SERVICE MANUAL
Ver. 1.1 2011.05
• HCD-PZ1D is the Amplifi er, Inputs/Outputs,
Disc player and Tuner section in MHC-PZ1D.
Amplifier section
The following measured at AC 127 V, 220 V,
60 Hz (Brazilian model)
The following measured at AC 127 V, 60 Hz
(Mexican model)
The following measured at AC 120 V, 220 V,
240 V, 50/60 Hz (Other models)
Brazilian model:
Power output (rated):
135 W + 135 W (at 6 Ω, 1 kHz, 1%
THD, at LINK MODE)
RMS output power (reference):
Front speaker:
175 W + 175 W (per channel at 8 Ω,
1 kHz, 10% THD)
Satellite speaker:
70 W + 70 W (per channel at 24 Ω,
1 kHz, 10% THD)
Subwoofer:
210 W (at 6 Ω, 100 Hz, 10% THD)
Other models:
Power output (rated):
135 W + 135 W (at 6 Ω, 1 kHz, 1%
THD, at LINK MODE)
RMS output power (reference):
Front speaker:
210 W + 210 W (per channel at 8 Ω,
1 kHz)
Satellite speaker:
90 W + 90 W (per channel at 24 Ω,
1 kHz)
Subwoofer:
240 W (at 6 Ω, 100 Hz)
9-893-158-02
Sony Corporation
2011E05-1
©
2011.05
Published by Sony Techno Create Corporation
SPECIFICATIONS
Inputs
VIDEO/SAT VIDEO IN (phono jack):
1 Vp-p, 75 Ω
VIDEO/SAT AUDIO IN L/R (phono jacks):
voltage 250/450 mV, impedance
47 kΩ
MIC (phone jack):
sensitivity 1 mV, impedance 10 kΩ
Intelligent Pantilter Dock:
1 Vp-p, 75 Ω
Outputs
VIDEO OUT (phono jack):
max. output level 1 Vp-p, unbalanced,
Sync negative, load impedance 75 Ω
COMPONENT VIDEO OUT
Y: 1 Vp-p, 75 Ω
p-p, 75 Ω
p-p, 75 Ω
DVD DIGITAL OUT (Square optical
connector jack, rear panel):
Wavelength 650 nm
PHONES (stereo mini jack):
accepts headphones of 8 Ω or more
FRONT SPEAKERS:
Use only the supplied speaker
SS-GZR999D.
SATELLITE SPEAKERS:
Use only the supplied speaker
SS-RSZ999D.
SUBWOOFER:
Use only the supplied subwoofer
SS-WGR999D.
(USB) port: Type A
Maximum current: 500 mA
Intelligent Pantilter Dock:
Output voltage: DC 4.2 V
Maximum current: 1 A
HCD-PZ1D
Model Name Using Similar Mechanism
DVD Mechanism Type
Optical Pick-up Name
Disc player section
System:
Compact disc and digital audio and
video system
Laser Diode Properties
Emission Duration: Continuous
Laser Output*: Less than 44.6 μW
* This output is the value measurement
at a distance of 200 mm from the
objective lens surface on the Optical
Pick-up Block with 7 mm aperture.
Video color system format: NTSC
Tuner section
FM stereo, FM/AM superheterodyne tuner
FM tuner section
Tuning range
Brazilian model:
87.5 MHz
108.0 MHz (100 kHz
step)
Other models:
87.5 MHz
108.0 MHz (50 kHz step)
Antenna:
FM lead antenna
Antenna terminals:
75 Ω unbalanced
Intermediate frequency:
10.7 MHz
AM tuner section
Tuning range:
530 kHz
1,710 kHz (10 kHz step)
531 kHz
1,710 kHz (9 kHz step)
Antenna:
AM loop antenna
Antenna terminals:
External antenna terminal
Intermediate frequency:
450 kHz
E Model
NEW
CDM74HFVX-DVBU101
KHM-313CAB
General
Power requirements
Argentine model:
AC 220 V, 50/60 Hz
Brazilian model:
AC 127 V, 220 V, 60 Hz, adjustable
with voltage selector
Mexican model:
AC 127 V, 60 Hz
Other models:
AC 120 V, 220 V, 230 V
240 V,
50/60 Hz, adjustable with voltage
selector
Power consumption: 215 W
Dimensions (W/H/D) (excl. speakers):
Approx. 280 mm × 330 mm ×
430 mm
Mass (excl. speakers): Approx. 13.3 kg
Quantity of the main unit: 1 piece
Design and specifications are subject to
change without notice.
Standby power consumption: 0.5 W
DVD RECEIVER
