  • Page 6: Service Navigation

    3 Service Navigation 3.1. PCB Layout Board Name Function Power Supply Non serviceable. P-Board should be exchanged for service. Main AV input, processing Remote receiver, Power LED, C.A.T.S sensor Data Driver (Lower Right) Data Driver (Lower Center) Data Driver (Lower Left) Scan Drive Sustain Drive Sustain out (Lower)

  • Page 7: Applicable Signals

    3.2. Applicable signals COMPONENT (Y, P ) (from AV2 terminal), HDMI Signal name COMPONENT HDMI 525 (480) / 60i, 60p 625 (576) / 50i, 50p 750 (720) / 60p, 50p 1,125 (1,080) / 60i, 50i 1,125 (1,080) / 60p, 50p, 24p * Mark: Applicable input signal PC (from HDMI terminal) Signal name...

  • Page 8: Specifications

    NTSC disc playback from DVD player and recorder. M.NTSC Playback from M.NTSC Video recorders (VCR). NTSC (AV input only) Playback from NTSC Video recorders (VCR). • Check the latest information on the available services at the following website. (English only) http://panasonic.jp/support/global/cs/tv/...
  • Page 9 Demodulation - QPSK, 8PSK DiSEqC - Version 1.0 • Check the latest information on the available services at the following website. (English only) http://panasonic.jp/support/global/cs/tv/ Receiving systems / Band name (R) PAL D, K, SECAM D, K VHF R1 - R2...
  • Page 10 0 °C - 40 °C Usage temperature range Battery Coin-shaped lithium battery CR2025 Operation time: Approx. 75 hours in continuous use of the battery made by Panasonic Viewing range Within 3.2 m from front surface of the TV Materials Main body: Resin...

  • Page 11: Technical Descriptions

    One-to-One CI Plus DTCP-IP WIDEVINE Netflix (For USB Rec.) TX-P50VT50B TX-P50VT50Y TX-PR50VT50 None None 5.2. USB HDD Recording 5.2.1. General information: Digital TV programmes can be recorded in USB HDD. A One-to-One key generated in A-board by SELF CHECK binds TV and USB-HDD for communication.

  • Page 12: Service Port (M3 Mini Jack) Specifications

    5.3. Service port (M3 mini Jack) Specifications The Service port (M3 mini Jack) on the following TVs can use as the RS232C terminal which is a standard computer SERIAL interface. *This operation system should be used by the certified professional dealer. PC Control of the TV •...
  • Page 13 Main, Input & Picture Control Command Control Inquiry Call back Parameter note Command Command Command STANDARD POWER ON QPW : * "0"(OFF)/ "1"(ON) CONTROL POWER OFF (level) AVL: *** QAV : *** "000" - "100" (up) (down) MUTE AMT (Toggle) QAM : * "0"(NO MUTED) / "1"(MUTED)
  • Page 14 Else & Remote Controller Key Command Control Inquiry Call back Parameter note Command Command Command Information QIF : ***** 480i 480p 576i 576p 720p 1080i 1080p DIRECT CH ICH : 0 INPUT ICH : 1 ICH : 2 ICH : 3 ICH : 4 ICH : 5 ICH : 6...

  • Page 15: Service Mode

    6 Service Mode 6.1. How to enter into Service Mode 6.1.1. Purpose After exchange parts, check and adjust the contents of adjustment mode. While pressing [VOLUME ( - )] button of the main unit, press [0] button of the remote control three times within 2 seconds. Note: Service Mode can not be entered when 3D signal input.
  • Page 16 6.1.4. Contents of adjustment mode • Value is shown as a hexadecimal number. • Preset value differs depending on models. • After entering the adjustment mode, take note of the value in each item before starting adjustment. Main item Sub item Sample Data Remark ADJUST...

  • Page 17: Option - Mirror

    6.2. Option - Mirror Picture can be reversed left and right or up and down. 00 : Default (Normal picture is displayed) 01 : Picture is reversed left and right. 02 : Picture is reversed up and down. Hint : If the defective symptom (e.g. Vertical bar or Horizontal bar) is moved by selection of this mirror, the possible cause is in A-board.

  • Page 18: Drv Check - Usbhdd Check

    6.4. DRV Check - USBHDD Check 1. Select [DRV Check - USBHDD Check] in Service Mode. 2. Press [OK] button on the remote control for more than 3 seconds. 6.5. Hotel mode 1. Purpose Restrict a function for hotels. Item Function 2.

  • Page 19: Data Copy By Sd Card

    6.6. Data Copy by SD Card 6.6.1. Purpose (a) Board replacement (Copy the data when exchanging A-board): When exchanging A-board, the data in original A-board can be copied to SD card and then copy to new A-board. (b) Hotel (Copy the data when installing a number of units in hotel or any facility): When installing a number of units in hotel or any facility, the data in master TV can be copied to SD card and then copy to other TVs.
  • Page 20 6.6.3. Data copy from TV set to SD Card 1. Turn on the TV set. 2. Insert SD card with a startup file (pwd file) to SD slot. On-screen Display will be appeared according to the startup file automatically. 3. Input a following password for (a) or (b) by using remote control. (a) For Board replacement : 2770 (b) For Hotel : 4850 Data will be copied from TV set to SD card.
  • Page 21 6.6.4. Data copy from SD Card to TV set 1. Turn on the TV set. 2. Insert SD card with Data to SD slot. On-screen Display will be appeared according to the Data folder automatically. 3. Input a following password for (a) or (b) by using remote control. (a) For Board replacement : 2771 (b) For Hotel : 4851 Data will be copied from SD card to TV set.

  • Page 22: Troubleshooting Guide

    7 Troubleshooting Guide Use the self-check function to test the unit. 1. Checking the IIC bus lines 2. Power LED Blinking timing 7.1. Check of the IIC bus lines 7.1.1. How to access 7.1.1.1. Self-check indication only: Produce TV reception screen, and while pressing [VOLUME ( - )] button on the main unit, press [OK] button on the remote control for more than 3 seconds.

  • Page 23: Power Led Blinking Timing Chart

    7.2. Power LED Blinking timing chart 1. Subject Information of LED Flashing timing chart. 2. Contents When an abnormality has occurred the unit, the protection circuit operates and reset to the stand by mode. At this time, the defective block can be identified by the number of blinks of the Power LED on the front panel of the unit. Blinking Times Contents Check point...

  • Page 24: No Power

    7.3. No Power First check point There are following 3 states of No Power indication by power LED. 1. No lit 2. Green is lit then turns red blinking a few seconds later. (See Power LED Blinking timing chart) 3. Only red is lit.

  • Page 25: No Picture

    7.4. No Picture...

  • Page 26: Local Screen Failure

    7.5. Local screen failure Plasma display may have local area failure on the screen. Fig-1 is the possible defect P.C.B. for each local area. Fig-1...

  • Page 27: Service Fixture & Tools

    8 Service Fixture & Tools 8.1. SC jig Purpose: To find the failure board (SC or SU/SD) when the power LED is blinking 7 times. SC jig: Jumper connector to connect to SC50 connector on SC board Part number: TZSC09187 How to use: Caution: Remove SC jig from SC board after inspection.

  • Page 28: Disassembly And Assembly Instructions

    9 Disassembly and Assembly Instructions 9.1. Disassembly Flow Chart for the Unit This is a disassembly chart. When assembling, perform this chart conversely.

  • Page 29: Disassembly Procedure For The Unit

    9.2. Disassembly Procedure for the Unit 9.2.1. Remove the Pedestal stand 9.2.4. Remove the Wi-LAN module 1. Remove the Plasma panel section from the servicing 1. Remove the screw (×1 ) and remove the Wi-LAN stand and lay on a flat surface such as a table (covered module.
  • Page 30 9.2.7. Remove the AC inlet 9.2.9. Remove the A-Board Caution: 1. Unlock the cable clampers and the tapes to free the To remove AC inlet wait 1 minute after power was off for cables. discharge from electrolysis capacitors. 2. Disconnect the connectors (A1, A6, A8, A12 and A50). 1.
  • Page 31 9.2.11. Remove the Speakers 9.2.13. Remove the Fan 1. Unlock the tapes to free the cables. 1. Remove the screws (×3 2. Disconnect the Relay connector. 2. Remove the Relay connector and remove the Fan. 3. Remove the Speaker clip (each) and remove the Speakers (L, R).
  • Page 32 9.2.15. Remove the SD-Board 9.2.16. Remove the SC-Board 1. Disconnect the flexible cables (SD1, SD2, SD3, SD4 and 1. Unlock the cable clampers and the tapes to free the SD5) connected to the SD-Board. cables. 2. Disconnect the flexible cable (SU11-SD11) and the bridge 2.
  • Page 33 9.2.18. Remove the SS2-Board 9.2.20. Remove the BT connector clamper 1. Disconnect the flexible cables (SS54, SS55 and SS57). 1. Unlock the cable clampers and the tapes to free the cables. 2. Remove the screws (×2 ) and remove the SS2-Board. 2.
  • Page 34 9.2.22. Remove the Contact metal bottom 9.2.25. Remove the Contact metals 1. Remove the Tape from the Contact metals. 2. Remove the screws (×6 1. Remove the screws (×6 3. Remove the Contact metal side (L, R). 2. Remove the Contact metal bottom B. 4.
  • Page 35 9.2.27. Remove the C2-Board 1. Disconnect the flexible cables (CB8, CB9, CB10 and CB11). 2. Disconnect the flexible cables (C21 and C26). 3. Disconnect the connectors (C20 and C25). 4. Remove the screws (×3 ) and remove the C2-Board. 9.2.28. Remove the C3-Board 1.

  • Page 36: Measurements And Adjustments

    10 Measurements and Adjustments 10.1. Adjustment 10.1.1. Vsus selection Caution: When Plasma panel or A-board is replaced, Vsus should be set to LOW or HIGH. Procedure 1. Go into main item [VSUS] in Service Mode. LOW or HIGH will be displayed. 2.
  • Page 37 10.1.2. White balance adjustment Name of measuring instrument Remarks Color analyzer (Minolta CS-2000 or equivalent) Procedure Remarks 1. Enter the Service mode. 2. Receive the Analog-RF (except for no signal) or set CVBS/YUV/HDMI (no signal is available). 3. Select [WB-ADJ] by using [1] and [2] key in the remote controller. 4.

  • Page 39: Block Diagram

    11 Block Diagram 11.1. Main Block Diagram MAIN AV INPUT,PROCESSING HDMI1-4 CI SLOT (HDMI2) TMDS DATA ETHERNET DATA Parallel_TS(SAT) ETHERPHY ETHERNET HDMI I/F LAN CON I/F ARC_OUT TUNER IFD_OUT TUNER I/F USB I/F USB1-3 Parallel_ TS(CI) DP/DM Parallel_ WiFi TS(FE) TS I/F OFDM USB HUB...

  • Page 40: Block (1/4) Diagram

    11.2. Block (1/4) Diagram JK8600 SD CARD SPEAKER_L SPEAKER_R WOOFER BLUETOOTH D3201 DIGITAL JK8602A JK8603 JK8601 JK8606 JK8605 JK4703B JK4702B JK4701B JK4700B AUDIO TU6702 ETHERNET USB1 USB2 USB3 WiFi MAIN AV INPUT,PROCESSING TER IN SAT IN HDMI1 HDMI2 HDMI3 HDMI4 TUNER LNB POWER DMD_...

  • Page 41: Block (2/4) Diagram

    11.3. Block (2/4) Diagram JK3103 RS-232C MAIN AV INPUT,PROCESSING IC9300 PD6H IC3851 STB3.3V RS232C VIDEO DATA DRIVER PLASMA AI VIDEO DATA LVDS DATA H/V Sync Control VIDEO DATA P+3.3V Sub Filed Processor RS-232C IC9803 P+1.2V P+3.3V DCDC15V P+1.2V SBI1 KEY1 IIC0 SBO1 KEYSCAN...

  • Page 42: Block (3/4) Diagram

    11.4. Block (3/4) Diagram POWER SUPPLY COLD COLD RESONANCE F301 Vda CONVERTER RECTIFIER SWITCHING SWITCHING SWITCHING 55kHz-280kHz 90kHz-240kHz TRANSFOMER 140kHz typ FOR RESONANCE Vsus Vsus SS11 Vsus P_S1 Vsus PFC OVP ERROR DET PHOTO P_S0 COUPLER S0_S1 CIRCUIT ERROR DET PHOTO COUPLER PHOTO...

  • Page 43: Block (4/4) Diagram

    11.5. Block (4/4) Diagram SCAN DRIVE SCAN OUT (UPPER) SUSTAIN DRIVE Reference Voltage IC14601-03 TPVSUS Vsus Lo : 213V Vsus Hi : 218V IC16784,85 Reference Voltage Vsus Vad = 200 PC16897 Reference Voltage PDP SCAN TPVSUS Vsus Lo : 213V IPD CIRCUIT DRIVER TPVAD...

  • Page 45: Wiring Connection Diagram

    12 Wiring Connection Diagram 12.1. Caution statement. Caution: Please confirm that all flexible cables are assembled correctly. Also make sure that they are locked in the connectors. Verify by giving the flexible cables a very slight pull. 12.2. Wiring (1)

  • Page 46: Wiring (2)

    12.3. Wiring (2) 12.4. Wiring (3)
  • Page 47 Model No. : TX-P50VT50B/Y,PR50VT50 Schematic Diagram Note...
  • Page 48 Model No. : TX-P50VT50B/Y,PR50VT50 Replacement Parts List Note...
  • Page 49 Model No. : TX-P50VT50B/Y,PR50VT50 A-Board (1/14)
  • Page 50 Model No. : TX-P50VT50B/Y,PR50VT50 A-Board (2/14)
  • Page 51 Model No. : TX-P50VT50B/Y,PR50VT50 A-Board (3/14)
  • Page 52 Model No. : TX-P50VT50B/Y,PR50VT50 A-Board (4/14)
  • Page 53 Model No. : TX-P50VT50B/Y,PR50VT50 A-Board (5/14)
  • Page 54 Model No. : TX-P50VT50B/Y,PR50VT50 A-Board (6/14)
  • Page 55 Model No. : TX-P50VT50B/Y,PR50VT50 A-Board (7/14)
  • Page 56 Model No. : TX-P50VT50B/Y,PR50VT50 A-Board (8/14) and K-Board S-10...
  • Page 57 Model No. : TX-P50VT50B/Y,PR50VT50 A-Board (9/14) S-11...
  • Page 58 Model No. : TX-P50VT50B/Y,PR50VT50 A-Board (10/14) S-12...
  • Page 59 Model No. : TX-P50VT50B/Y,PR50VT50 A-Board (11/14) S-13...
  • Page 60 Model No. : TX-P50VT50B/Y,PR50VT50 A-Board (12/14) S-14...
  • Page 61 Model No. : TX-P50VT50B/Y,PR50VT50 A-Board (13/14) S-15...
  • Page 62 Model No. : TX-P50VT50B/Y,PR50VT50 A-Board (14/14) S-16...
  • Page 63 Model No. : TX-P50VT50B/Y,PR50VT50 C1-Board (1/2) S-17...
  • Page 64 Model No. : TX-P50VT50B/Y,PR50VT50 C1-Board (2/2) S-18...
  • Page 65 Model No. : TX-P50VT50B/Y,PR50VT50 C2-Board S-19...
  • Page 66 Model No. : TX-P50VT50B/Y,PR50VT50 C3-Board S-20...
  • Page 67 Model No. : TX-P50VT50B/Y,PR50VT50 SC-Board (1/3) S-21...
  • Page 68 Model No. : TX-P50VT50B/Y,PR50VT50 SC-Board (2/3) S-22...
  • Page 69 Model No. : TX-P50VT50B/Y,PR50VT50 SC-Board (3/3) S-23...
  • Page 70 Model No. : TX-P50VT50B/Y,PR50VT50 SS-Board (1/2) S-24...
  • Page 71 Model No. : TX-P50VT50B/Y,PR50VT50 SS-Board (2/2) and SS2-Board S-25...
  • Page 72 Model No. : TX-P50VT50B/Y,PR50VT50 A-Board (Foil side) S-26...
  • Page 73 Model No. : TX-P50VT50B/Y,PR50VT50 A-Board (Component side) S-27...
  • Page 74 Model No. : TX-P50VT50B/Y,PR50VT50 K-Board S-28...
  • Page 75 Model No. : TX-P50VT50B/Y,PR50VT50 C1-Board S-29...
  • Page 76 Model No. : TX-P50VT50B/Y,PR50VT50 C2-Board S-30...
  • Page 77 Model No. : TX-P50VT50B/Y,PR50VT50 C3-Board S-31...
  • Page 78 Model No. : TX-P50VT50B/Y,PR50VT50 SC-Board (Foil side) S-32...
  • Page 79 Model No. : TX-P50VT50B/Y,PR50VT50 SC-Board (Component side) S-33...
  • Page 80 Model No. : TX-P50VT50B/Y,PR50VT50 SS-Board (Foil side) S-34...
  • Page 81 Model No. : TX-P50VT50B/Y,PR50VT50 SS-Board (Component side) S-35...
  • Page 82 Model No. : TX-P50VT50B/Y,PR50VT50 SS2-Board S-36...
  • Page 83 Model No. : TX-P50VT50B/Y,PR50VT50 Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks A-PR50VT50 CIRCUIT BOARD A 1 (PR) (RTL)PAVCCZ A-P50VT50B CIRCUIT BOARD A 1 (B) (RTL)PAVCCZ A-P50VT50Y CIRCUIT BOARD A 1 (Y) (RTL)PAVCCZ TXN/K1SUUE CIRCUIT BOARD K 1 (RTL)PAVCCZ N0AE6KL00010 CIRCUIT BOARD P...
  • Page 84 Model No. : TX-P50VT50B/Y,PR50VT50 Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks C3037 F1G1A105A047 C 1UF 10V C3063 F1G1C104A077 C 0.1UF 16V C3065 F1J1A106A087 C 10UF, 10V C3083 F1J1A106A110 C 10UF, 10V 1 PAVCCZ C3084 F1J1A106A110 C 10UF, 10V 1 PAVCCZ C3085...
  • Page 85 Model No. : TX-P50VT50B/Y,PR50VT50 Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks C5003 F1H1C105A145 C 1 uF 16 V C5007 F1G1C104A077 C 0.1UF 16V C5009 F1G1C104A077 C 0.1UF 16V C5011 F1G1C104A077 C 0.1UF 16V C5012 EEEHB1C101UP C 100PF, J, 16V C5013 F1G1A105A047...
  • Page 86 Model No. : TX-P50VT50B/Y,PR50VT50 Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks C6915 F1G1C104A077 C 0.1UF 16V C6916 F1J1A106A110 C 10UF, 10V 1 PAVCCZ C6917 F1G1C104A077 C 0.1UF 16V C8002 F1J1A106A087 C 10UF, 10V C8003 F1J1A106A087 C 10UF, 10V C8006 F1G1C104A077...
  • Page 87 Model No. : TX-P50VT50B/Y,PR50VT50 Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks C8236 F1G1C104A077 C 0.1UF 16V C8237 F1J1A106A087 C 10UF, 10V C8238 F1G1C104A077 C 0.1UF 16V C8240 F1G1C104A077 C 0.1UF 16V C8242 F1G1C104A077 C 0.1UF 16V C8245 F1G1C104A077 C 0.1UF 16V...
  • Page 88 Model No. : TX-P50VT50B/Y,PR50VT50 Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks C8643 F1G1C104A077 C 0.1UF 16V C8644 F1G1C1030008 C 0.01UF 16V C8645 F1G1C104A077 C 0.1UF 16V C8646 F1G1C104A077 C 0.1UF 16V C8647 EEEHB0J221UP E 220UF, 6.3V C8648 F1G1C104A077 C 0.1UF 16V...
  • Page 89 Model No. : TX-P50VT50B/Y,PR50VT50 Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks C9122 F1G1A105A047 C 1UF 10V C9123 F1G1A105A047 C 1UF 10V C9222 F1K1E106A134 C 10UF, 25V C9235 ECJ1VB1E104K C 0.1 UF, 25V C9237 F1K0J226A049 C 22UF, 6.3V C9238 F1K0J226A049 C 22UF, 6.3V...
  • Page 90 Model No. : TX-P50VT50B/Y,PR50VT50 Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks C9413 F1J1A106A110 C 10UF, 10V 1 PAVCCZ C9415 F1J1A106A110 C 10UF, 10V 1 PAVCCZ C9416 F1G1C104A077 C 0.1UF 16V C9417 F1J1A106A110 C 10UF, 10V 1 PAVCCZ C9418 F1G1C104A077...
  • Page 91 Model No. : TX-P50VT50B/Y,PR50VT50 Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks IC5702 C0DBGYY00887 IC5703 C0CBCYY00043 IC5704 C0DBEYY00175 IC6851 C1AB00003807 1 PAVCCZ IC6900 C1AB00003808 1 PAVCCZ IC8000 MN2WS0235E 1 PAVCCZ IC8100 C0DBAYY01286 1 PAVCCZ IC8101 C0DBAYY01284 1 PAVCCZ IC8200 C3ABUY000019 1 PAVCCZ...
  • Page 92 Model No. : TX-P50VT50B/Y,PR50VT50 Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks L4901 G1C100MA0533 INDUCTION COIL 1 PAVCCZ L4902 G1C100MA0533 INDUCTION COIL 1 PAVCCZ L4903 G1C100MA0533 INDUCTION COIL 1 PAVCCZ L4904 G1C100MA0533 INDUCTION COIL 1 PAVCCZ L4905 G1C150MA0533 INDUCTION COIL...
  • Page 93 Model No. : TX-P50VT50B/Y,PR50VT50 Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks Q2810 B1ABCE000015 TRANSISTOR Q2811 B1ABCE000015 TRANSISTOR Q2812 B1ABCE000015 TRANSISTOR Q3008 B1ADCF000194 TRANSISTOR Q3051 B1ABCE000015 TRANSISTOR Q3102 B1ABKE000001 TRANSISTOR 1 PAVCCZ Q3103 B1ABKE000001 TRANSISTOR 1 PAVCCZ Q3304 B1ADCF000194 TRANSISTOR...
  • Page 94 Model No. : TX-P50VT50B/Y,PR50VT50 Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks R1365 D0GA103JA023 M10KOHM, J.1/16 W R1366 D0GA103JA023 M10KOHM, J.1/16 W R1367 D0GA103JA023 M10KOHM, J.1/16 W R1368 D0GA103JA023 M10KOHM, J.1/16 W R1372 D0GA103JA023 M10KOHM, J.1/16 W R1373 D0GA103JA023 M10KOHM, J.1/16 W...
  • Page 95 Model No. : TX-P50VT50B/Y,PR50VT50 Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks R3001 D1BA1403A023 M 140 KOHM,F.1/16 W 1 PAVCCZ R3002 D1BA1403A023 M 140 KOHM,F.1/16 W 1 PAVCCZ R3061 D0GA221JA023 M220 OHM, J.1/16 W R3062 D0GA103JA023 M10KOHM, J.1/16 W R3063 D0GA103JA023...
  • Page 96 Model No. : TX-P50VT50B/Y,PR50VT50 Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks R4709 D0GA103JA023 M10KOHM, J.1/16 W R4710 D1HY4734A012 NETWORK RESISTER 1 PAVCCZ R4711 D0GA102JA023 M1KOHM, J.1/16 W R4715 D0GA103JA023 M10KOHM, J.1/16 W R4721 D0GA103JA023 M10KOHM, J.1/16 W R4722 D0GA103JA023 M10KOHM, J.1/16 W...
  • Page 97 Model No. : TX-P50VT50B/Y,PR50VT50 Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks R6732 D0GA103JA023 M10KOHM, J.1/16 W R6739 D0GAR00J0005 M 0 OHM, 1/16W R6740 D0GAR00J0005 M 0 OHM, 1/16W R6741 D0GA681JA023 M680 OHM, J,1/16W R6742 D0GA681JA023 M680 OHM, J,1/16W R6851 D1BA1622A023...
  • Page 98 Model No. : TX-P50VT50B/Y,PR50VT50 Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks R8262 D1HY4704A012 NETWORK RESISTER 1 PAVCCZ R8263 D0GA220JA023 M22 OHM, J.1/16 W R8300 D0GA471JA023 M 470OHM, J,1/16W R8301 D0GA360JA023 M 36 OHM, J,1/16W R8302 D0GA360JA023 M 36 OHM, J,1/16W R8303...
  • Page 99 Model No. : TX-P50VT50B/Y,PR50VT50 Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks R8639 D0GA103JA023 M10KOHM, J.1/16 W R8640 D0GA103JA023 M10KOHM, J.1/16 W R8643 D0GA272JA023 M 2.7KOHM, J.1/16W R8645 D0GA272JA023 M 2.7KOHM, J.1/16W R8649 D0GA104JA023 M100KOHM, J.1/16 W R8650 D0GA472JA023 M 4.7KOHM, J,1/16W...
  • Page 100 Model No. : TX-P50VT50B/Y,PR50VT50 Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks R8788 D0GA102JA023 M1KOHM, J.1/16 W R8792 D0GA103JA023 M10KOHM, J.1/16 W R8797 D1BA1302A023 M 13KOHM,F,1/16W 1 PAVCCZ R8798 D1BA1002A023 M 10KOHM,F,1/16W 1 PAVCCZ R8799 D1BA3742A023 M 37.4 KOHM,F.1/16 W 1 PAVCCZ R8817...
  • Page 101 Model No. : TX-P50VT50B/Y,PR50VT50 Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks R9404 D1HY1038A012 NETWORK RESISTER 1 PAVCCZ R9405 D1HY6808A012 NETWORK RESISTER 1 PAVCCZ R9503 D0GA103JA023 M10KOHM, J.1/16 W R9608 D1HY2208A012 NETWORK RESISTER 1 PAVCCZ R9610 D1HY2208A012 NETWORK RESISTER 1 PAVCCZ...
  • Page 102 Model No. : TX-P50VT50B/Y,PR50VT50 Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks C16195 F1K1E105A029 C 1UF, 25V C16201 F0C2E225A307 C 2.2UF, 250V 1 PAVCCZ C16202 F0C2E225A307 C 2.2UF, 250V 1 PAVCCZ C16242 F1H1C105A145 C 1 uF 16 V C16243 ECJ1VB1H103K C 0.01UF, 50V C16244 F1J1A106A087...
  • Page 103 Model No. : TX-P50VT50B/Y,PR50VT50 Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks C16753 F1K1E105A029 C 1UF, 25V C16770 F1H1C105A145 C 1 uF 16 V C16791 F2A1E151B705 E 150UF, 25V C16793 F2A1E151B705 E 150UF, 25V C16794 F1J1A106A087 C 10UF, 10V C16795 F2A1E151B705 E 150UF, 25V...
  • Page 104 Model No. : TX-P50VT50B/Y,PR50VT50 Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks C17363 F1L2E224A028 C 0.22UF, 250V C17364 ECJ1XB1C104K C 0.1UF, Z, 16V K1MY55B00001 55P CONNECTOR K1MY55B00001 55P CONNECTOR K1MY55B00001 55P CONNECTOR K1MY55B00001 55P CONNECTOR K1MY55B00001 55P CONNECTOR K1MY55B00001 55P CONNECTOR...
  • Page 105 Model No. : TX-P50VT50B/Y,PR50VT50 Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks D16482 B0FCCN000005 DIODE 1 PAVCCZ D16506 DZ2J051M0L ZENER DIODE D16534 DZ2J051M0L ZENER DIODE D16536 B0ECKP000055 DIODE D16581 DZ2J330M0L ZENER DIODE D16582 DZ2J330M0L ZENER DIODE D16583 B3ABB0000381 1 PAVCCZ D16601 DZ2J051M0L...
  • Page 106 Model No. : TX-P50VT50B/Y,PR50VT50 Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks HS16600 K4AZ02D00004 TERMINAL 1 PAVCCZ HS16621 K4AZ02D00004 TERMINAL 1 PAVCCZ HS16622 K4AZ02D00004 TERMINAL 1 PAVCCZ HS16624 K4AZ02D00004 TERMINAL 1 PAVCCZ HS16625 K4AZ02D00004 TERMINAL 1 PAVCCZ HS16626 K4AZ02D00004 TERMINAL 1 PAVCCZ...
  • Page 107 Model No. : TX-P50VT50B/Y,PR50VT50 Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks PC16723 B3PBA0000580 PC16896 B3PBA0000580 PC16897 B3PBA0000580 Q16002 B1JBDN000005 TRANSISTOR 1 PAVCCZ Q16004 B1JBDN000005 TRANSISTOR 1 PAVCCZ Q16021 B1JBDN000005 TRANSISTOR 1 PAVCCZ Q16022 B1JBDN000005 TRANSISTOR 1 PAVCCZ Q16024 B1JBDN000005 TRANSISTOR...
  • Page 108 Model No. : TX-P50VT50B/Y,PR50VT50 Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks R16101 D0GD150JA059 M 15 OHM,J,1/4W R16102 D0GD150JA059 M 15 OHM,J,1/4W R16105 D0GF474JA048 M 470KOHM,J,1/3W R16109 D0GD100JA059 M 10 OHM,J,1/4W R16116 D0GB473JA065 M 47KOHM J. 1/10W R16130 D0GB103JA065 M 10K OHM J 1/10W R16132 D0GB220JA065...
  • Page 109 Model No. : TX-P50VT50B/Y,PR50VT50 Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks R16466 D0GF473JA048 M 47KOHM,J,1/3W R16467 D0GF473JA048 M 47KOHM,J,1/3W R16471 D0GB203JA065 M 20KOHM J 1/10W R16472 D0GB222JA065 M 2.2KOHM,J,1/10W R16473 D0GD561JA052 M 560 OHM,J,1/8W R16474 D0GB102JA065 M 1KOHM,J,1/10W R16475 D0GB472JA065 M 4.7KOHM, J,1/10W...
  • Page 110 Model No. : TX-P50VT50B/Y,PR50VT50 Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks R16666 D1BB1003A074 M 100 KOHM,F.1/10 W 1 PAVCCZ R16674 D0GF102JA047 M 1.0 KOHM,J,1/3W R16675 D0GB103JA065 M 10K OHM J 1/10W R16676 D1BD2700A066 M 270KOHM,F.1/8W 1 PAVCCZ R16678 D0GF102JA047 M 1.0 KOHM,J,1/3W...
  • Page 111 Model No. : TX-P50VT50B/Y,PR50VT50 Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks R16931 D1BF2R70A073 M 2.7 OHM,F.1/8W 1 PAVCCZ R16932 D0GD223JA052 M 22KOHM,J,1/8W R16937 D0GB184JA065 M 180KOHM J 1/10W R16939 D0GB472JA065 M 4.7KOHM, J,1/10W R16940 D0GB472JA065 M 4.7KOHM, J,1/10W R16945 D0GB471JA065 M 470 OHM,J,1/10W...
  • Page 112 Model No. : TX-P50VT50B/Y,PR50VT50 Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks R17243 D0GD224JA052 M 220KOHM,J,1/8W R17245 D1H84704A041 NETWORK RESISTER 1 PAVCCZ R17262 D1H86814A041 NETWORK RESISTER 1 PAVCCZ R17263 D0GB681JA065 M 680 OHM,J,1/10W R17264 D0GB681JA065 M 680 OHM,J,1/10W R17311 D0GB101JA065 M 100 OHM,J,1/10W R17312 D0GB101JA065...
  • Page 113 Model No. : TX-P50VT50B/Y,PR50VT50 Exploded View 1 S-67...
  • Page 114 Model No. : TX-P50VT50B/Y,PR50VT50 Exploded View 2 S-68...
  • Page 115 Model No. : TX-P50VT50B/Y,PR50VT50 Packing 1 S-69...
  • Page 116 Model No. : TX-P50VT50B/Y,PR50VT50 Packing 2 S-70...
  • Page 117 Model No. : TX-P50VT50B/Y,PR50VT50 Packing 3 S-71...
  • Page 118 Model No. : TX-P50VT50B/Y,PR50VT50 Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks BAT-C-0715 Battery Cover of RC 1 PAVCCZ EAK1H04AL SPEAKER_SC(L) 1 PAVCCZ EAK1H04AR SPEAKER_SC(R) 1 PAVCCZ J0KG00000011 FERRITE CORE J0KG00000036 FERRITE CORE FOR AV2 COMPONENT CABLE 1 PAVCCZ J0KG00000146 FERRITE CORE PACK FOR LAN CABLE...
  • Page 119 Model No. : TX-P50VT50B/Y,PR50VT50 Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks TPE5ZB024 BAG (PEDESTAL STAND) 1 PAVCCZ TPE5ZB025 BAG (STAND ACCESSORY NECK) 1 PAVCCZ TPE5ZB027 BAG (STAND METAL COVER) 1 PAVCCZ TPG0E9860 PAPER CAP 0.2 PAVCCZ TQB0E2250 INSTRUCTION BOOK(ENGLISH) 1 (B) PAVCCZ...

This manual is also suitable for:

Tx-p50vt50yTx-p50vt50b
