1 Safety Precautions 1.1. General Guidelines 1. When conducting repairs and servicing, do not attempt to modify the equipment, its parts or its materials. 2. When wiring units (with cables, flexible cables or lead wires) are supplied as repair parts and only one wire or some of the wires have been broken or disconnected, do not attempt to repair or re-wire the units.
2 Warning 2.1. Prevention of Electrostatic Discharge (ESD) to Electrostatically Sensitive (ES) Devices Some semiconductor (solid state) devices can be damaged easily by static electricity. Such components commonly are called Elec- trostatically Sensitive (ES) Devices. Examples of typical ES devices are integrated circuits and some field-effect transistors and semiconductor [chip] components.
2.2. About lead free solder (PbF) Note: Lead is listed as (Pb) in the periodic table of elements. In the information below, Pb will refer to Lead solder, and PbF will refer to Lead Free Solder. The Lead Free Solder used in our manufacturing process and discussed below is (Sn+Ag+Cu). That is Tin (Sn), Silver (Ag) and Copper (Cu) although other types are available.
3 Service Navigation 3.1. PCB Layout Board Name Function Board Name Function Power Supply Data Driver (Lower Right) DC-DC Converter, Tuner Data Driver (Lower Left) Speaker out, AV Terminal, HDMI in, SD Card Scan Drive Digital Signal Processor, PEAKS-sLD Sustain Drive Format Converter, Plasma AI, Sub-Field Processor Scan out Key Switch...
Countries that DVB-C is available: Germany, Switzerland, Denmark, Sweden, Norway, Finland, Netherlands • Check the latest information on the available services at the following website. (English only) http://panasonic.jp/support/global/cs/ Receiving Systems / Band name (R) PAL D, K, SECAM D, K...
Page 9
HDMI2 : HDMI (Version 1.4 with Audio Return Channel) and HDMI (Version 1.3a with x.v.Colour.) • This TV supports [ HDAVI Control 5 ] function. SD Card slot × 1 Card slot Common Interface slot × 1 Output DIGITAL AUDIO OUT PCM / Dolby Digital / DTS, Fiber optic Dimensions (W ×...
3 seconds. TV will be forced to the factory shipment setting after this SELF CHECK. 5.1.3. Model and Keys: Model No. Keys CI Plus DTCP-IP One-to-One (For USB Rec.) TX-P37C2B None None None TX-P37C2E None None TX-PR37C2 None None...
6 Service Mode 6.1. How to enter into Service Mode While pressing [VOLUME ( - )] button of the main unit, press [0] button of the remote control three times within 2 seconds. 6.1.1. Key command [1] button...Main items Selection in forward direction [2] button...Main items Selection in reverse direction [3] button...Sub items Selection in forward direction [4] button...Sub items Selection in reverse direction...
Page 12
6.1.2. Contents of adjustment mode • Value is shown as a hexadecimal number. • Preset value differs depending on models. • After entering the adjustment mode, take note of the value in each item before starting adjustment. 6.1.3. How to exit Switch off the power with the [POWER] button on the main unit or the [POWER] button on the remote control.
6.2. Option - Mirror Picture can be reversed left and right or up and down. 00 : Default (Normal picture is displayed) 01 : Picture is reversed left and right. 02 : Picture is reversed up and down. Hint : If the defective symptom (e.g. Vertical bar or Horizontal bar) is moved by selection of this mirror, the possible cause is in A-board.
6.4. Hotel mode 1. Purpose Restrict a function for hotels. item Function 2. Access command to the Hotel mode setup menu Hotel Mode Select hotel mode ON/OFF In order to display the Hotel mode setup menu, please Initial INPUT Select input signal modes. enter the following command (within 2 second).
6.5. Data Copy by SD Card 6.5.1. Purpose (a) Board replacement (Copy the data when exchanging A-board): When exchanging A-board, the data in original A-board can be copied to SD card and then copy to new A-board. (b) Hotel (Copy the data when installing a number of units in hotel or any facility): When installing a number of units in hotel or any facility, the data in master TV can be copied to SD card and then copy to other TVs.
Page 16
6.5.3. Data copy from TV set to SD Card 1. Turn on the TV set. 2. Insert SD card with a startup file (pwd file) to SD slot. On-screen Display will be appeared according to the startup file automatically. 3. Input a following password for (a) or (b) by using remote control. (a) For Board replacement : 2770 (b) For Hotel : 4850 Data will be copied from TV set to SD card.
Page 17
6.5.4. Data copy from to SD Card to TV set 1. Turn on the TV set. 2. Insert SD card with Data to SD slot. On-screen Display will be appeared according to the Data folder automatically. 3. Input a following password for (a) or (b) by using remote control. (a) For Board replacement : 2771 (b) For Hotel : 4851 Data will be copied from SD card to TV set.
7 Troubleshooting Guide Use the self-check function to test the unit. 1. Checking the IIC bus lines 2. Power LED Blinking timing 7.1. Check of the IIC bus lines 7.1.1. How to access 7.1.1.1. Self-check indication only: Produce TV reception screen, and while pressing [VOLUME ( - )] button on the main unit, press [OK] button on the remote control for more than 3 seconds.
7.2. Power LED Blinking timing chart 1. Subject Information of LED Flashing timing chart. 2. Contents When an abnormality has occurred the unit, the protection circuit operates and reset to the stand by mode. At this time, the defective block can be identified by the number of blinks of the Power LED on the front panel of the unit.
7.3. No Power First check point There are following 3 states of No Power indication by power LED. 1. No lit. 2. Green is lit then turns red blinking a few seconds later. (See 7.2.) 3. Only red is lit.
8 Service Fixture & Tools 8.1. SC jig Purpose: To find the failure board (SC) when the power LED is blinking 7 times. SC jig: Jumper connector to connect to SC50 connector on SC board Part number: TZSC09187 How to use: Caution: Remove SC jig from SC board after inspection.
9 Disassembly and Assem- 9.4. Remove Side terminal cover and the Side shield metal bly Instructions , ×1 , ×1 1. Remove the screws (×2 2. Remove the Side terminal cover. 9.1. Remove the Rear cover 1. See PCB Layout (Section 3) 9.2.
9.5. Remove the Tuner unit 9.7. Remove the Speakers 1. Remove the Side terminal cover and the Side shield 1. Unlock the cable clampers to free the cable. metal. (See section 9.4.) 2. Disconnect the Speaker terminal. 2. Unlock the cable clampers to free the cable. 3.
9.9. Remove the SC-Board 9.11. Remove the Hanger metals and the Stand brackets 1. Remove the SM-Board. (See section 9.8.) 2. Disconnect the connectors (SC2 and SC3). 1. Remove the Plasma panel section from the servicing 3. Disconnect the flexible cable (SC20). stand and lay on a flat surface such as a table (covered 4.
9.12. Remove the C1-Board 9.14. Remove the S-Board 1. Remove the Hanger metal R and the Stand bracket R. 1. Remove the screws (×2 ) and remove the S-Board (See section 9.10.) unit. 2. Remove the flexible cable holder fastening screws (×8 3.
9.15. Remove the Plasma panel sec- 9.16. Remove the Glass holders tion from the Cabinet assy 1. Remove the Cabinet assy. (See section 9.15.) 2. Remove the screws (×4 (glass) 3. Remove the Glass holder side (L, R). 1. Remove the plasma panel fastening screws (×3 ) and 4.
9.18. Replace the plasma panel Caution: A new plasma panel itself without Hanger metals is fragile. To avoid the damage to new plasma panel, carry a new plasma panel taking hold of the Hanger metals after assembling the Hanger metals and the Stand brackets. 1.
10 Measurements and Adjustments 10.1. Adjustment 10.1.1. Vsus selection Caution: When Plasma panel or A-board is replaced, Vsus should be set to LOW or HIGH. Procedure 1. Go into main item [VSUS] in Service Mode. LOW or HIGH will be displayed. 2.
Page 31
10.1.2. Sub-Contrast adjustment Name of measuring instrument Connection Remarks RF generator Base Band signal generator HD signal generator Steps Remarks Adjustment of TV (RF system) Ref.: RF signal modulation spec. Note: B models: 80% In adjustment, you must setting to modulation of signal at 80%. Other models: 90% 1.
Page 32
Steps Remarks Another procedure Adjustment of AV system 1. PAL 100% Full White or Split Colour bar receive AV1(or AV2), shown as below. 2. Goes into service adjustment mode. 3. Push [ 1 ] or [ 2 ] key, and goes into adjustment mode for [ Contrast ]. Adjustment 1.
Page 33
10.1.3. White balance adjustment Name of measuring instrument Connection Remarks W/ B pattern Panel surface Color analyzer (Minolta CA-100 or equivalent) Steps Remarks • Make sure the front panel to be used on the final set is fitted. Picture menu : Dynamic •...
11.3. Block (2/4) Diagram DIGITAL SIGNAL PROCESSOR IC9300 VIDEO DATA PLASMA AI VIDEO DATA LVDS DATA CPG with SS H/V Sync Control VIDEO DATA Sub Filed Processor P+3.3V IC9304 P+3.3V ADDR/DATA FLASH IIC0 FLASH I/F MEMORY P_S0 CONTROL DATA P_S0 P_S1 DISCHARGE CONTROL P_S1...
12 Wiring Connection Diagram 12.1. Caution statement. Caution: Please confirm that all flexible cables are assembled correctly. Also make sure that they are locked in the connectors. Verify by giving the flexible cables a very slight pull. 12.2. Wiring (1) 12.3.
13.10. A-Board (5/19) Schematic Diagram A-BOARD (5/19) CI SLOT,SD CARD,FLASH MEMORY FLASH CI CONNECTOR USE Adress Data Multi PleX NOR & NAND USE USE LO HEIGHT DeMPX ED[15-0] --> EA[23-8] R8918 EXB2HV680JV AA_ED0 AA_ED0 AA_ED0 AA_ED1 AA_ED1 JK8940 AA_ED1 AA_ED2 AA_ED2 AA_ED2 K1NA68B00054...
14.2. K and S-Board S-BOARD (FOIL SIDE) K-BOARD (FOIL SIDE) TNPA4858AB TXN/K1LGUE T N P A 4 8 5 8 P b F S E E R E V E R S E T P 0 2 F O R O R D E R N O . T P 0 3 CR25 S W 2 5 0 0...
14.4. C1-Board C1-BOARD (FOIL SIDE) TXNC111EFK CMM11 TNPA5073 1 C1 P b F 1 2 3 S E E R E V E R S E F O R O R D E R N O . C1-BOARD (COMPONENT SIDE) TXNC111EFK I C 1 0 1 R 1 2 4...
14.5. C2-Board C2-BOARD (FOIL SIDE) TXNC211EFK CMM21 P b F TNPA5074 1 C2 1 2 3 S E E R E V E R S E F O R O R D E R N O . C2-BOARD (COMPONENT SIDE) TXNC211EFK I C 2 0 2 F L 2 0 1...
14.6. SC-Board SC-BOARD (FOIL SIDE) TXNSC11EFK T P 6 0 T P 6 1 R 6 9 6 SC42 T P 5 1 SC46 TNPA5062 S E E R E V E R S E F O R O R D E R N O . T P 1 1 6 T P 5 8 1 SC...
Page 86
SC-BOARD (COMPONENT SIDE) TXNSC11EFK H.V. DANGER H.V. DANGER H.V. DANGER H.V. DANGER Z A 4 2 2 Z A 4 2 1 Z A 4 1 2 Z A 4 1 1 C 4 6 4 TNPA5062 SC46 P b F SC CRNo.16 SC42 O R D E R N O .
14.7. SS-Board SS-BOARD (FOIL SIDE) TXNSS11EFK C 2 4 1 C 1 9 3 L 0 1 4 L 0 1 3 L 0 1 2 L 3 0 3 L 0 1 1 C R N o . 1 6 L 1 0 3 T P 6 6 T N P A 5 0 7 2...
Page 88
SS-BOARD (COMPONENT SIDE) TXNSS11EFK C 2 4 4 R 1 3 1 R 1 3 5 C 1 0 6 C 1 0 5 R 1 3 6 C 2 4 2 R 1 9 1 C 1 0 4 D 1 3 1 C 1 0 3 C 3 2 8...
Page 93
15.1.5. Mechanical Replacement Parts List...
Page 94
N2QAYB000487 REMOTE CONTROL 1 PAVCCZ TBLA3689 STAND POLE R TBLA3690 STAND POLE L TBLX0136 PEDESTAL STAND (SQUARE GB) 1 PAVCCZ TBMA339 PANASONIC SHEET BADGE TBX3EA00201 POWER BUTTON 1 PAVCCZ THEJ0339 SCREW (BC-TUNER:1 SIDE_COVER:2) THEL0429 SCREW THEL052Z SCREW (BC TOP:4) THEL079N...
Page 95
Ref. Safety Part No. Part Name & Description Q'ty Remarks TPDX0016-1 JOINT FOR PEDESTAL TPE0E4047 SET BAG 1 PAVCCZ TPE0E9002 ACCESSORIES BAG 1 PAVCCZ TPE0E9003 BAG FOR AC CORD 1 PAVCCZ TPEB341 STAND ACCESSORY BAG TPEB423 BAG (PEDESTAL STAND) TPG0E9331 PAPER CAP 0.25 PAVCCZ TQB0E0908...
Page 96
Ref. Safety Part No. Part Name & Description Q'ty Remarks TXFEA01LWUE SPEAKER ASSY 2 PAVCCZ TXFKP01LDUE SIDE TERMINAL COVER ASSY 1 PAVCCZ TXFKY01LDUE CABINET ASSY 1 PAVCCZ TXJA11LFUE SPEAKER LEAD (A11-SPL/SPR) 1 PAVCCZ XSB3+6FJ SCREW(HDMI:3) XTB4+12GFJ SCREW(GH:20 PW:2 LED:1) XTB4+12GFJK SCREW(BC:11) XTV3+10JFJK SCREW(REAR AV:2)
15.2. Electrical Replacement Parts List 15.2.1. Replacement Parts List Notes...
Page 98
15.2.2. Electrical Replacement Parts List Safety Ref. No. Part No. Part Name & Pcs Remarks Description Safety Ref. No. Part No. Part Name & Pcs Remarks C2324 F1J1E105A231 C 1 UF 25V Description C2325 F1G1H102A730 C 1000UF, 50V C2334 F1J1H474A757 C 0.47UF, 50V LSEP1287LDHB CIRCUIT BOARD P (RTL)PA C2335...
Page 99
Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description C3021 ECJ1VB1A105K C 0.01UF, Z, 10V C5101 F1H1A474A084 C 0.47UF, 50V C3022 ECJ1VB1A105K C 0.01UF, Z, 10V C5155 F1J0J106A004 C 0.010UF, K, C3023 ECJ1VB1A105K C 0.01UF, Z, 10V...
Page 100
Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description C8017 F1G1C104A116 C 0.10UF, K, 16V C8126 F1J1A106A087 C 0.010UF, K, C8019 F1G1C104A116 C 0.10UF, K, 16V C8127 ECJ1VB0J105K C 1UF, K, 6.3V C8020 F1G1C104A116 C 0.10UF, K, 16V...
Page 101
Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description C9308 F1G1C104A116 C 0.10UF, K, 16V C9311 F1G1C104A116 C 0.10UF, K, 16V D1101 B0JCCE000008 DIODE C9312 F1J1A106A087 C 0.010UF, K, D2014 B0ACCJ000048 DIODE D2520...
Page 102
Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description JK3107A K4AK04B00002 TERMINAL BOARD L8400 J0JHC0000045 CHIP INDUCTOR L8401 J0JHC0000045 CHIP INDUCTOR K1KA05B00219 5P CONNECTOR L8850 J0JHC0000045 CHIP INDUCTOR L8920 J0JHC0000075 CHIP INDUCTOR L2301...
Page 103
Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description R0949 D0GA222JA015 M 2.2KOHM, R2260 ERJ2GEJ103 M 10KOHM, J,0.063W J,0.063W R0957 ERJ2GEJ102X M 1K OHM J 1/4W R2263 ERJ2GEJ103 M 10KOHM, J,0.063W...
Page 104
Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description R3108 D0GA101JA015 M 100 OHM, R4551 D0GA151JA015 M 150 OHM, J,0.063W J,0.063W R3120 EXB28V221J RESISTOR ARRAY R4552 D0GA560JA015 M 56 OHM, J,0.063W R3129 ERJ2GEJ104...
Page 105
Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description R5008 D0GA822JA015 M8.2KOHM, R5609 ERJ2GEJ103 M 10KOHM, J,0.063W J,0.063W R5050 D0GA473JA015 M 47KOHM, R5610 D0GA473JA015 M 47KOHM, J,0.063W J,0.063W R5051 D0GA473JA015 M 47KOHM,...
Page 106
Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description R8326 D0GA472JA015 M 4.7KOHM, R8457 ERJ2GEJ103 M 10KOHM, J,0.063W J,0.063W R8327 D0GA472JA015 M 4.7KOHM, R8462 EXB28V680JX RESISTOR ARRAY J,0.063W R8463 D0GA680JA015 M 68 OHM,...
Page 107
Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description R8618 ERJ2GEJ103 M 10KOHM, R8918 EXB2HV680J RESISTOR ARRAY J,0.063W R8919 EXB2HV680J RESISTOR ARRAY R8622 D0GA680JA015 M 68 OHM, R8920 D0GA222JA015 M 2.2KOHM, J,0.063W...
Page 108
Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description R9873 D1BB1002A055 M 10KOHM, 1/10W C16316 F1H1C104A143 C 0.1UF, K, 16V R9874 D1BB2702A055 M 27KOHM, 1/10W C16317 ECJ1VB1A105K C 0.01UF, Z, 50V R9875 D1BB2002A055 M 20KOHM, 1/10W C16318...
Page 109
Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description C16843 F1J1H104A835 C 0.10UF, 50V D16493 B0ADCJ000100 DIODE C16844 F1J1H104A835 C 0.10UF, 50V D16494 B0ADCJ000100 DIODE C16854 F1J1H104A835 C 0.10UF, 50V D16497 B0ECKP000055 DIODE C16856...
Page 110
Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description IC17203 C0JBAZ002692 IC Q16921 B1ABCN000007 TRANSISTOR Q16930 DSC2001Q0L TRANSISTOR L16011 G0ZZ00002183 PEAKING COIL Q16931 B1ABCN000007 TRANSISTOR L16012 G0ZZ00002183 PEAKING COIL Q16932 DSC2001Q0L TRANSISTOR...
Page 111
Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description R16416 D0GB103JA057 M 10K OHM J 1/ R16588 D0GB103JA057 M 10K OHM J 1/ R16417 ERJ6GEYJ101V M 100 OHM,J,1/ R16590 ERJ3GEYJ221 M 220 OHM,J,1/...
Page 112
Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description R16752 ERJ3GEYJ472 M 4.7KOHM,J,1/ R16929 ERJT08J1R0V M 1.8OHM,J, 0.33W R16753 ERJ6GEYF473 M 47KOHM,J,1/10W R16930 D1BF2R70A021 M 2.7 OHM, 1/10W R16755 ERJT06J273V M 27KOHM,J,0.25W...
Page 113
Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description R17220 D0GB101JA041 M 100 OHM,J,1/ C210 F2A1H4700057 E 47UF, 50V C211 F1J1E225A209 C 2.2 UF 25V R17221 D0GB101JA041 M 100 OHM,J,1/ C212 ECJ1VB1H102K C 1000PF, K, 50V C300...
Page 114
Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description C906 F1H1H222A219 C 2200PF, K, 50V IC902 C0DBZYY00360 IC C907 F1H1C105A148 C 1UF, K, 16V IC903 B3PBA0000459 IC C908 ECJ1VB1H102K C 1000PF, K, 50V IC904...
Page 115
Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description R119 D0GB103JA057 M 10K OHM J 1/ R417 D1AB6343A023 CHIP RESISTOR R418 ERJ6ENF1003 M 100KOHM, 1/10W R121 ERJ3GEYJ333 M 33KOHM,J,1/16W R500 ERJ6GEYG221...
Page 116
Safety Ref. No. Part No. Part Name & Pcs Remarks Safety Ref. No. Part No. Part Name & Pcs Remarks Description Description R704 ERJ6GEYJ100V M 10 OHM,J,1/10W R792 ERJ3GEY0R00 M 0 OHM, 1/16W R706 ERJ8ENF1500 M 150 OHM, 1/8W R793 ERJ3GEY0R00 M 0 OHM, 1/16W R707...
Page 117
Safety Ref. No. Part No. Part Name & Pcs Remarks Description T300 G4DYA0000194 SWITCHING TRANS- FORMER T301 ETS35LK11GAD SWITCHING TRANS- FORMER T400 ETS29AZ2YGAD SWITCHING TRANS- FORMER T900 ETS25AG11GAD SWITCHING TRANS- FORMER TP700 G0ZZ00002183 PEAKING COIL TP900 G0ZZ00002183 PEAKING COIL VR251 EVMAASA00B33 CONTROL 3KOHMB X600 H2B400400021 CRYSTAL...
