Sony VPL-X600U Service Manual
  1. Manuals
  2. Brands
  3. Sony Manuals
  4. Projector
  5. VPL-X600U Mk II
  6. Service manual

Sony VPL-X600U Service Manual

Lcd data projector
Hide thumbs Also See for VPL-X600U:
Table of Contents

Advertisement

Quick Links

Download this manual
SERVICE MANUAL
SERVICE MANUAL
MODEL
MODEL
...............
...............
VPL-X600U
VPL-X600E
VPL-X600M
IFB-X600E
VPL-X600U/X600E/X600M
IFB-X600E
RM-PJM600
PSS-600
DEST.
DEST.
CHASSIS NO.
CHASSIS NO.
.........
.........
....................
....................
US/CND
SCC-G61J-A
AEP/UK
SCC-G61G-A
E
SCC-G61J-A
AEP
MODEL
MODEL
...............
...............
RM-PJM600
PSS-600
Lcd Data Projector
Interface Board (FOR VPL-X600E/S600E)
Remote Commander
Projector Suspension
LCD DATA PROJECTOR
LCD DATA PROJECTOR
DEST.
DEST.
CHASSIS NO.
CHASSIS NO.
.........
.........
....................
....................
AEP
SCC-G62F-A
Australian SCC-N17A-A
Australian SCC-N17B-A

Advertisement

Table of Contents
loading

Related Manuals for Sony VPL-X600U

Summary of Contents for Sony VPL-X600U

  • Page 1 CHASSIS NO. DEST. DEST. CHASSIS NO. CHASSIS NO....................................VPL-X600U RM-PJM600 SCC-G62F-A US/CND SCC-G61J-A VPL-X600E PSS-600 Australian SCC-N17A-A AEP/UK SCC-G61G-A VPL-X600M SCC-G61J-A Australian SCC-N17B-A IFB-X600E VPL-X600U/X600E/X600M Lcd Data Projector IFB-X600E...
  • Page 2 VUES EXPLOSÉES ET LES LISTES DE PIECES CONT D'UNE IMPORTANCE CRITIQUE POUR LA SÉCURITÉ DU FONCTIONNEMENT. NE LES REMPLACER QUE PAR DES COMPOSANTS SONY DONT LE NUMÉRO DE PIÉCE EST INDIQUÉ DANS LE PRÉSENT MANUEL OU DANS DES SUPPLÉMENTS PUBLIÉS PAR SONY. LES RÉGLAGES DE CIRCUIT DONT L'IMPORTANCE EST CRITIQUE POUR LA SÉCURITÉ...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS 1. OPERATING INSTRUCTIONS 1-1. VPL-X600U/X600E/X600M OPERATING INSTRUCTIONS ....1-1 1-2. VPL-X600U/X600E/X600M INSTALLATION MANUAL FOR DEALERS ..........1-24 1-3. IFB-X600E OPERATING INSTRUCTIONS ..........1-35 1-4. PSS-600 INSTALLATION MANUAL ............1-38 2. SERVICE INFORMATIONS 2-1. CIRCUIT BOARDS LOCATION ..............2-1 2-2.
  • Page 4 6-1. CABNET ......................6-2 6-2. CHASSIS ......................6-3 6-3. BASE ......................6-4 6-4. OPTICAL UNIT ..................... 6-5 7. ELECTRICAL PARTS LIST • VPL-X600U/X600E/X600M ................7-2 • IFB-X600E ...................... 7-23 • PSS-600 ......................7-23 • RM-PJM600 ....................7-23 8. BLOCK DIAGRAMS •...
  • Page 5 3-862-352-11 (1) LCD Data Projector Operating Instructions Mode d’emploi Manual de instrucciones VPL-X600U VPL-X600E VPL-X600M © 1998 by Sony Corporation...
  • Page 6 • When the Remote Commander causes mulfunction, consult the FCC Rules. These limits are designed to provide and be easily accessible. with qualified Sony personnel. We change the Remote reasonable protection against harmful interference when the Commander as new one according to the guarantee.
  • Page 7 Table of Contents Overview Precautions ..............6 (EN) Features ..............8 (EN) Location and Function of Controls ......9 (EN) Front ................9 (EN) Rear ................. 13 (EN) Remote Commander ..........15 (EN) Setting up and projecting Installing the Projector ..........17 (EN) Connecting ...............
  • Page 8 • Do not place your hand or objects near the ventilation holes — the air coming out is hot. • When the projector is mounted on the ceiling, the Sony PSS-600 Projector Suspension Support must be used for installation. • Be careful not to catch your fingers by the adjusters when you lift up the projector.
  • Page 9 1024 × 768 dots for RGB input and 750 horizontal TV lines for video input. Simple setup • Sony original APA (Auto Pixel Alignment) function You can get the clearest picture automatically by simply pressing the APA key when the signal is input from a computer.
  • Page 10 Location and Function of Controls !£ Speakers How to install the Remote Commander in the front cover !¢ Control panel For details, see “Control panel” on page 11 (EN). Install the Remote Commander in the back of the front !∞ Lens hood cover and fix it with the velcro tapes.
  • Page 11 STANDBY: Lights in red when the AC power cord The illustration above is the VPL-X600U/M model. is plugged into the wall outlet. Once in the standby mode, you can turn on the...
  • Page 12 INPUT AUDIO PICTURE !¢ !£ MENU LASER !™ The illustration above is the VPL-X600U/M model. !ª ENTER R CLICK !¡ 1 VIDEO IN jacks MOUSE (13-pin): Connects to the mouse port on a RESET Connect to external video equipment such as a VCR.
  • Page 13 Install the two size AA (R6) batteries (supplied) Connects to the CONTROL S IN jack on the projector projector on a table. For ceiling installation, consult with qualified Sony with the correct polarity. with the connecting cable (not supplied) when using personnel (see page 34 (EN)).
  • Page 14 Connecting Note on the VPL-X600E model Note The optional IFB-X600E Interface Board is required for the VIDEO IN Connect all the connecting cables to the INPUT A connector when you and AUDIO IN jacks. input a signal from the INPUT A connector. Connect all the cables to the INPUT B connector when you input a signal from the INPUT B connector Connecting with a Computer as well.
  • Page 15 CONTROL S IN to audio/video to S video PLUG IN POWER outputs output Audio/video cable INPUT A INPUT B S-Video cable (VPL-X600U/M: supplied MOUSE AUDIO MOUSE AUDIO (not supplied) VPL-X600E: supplied with the IFB-X600E Interface Board) Rear VIDEO IN AUDIO IN...
  • Page 16 Press the PATTERN key on the control panel to display the H pattern, and turn the focus ring to adjust the focus. HHHH HHHH HHHH HHHH HHHH HHHH HHHH HHHH HHHH HHHH Press the PATTERN key again to clear the pattern. Turn the zoom ring to adjust the size of the picture.
  • Page 18 The PICTURE CTRL Menu The PICTURE CTRL (control) menu is used for CONTRAST SHARP COLOR TEMP adjusting the picture. Unadjustable items depending on the input signal are Adjusts the picture contrast. Adjusts the picture sharpness. Adjusts the color temperature. not displayed in the menu. Note on the VPL-X600E model V I DEO P I CTURE CTRL...
  • Page 19 ASPECT Input signals and adjustable/setting items Sets the aspect ratio of the picture. Item Input signal When inputting 16:9 (squeezed) signal from Video or 15k RGB HDTV RGB B&W equipment such as a DVD player, set to 16:9. S video Component (Y/C) DOT PHASE –...
  • Page 20 15k RGB/Component 50 Hz 15.625 50.000 H-neg V-neg WS Sunmicro 1248 HDTV 33.750 60.000 H-neg V-neg 640 × 350 VGA mode 1 31.469 70.086 H-pos V-neg 800 Sony News 1281 PC-9821 1200 VGA VESA 85 Hz 37.861 85.080 H-pos V-neg 832 1280 ×...
  • Page 21 Installation Examples The SET SETTING Menu The on-screen picture size changes according to the input signal. Note that LANGUAGE POWER SAVING the projection distance also changes depending on the picture size. Selects the language used in the menu and on-screen When set to ON, the projector goes into the power Floor Installation displays.
  • Page 22 Do not install the projector in the following situations. These installations Ceiling Installation may cause mulfunction or damage to the projector. When installing the projector on the ceiling, use the For ceiling installation, consult with qualified Sony PSS-600 Projector Suspension Support. personnel. Poorly ventilated •...
  • Page 23     Notes on Installation Maintenance Carry out the followings. Note on the Time to Replace the Cleaning the Air Filter Lamp The air filter should be cleaned every 300 hours. When No toppling of the unit it becomes difficult to remove the dust from the filter, When it is time to replace the lamp, replace the lamp replace the filter with a new one.
  • Page 24 If the projector appears to be operating erratically, try to diagnose and correct the problem, using the following Symptom Cause Remedy guide. If the problem still persists, consult with qualified Sony personnel. The lamp cover or the air filter cover is Attach the cover securely (see page 37 (EN)) . The LAMP/COVER indicator detached.
  • Page 25 Specifications Specifications Optical characteristics Input/Output Projection system 3 LCD panels, 1 lens, projection VIDEO IN (only for VPL-X600U/M) system VIDEO: phono type LCD panel 1.3-inch TFT LCD panel, Composite video: 1 Vp-p ±2 dB 2, 359, 296 pixels sync negative (75 ohms (786, 432 pixels ×...
  • Page 26 Specifications Pin assignment Mouse cable pin assignment Switch position for signal adapter SIC-S20 RGB connector (HD D-sub 15-pin, female) to Macintosh 13-pin mini DIN 4-pin DIP switch ON (upper position) to Projector OFF (lower position) = 0 DIP switch R/R-Y N.C.
  • Page 27 Specifications Dimensions Top (with the front cover) Rear Front Center of the unit Center of the unit 57.5 (2 ⁄ ) 27.5 (1 ⁄ 48.8 35 (1 ⁄ 222.7 (8 ⁄ ⁄ 92.3 (3 ⁄ Center of 2.5 ( ⁄ projection balance 35 (1...

  • Page 28: Vpl-X600U/X600E/X600M

    3-862-351-12 (1) LCD Data Projector Installation Manual for Dealers Manuel d’installation destiné aux revendeurs Manual de instalación para proveedores VPL-X600U/X600E/X600M VPL-S600U/S600E/S600M © 1998 by Sony Corporation...
  • Page 29 • Do not carry the projector with the cabinet on and with its cover open. On installation • When the projector is mounted on the ceiling, the Sony PSS-600 Projector Suspension Support must be used for installation. • Allow adequate air circulation to prevent internal heat build-up. Do not place the unit on surfaces (rugs, blankets, etc.) or near materials (curtains,...
  • Page 30 Overview On illumination This manual describes how to install the Sony LCD Data Projector VPL- • To obtain the best picture, the front of the screen should not be exposed X600U/E/M and VPL-S600U/E/M, how to replace the lens, how to change to direct lighting or sunlight.
  • Page 31 Changing the Lens Position for Rear Projection Replacing the Lens (Optical Axis Angle: 0 degree) You can install the following two types of lenses in the For rear projection, you can set the optical axis angle Install the lens with the lens stopper and the Remove the lens hood locking the lens by projector.
  • Page 32 Changing the Lens Position for Rear Projection (Optical Axis Angle: 0 degree) Lock the lens by tightening the four screws Disconnect the two connectors on the back of the Install the front panel and lock with the two screws (M4×12, with washers). front panel, one for cooling fan and the other for (M3×8, with washers).
  • Page 33 = x – SS/1.29 × 9.5 c = x – (SS/1.26 × 9.5 + 83.3) c = x – (SS/1.29 × 9.5 + 83.3) Macintosh 16-inch mode signal (horizontal 832 × vertical 624)/HDTV input Refer to the table of the VPL-X600U/E/M. (EN) (EN)
  • Page 34 = x – (SS/1.29 × 9.5 + 83.3) x: Distance between the ceiling and the center of the screen Macintosh 16-inch mode signal (horizontal 832 × vertical 624)/HDTV input Refer to the table of the VPL-X600U/E/M. (Continued) (EN) (EN)
  • Page 35 624)/HDTV input SS: Screen size diagonal (inches) XGA/SXGA signal input Refer to the table of the VPL-X600U/E/M. a min = (SS × 72.290/1.26 – 155) × 1.025 a min = (SS × 72.290/1.29 – 155) × 1.025 a max = (SS × 140.374/1.26 – 20) × 0.975 a max = (SS ×...
  • Page 36 SET SETTING menu. Macintosh 16-inch mode signal (horizontal 832 × For details, refer to the INSTALLATION in the Operating vertical 624)/HDTV input Instructions for the VPL-X600U/E/M or the VPL-S600U/E/ Refer to the table of the VPL-X600U/E/M. (EN) (EN)
  • Page 37 624)/HDTV input a max = (SS × 140.374/1.29 – 20) × 0.975 a max = (SS × 140.374/1.26 – 20) × 0.975 Refer to the table of the VPL-X600U/E/M. b = x b = x c = x – 74 c = x –...
  • Page 38 = 24.275 × SS/1.29 – 64 b = x b = x c = x – 74 c = x – 74 Macintosh 16-inch mode signal (horizontal 832 × vertical 624)/HDTV input Refer to the table of the VPL-X600U/E/M. (EN)
  • Page 39 3-862-502-11 (1) Interface Board Operating Instructions Page 2 Mode d’emploi Page 6 Bedienungsanleitung Seite 10 Manual de instrucciones Página 14 Istruzioni per l’uso Pagina 18 IFB-X600E © 1998 by Sony Corporation...
  • Page 40 2 Pull out the connector socket from the projector. Insert the connector socket (set the uneven side on the right) into the The IFB-X600E interface board is designed to be mounted on Sony interface board connector plug. Gather the wires together and VPL-X600E/S600E LCD data projector so that composite video or S place them in the hook of the interface board.
  • Page 41 Location and Function of Parts Specifications VIDEO IN jacks S VIDEO (4-pin mini-DIN type): Y (luminance) signal input: 1 Vp-p ± 2 dB, sync negative, 75 ohms terminated VIDEO IN AUDIO IN C (chrominance) signal input: burst 0.286 Vp-p ± 2 dB (NTSC), burst 0.3 Vp-p ±...

  • Page 42: Installation Manual

    3-862-500-01(1) Projector Suspension Support Installation manual Manuel d’installation Installationshandbuch Manual de instalación Manuale d’installazione PSS-600 © 1998 by Sony Corporation...

  • Page 53: Service Informations

    SECTION 2 SERVICE INFORMATIONS 2-1. CIRCUIT BOARDS LOCATION [X600M/X600U] SCAN CONVERTER UNIT (BB) POWER SUPPLY BLOCK VPL-X600...

  • Page 54: Disassembly

    2-2. DISASSEMBLY 2-2-1. Cabinet Assy Removal 2-2-2. Front Panel Assy and NF Board Removal 3 Three screws (+B 3X8) 1 Claw 2 Lens cover (TP) 1 Two screws CN6001 CN6002 (+PSW 3X8) 5 Cabinet assy CN4001 3 pin 4 Two screws 3 Screw (+B 3X8) (+PTPWH 3X10)

  • Page 55: Power Supply Block Removal

    2-2-5. Power Supply Block Removal 2-2-6. F Board Removal • Remove the power supply block. (Refer to 2-2-5.) 5 Two screws (+BVTP 3X8) 2 Two screws 1 Screw (+PSW 3X8) 6 Power supply block (+PSW 4X8) 1 Screw 3 Two screws 3 Ground (+BVTP 3X8) 4 F holder...

  • Page 56: C Board Removal

    2-2-8. C Board Removal 2-2-9. Optical Unit Removal • Remove the C board (Refer to 2-2-8.) 2 Four screws 5 Five screws (+PSW 3X8) (+PSW 4X12) 3 C board CN5008 6 Optical unit CN5003 CN5023 CN5007 CN5006 CN5020 CN5202 CN5022 CN5404 CN5012 CN5101...

  • Page 57: Lens Removal

    2-2-12. Lens Removal 2-2-13. Lens Adjustment Any projection size is available when it’s within 40~100inches extent. 1 Four screws Screw driver (–) (+PSW 4X12) 2 Lens Lens Focus ring Zoom ring Screw driver blade (–) Procedure (0) Focus Ring = Mid Position (1) Zoom Ring = Tele End (2) Adjust focus using Focus Ring (3) Zoom Ring = Wide End...

  • Page 59: Set-Up Adjustments

    SECTION 3 SET-UP ADJUSTMENTS Enter the FACTORY MODE in the following manner: 3. W/B: Copy the value in the LOW mode. RGB LEVEL spec. How to enter the FACTORY MODE: All of TP5106, TP5105, and TP5104 0IRE2.00 ± 0.02 Vdc 1.

  • Page 60: Adjustment Of Video Sub Hue And Color

    3-2-3. Adjustment of VIDEO SUB HUE and 9. Input XGA green single-color FLAT FIELD 30 IRE to COLOR INPUT A, and adjust CXA2111 G GAIN so that the brightness Y30 will be within the specification. 1. Set the Color to 45. Brightness adjustment spec.

  • Page 61: Dot Phase & Osd Dot Adjustment

    3-4. DOT PHASE & OSD DOT ADJUST- MENT 1. Select DOT PHASE in the user MENU, and adjust it. 2. If adjustment is insufficient and the part of the burst sig- nal jitters, enter the FACTORY MODE. 3. Enter the DOT PHASE adjustment screen of the Device Adjust.

  • Page 63: Circuit Adjustments

    SECTION 4 CIRCUIT ADJUSTMENTS 4-1. C BOARD ADJUSTMENT (A SIDE) (B SIDE) IC5105 TP5105 25 36 TP5106 TP5104 CN5101 CN5008 4-1-1. Signal Input 4-1-2. Adjustment of RGB Bias and Gain CN5101; 4 pin Make adjustment so that TP5104, TP5105, and TP5106 CN5101;...

  • Page 65: Semiconductors

    IC, TRANSISTOR SECTION 5 SEMICONDUCTORS 10-46547 ISPLSI1016E PC123F2 2SA1162-G CXA1875AM PC123FY2 2SA1162-YG Z86C0404PCU1 EL4332CS MM1231XFBE 2SC2712-YG PC74HC123D-T 2SC3545-T43 TDA4665T-T DTA144EKA-T146 TOP VIEW DTC114EKA 18pin DIP TOP VIEW DTC144EKA-T146 44pin QFP 10-75253 PC74HC02D-T Z86C3012SSSSU2 M52337SP 1 TOP VIEW TC74HC07AF TC74VHC04FS 16pin SOP TC74VHC32F TOP VIEW TOP VIEW...
  • Page 66 DIODE 1S2836 D6SB80 FSF10A60 DAP202K CATHODE ANODE P6KE200AG23 1SS226 D10SC9M MA157-TX CATHODE ANODE 1SS355 RD12M-B2 DTZ12 DAN202K DTZ5.1B DTZ5.6A DTZ6.8A DTZ9.1 DTZ-TT11-12 DTZ-TT11-5.1 DTZ-TT11-5.6A RD5.6SB2 DTZ-TT11-6.8 EL1Z DTZ-TT11-9.1 RGP10GPKG23 RB501V-40TE-17 CATHODE RD3.3SB2-T1 RD9.1S-B2 RD9.1SB2-T1 ANODE RGP10JPKG23 F10P06Q CATHODE ANODE FCQ20A04 CATHODE D1FS4A PTZ-TE25-4.7B...

  • Page 67: Exploded Views

    SECTION 6 The components identified by EXPLODED VIEWS shading and mark are criti- cal for safety. NOTE: • The construction parts of an assembled Replace only with part number part are indicated with a collation number specified. • Items with no part number and no in the remark column.
  • Page 68 CABINET 6-1. CABINET : 7-685-646-79 +BVTP 3X8 : 7-682-548-09 +B 3X8 : 7-682-549-09 +B 3X10 : 7-685-167-19 +P 4X35 : 7-685-903-31 +PTPWH 3X10 : 7-685-144-11 +P 3X5 Ref.No. Part No. Description Remark Ref.No. Part No. Description Remark * X-4035-432-1 HOOD ASSY * 1-668-126-11 NF BOARD * 4-063-685-01...

  • Page 69: Chassis

    * A-1241-314-A F BOARD, COMPLETE 4-063-677-01 WINDOW (RE), RM ! 1-526-954-11 INLET, AC ! 1-468-286-11 SUPPLY BLOCK, POWER * 3-715-526-01 WASHER (M3) * 1-668-130-11 QB BOARD (VPL-X600U/X600M) 1-500-249-11 BEAD, FERRITE (CASE) 4-382-854-01 SCREW (M3X8), P, SW (+) * 1-668-127-11 NR BOARD VPL-X600...

  • Page 70: Base

    BASE 6-3. BASE : 7-685-646-79 +BVTP 3X8 : 7-682-948-01 +PSW 3X8 : 7-682-663-09 +PSW 4X12 : 7-682-667-09 +PSW 4X25 : 7-682-647-09 +PS 3X6 Ref.No. Part No. Description Remark Ref.No. Part No. Description Remark 1-475-689-11 CONVERTER UNIT, SCAN 4-054-855-01 SCREW (+PWH M3X10), MACHINE * 4-063-633-01 HOLDER (TP), GB * 4-063-685-01...

  • Page 71: Optical Unit

    OPTICAL UNIT 6-4. OPTICAL UNIT Ref.No. Part No. Description Remark Ref.No. Part No. Description Remark 1-475-697-11 OPTICAL UNIT 152-160 9-880-346-01 PS CONVERTER 9-880-349-01 POLARIZATION PLATE (R)/ CONDENSER LENS 9-880-344-01 FLYEYE LENS A 9-880-347-01 POLARIZATION PLATE (G)/ 9-880-342-01 PRISM BLOCK, X600 CONDENSER LENS 9-880-355-01 SPACER, COMPLETE...

  • Page 73: Electrical Parts List

    SECTION 7 ELECTRICAL PARTS LIST NOTE: • The components identified by in this manual When indicating parts by reference number, The components identified by have been carefully factory-selected for each set shading and mark are criti- please include the board name. in order to satisfy regulations regarding X-ray cal for safety.

  • Page 74: Vpl-X600U/X600E/X600M

    [BA] VPL-X600U/X600E/X600M Ref.No. Part No. Description Remark Ref.No. Part No. Description Remark * A-1135-928-A BA BOARD, COMPLETE C2062 1-117-681-11 ELECT CHIP 100MF 20% 16V ****************************** C2063 1-117-681-11 ELECT CHIP 100MF 20% 16V C2065 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V C2069...
  • Page 75 [BA] Ref.No. Part No. Description Remark Ref.No. Part No. Description Remark C2160 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V C2311 1-126-603-11 ELECT CHIP 4.7MF 20% 35V C2161 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V C2312 1-164-232-11 CERAMIC CHIP 0.01MF 10% 50V C2313 1-163-009-11 CERAMIC CHIP 0.001MF 10% 50V C2162...
  • Page 76 [BA] Ref.No. Part No. Description Remark Ref.No. Part No. Description Remark IC2003 8-752-073-52 IC CXA2016S Q2018 8-729-230-49 TRANSISTOR 2SC2712-YG IC2004 8-752-073-52 IC CXA2016S Q2019 8-729-230-49 TRANSISTOR 2SC2712-YG IC2005 8-759-491-93 IC EL4332CS-TE2 Q2020 8-729-230-49 TRANSISTOR 2SC2712-YG Q2021 1-801-806-11 TRANSISTOR DTC144EKA-T146 IC2006 8-759-272-90 IC 74VHC240SJX IC2007 8-759-272-90 IC 74VHC240SJX...
  • Page 77 [BA] Ref.No. Part No. Description Remark Ref.No. Part No. Description Remark R2030 1-216-025-91 RES,CHIP 1/10W R2087 1-216-041-00 RES,CHIP 1/10W R2088 1-216-025-91 RES,CHIP 1/10W R2089 1-216-025-91 RES,CHIP 1/10W R2031 1-216-025-91 RES,CHIP 1/10W R2032 1-216-025-91 RES,CHIP 1/10W R2092 1-216-089-91 RES,CHIP 1/10W R2033 1-216-025-91 RES,CHIP 1/10W R2034...
  • Page 78 [BA][F] Ref.No. Part No. Description Remark Ref.No. Part No. Description Remark R2149 1-216-025-91 RES,CHIP 1/10W R2306 1-216-033-00 RES,CHIP 1/10W R2307 1-216-635-11 METAL CHIP 0.50%1/10W R2308 1-216-049-91 RES,CHIP 1/10W R2151 1-216-049-91 RES,CHIP 1/10W R2158 1-216-073-00 RES,CHIP 1/10W R2309 1-216-061-00 RES,CHIP 3.3K 1/10W R2159 1-216-073-00 RES,CHIP...
  • Page 79 1-164-161-11 CERAMIC CHIP 0.0022MF 10% 50V C1072 1-124-779-00 ELECT CHIP 10MF 20% 16V ******************************************************************************** C1073 1-164-161-11 CERAMIC CHIP 0.0022MF 10% 50V * 1-668-130-11 QB BOARD (VPL-X600U/X600M) C1074 1-124-779-00 ELECT CHIP 10MF 20% 16V ************** C1075 1-107-682-11 CERAMIC CHIP 1MF 10% 16V...
  • Page 80 [QA] Ref.No. Part No. Description Remark Ref.No. Part No. Description Remark D1009 8-719-914-43 DIODE DAN202K R1008 1-216-113-00 RES,CHIP 470K 1/10W D1010 8-719-914-44 DIODE DAP202K R1009 1-216-057-00 RES,CHIP 2.2K 1/10W D1011 8-719-036-76 DIODE RD3.3SB2-T1 R1010 1-216-113-00 RES,CHIP 470K 1/10W R1011 1-216-089-91 RES,CHIP 1/10W D1012 8-719-914-43 DIODE DAN202K...
  • Page 81 [QA][QC] Ref.No. Part No. Description Remark Ref.No. Part No. Description Remark R1117 1-216-073-00 RES,CHIP 1/10W Q1603 1-801-806-11 TRANSISTOR DTC144EKA-T146 Q1606 8-729-230-49 TRANSISTOR 2SC2712-YG R1118 1-216-073-00 RES,CHIP 1/10W Q1607 1-801-806-11 TRANSISTOR DTC144EKA-T146 R1119 1-216-049-91 RES,CHIP 1/10W Q1608 8-729-216-22 TRANSISTOR 2SA1162-G R1120 1-216-049-91 RES,CHIP 1/10W R1121...
  • Page 82 [QC][GA][GB] Ref.No. Part No. Description Remark Ref.No. Part No. Description Remark <CRYSTAL> <TRANSISTOR> X1600 1-760-496-21 VIBRATOR, LITHIUM NIOBATE Q8001 ! 8-729-043-15 TRANSISTOR 2SK3013F-02 X1601 1-760-496-21 VIBRATOR, LITHIUM NIOBATE Q8002 ! 8-729-043-15 TRANSISTOR 2SK3013F-02 Q8003 ! 8-729-230-50 TRANSISTOR 2SC2712-YG-TE85L ******************************************************************************** <RESISTOR> !* A-1316-340-A GA BOARD, COMPLETE R8001 ! 1-219-363-11 FUSIBLE ******************************...
  • Page 83 [GB] Ref.No. Part No. Description Remark Ref.No. Part No. Description Remark C7016 ! 1-163-031-91 CERAMIC CHIP 0.01MF D7021 ! 8-719-055-30 DIODE D1FS4A-TA C7026 ! 1-164-004-91 CERAMIC CHIP 0.1MF 10% 25V D7022 ! 8-719-055-30 DIODE D1FS4A-TA D7023 ! 8-719-055-30 DIODE D1FS4A-TA C7027 ! 1-164-004-91 CERAMIC CHIP 0.1MF 10% 25V C7031 ! 1-129-718-51 FILM...
  • Page 84 [GB][GBA][C] Ref.No. Part No. Description Remark Ref.No. Part No. Description Remark Q7018 ! 8-729-042-96 TRANSISTOR 2SK2677F-02 * A-1316-369-A GBA BOARD, COMPLETE ******************************** <RESISTOR> <CAPACITOR> R7001 ! 1-217-418-61 FUSIBLE 0.47 10% 1/2W F R7002 ! 1-216-009-91 RES,CHIP C7101 1-164-004-11 CERAMIC CHIP 0.1MF 10% 25V 1/10W R7003 ! 1-218-191-71 METAL OXIDE 0.1...
  • Page 85 Ref.No. Part No. Description Remark Ref.No. Part No. Description Remark C5014 1-164-156-11 CERAMIC CHIP 0.1MF C5144 1-162-970-11 CERAMIC CHIP 0.01MF 10% 25V C5015 1-126-204-11 ELECT CHIP 47MF 20% 16V C5145 1-162-970-11 CERAMIC CHIP 0.01MF 10% 25V C5147 1-162-918-11 CERAMIC CHIP 18PF C5016 1-164-156-11 CERAMIC CHIP 0.1MF C5148...
  • Page 86 Ref.No. Part No. Description Remark Ref.No. Part No. Description Remark CN5007 1-764-643-21 PIN, CONNECTOR (SMD) 11P FB5354 1-414-227-11 INDUCTOR CHIP 0UH CN5008 1-569-481-21 CONNECTOR, FPC 30P FB5355 1-216-864-11 SHORT CN5009 1-580-055-21 PIN, CONNECTOR 2P FB5356 1-216-864-11 SHORT FB5357 1-216-864-11 SHORT CN5010 1-573-768-21 PIN, CONNECTOR (1.5MM) (SMD)5P CN5012 * 1-580-056-21 PIN, CONNECTOR (SMD) 3P FB5358 1-216-864-11 SHORT...
  • Page 87 Ref.No. Part No. Description Remark Ref.No. Part No. Description Remark IC5002 8-759-259-77 IC PQ20VZ5U R5010 1-216-809-11 RES,CHIP 1/16W IC5003 8-759-082-58 IC TC7W08FU IC5004 8-759-351-63 IC TA7812F(TE16L) R5011 1-216-809-11 RES,CHIP 1/16W IC5006 8-759-162-80 IC MM1170BFB R5012 1-216-809-11 RES,CHIP 1/16W R5013 1-216-809-11 RES,CHIP 1/16W IC5007 8-759-471-25 IC BR24CF16F...
  • Page 88 Ref.No. Part No. Description Remark Ref.No. Part No. Description Remark R5070 1-216-864-11 SHORT R5161 1-216-801-11 RES,CHIP 1/16W R5071 1-216-864-11 SHORT R5162 1-216-801-11 RES,CHIP 1/16W R5164 1-216-829-11 RES,CHIP 4.7K 1/16W R5072 1-216-864-11 SHORT R5167 1-216-809-11 RES,CHIP 1/16W R5168 1-216-809-11 RES,CHIP 1/16W R5073 1-216-864-11 SHORT R5076...
  • Page 89 Ref.No. Part No. Description Remark Ref.No. Part No. Description Remark R5277 1-216-809-11 RES,CHIP 1/16W R5410 1-216-821-11 RES,CHIP 1/16W R5411 1-216-821-11 RES,CHIP 1/16W R5412 1-216-821-11 RES,CHIP 1/16W R5278 1-216-833-11 RES,CHIP 1/16W R5279 1-216-833-11 RES,CHIP 1/16W R5413 1-216-821-11 RES,CHIP 1/16W R5280 1-216-833-11 RES,CHIP 1/16W R5281 1-216-829-11 RES,CHIP...
  • Page 90 [C][V][H] Ref.No. Part No. Description Remark Ref.No. Part No. Description Remark R5515 1-216-828-11 RES,CHIP 3.9K 1/16W D6012 8-719-914-44 DIODE DAP202K R5516 1-216-823-11 RES,CHIP 1.5K 1/16W D6013 8-719-914-44 DIODE DAP202K R5517 1-216-821-11 RES,CHIP 1/16W D6014 8-719-045-60 DIODE SEC1401C D6015 8-719-045-53 DIODE SEC1801C <RESISTOR BLOCK>...
  • Page 91 [H][U][NF][NR][BB] Ref.No. Part No. Description Remark Ref.No. Part No. Description Remark R6031 1-216-039-00 RES,CHIP 1/10W <RESISTOR> R6032 1-216-039-00 RES,CHIP 1/10W R6033 1-216-039-00 RES,CHIP 1/10W R4001 1-216-017-91 RES,CHIP 1/10W R6034 1-216-039-00 RES,CHIP 1/10W R4002 1-216-025-91 RES,CHIP 1/10W R6035 1-216-061-00 RES,CHIP 3.3K 1/10W R6036 1-216-061-00 RES,CHIP...
  • Page 92 [BB] Ref.No. Part No. Description Remark Ref.No. Part No. Description Remark C3022 1-115-156-11 CERAMIC C3091 1-164-156-11 CERAMIC CHIP 0.1MF C3023 1-164-156-11 CERAMIC CHIP 0.1MF C3024 1-164-156-11 CERAMIC CHIP 0.1MF C3092 1-162-921-11 CERAMIC CHIP 33PF C3025 1-164-156-11 CERAMIC CHIP 0.1MF C3093 1-162-970-11 CERAMIC CHIP 0.01MF 10% 25V C3098...
  • Page 93 [BB] Ref.No. Part No. Description Remark Ref.No. Part No. Description Remark <DIODE> R3010 1-216-815-11 RES, CHIP 1/16W D3001 8-719-988-62 DIODE 1SS355 R3011 1-219-365-11 CONDUCTOR, CHIP D3002 8-719-988-62 DIODE 1SS355 R3012 1-216-815-11 RES, CHIP 1/16W R3013 1-219-365-11 CONDUCTOR, CHIP D3003 8-719-988-62 DIODE 1SS355 D3004 8-719-988-62 DIODE 1SS355 R3014...
  • Page 94 [BB] Ref.No. Part No. Description Remark Ref.No. Part No. Description Remark R3098 1-216-821-11 RES, CHIP 1/16W MISCELLANEOUS R3099 1-216-833-11 RES, CHIP 1/16W *********************** R3105 1-216-017-91 RES, CHIP 1/10W R3106 1-216-017-91 RES, CHIP 1/10W ! 1-468-286-11 SUPPLY BLOCK, POWER 1-475-689-11 CONVERTER UNIT, SCAN (BB BOARD) R3107 1-216-017-91 RES, CHIP 1/10W...

  • Page 95: Ifb-X600E

    RM-PJM600 Ref.No. Part No. Description Remark Ref.No. Part No. Description Remark 1-475-735-11 REMOTE COMMANDER (X600E/X600M) 1-475-735-21 REMOTE COMMANDER (X600U) 9-880-535-01 BATTERY COVER (FOR RM-PJM600) IFB-X600E PSS-600 Ref.No. Part No. Description Remark Ref.No. Part No. Description Remark * A-1275-152-A QB BOARD, COMPLETE ACCESSORIES AND PACKING MATERIALS ****************************** ******************************************************...

  • Page 97: Block Diagrams

    BA, QB BA, QB SECTION 8 BLOCK DIAGRAMS INPUT AB/VIDEO RGB INPUT,DIGITAL COMB FILTER, Q2028 CHROMA DEC.,RGB DECODER SECAM (VIDEO INPUT) TRAP IC2012 J1501 Y/CV SW CN1501 CN2007 IC2015 IC2018 14 IN2B OUT2 5 CHROMA DEC TP2009 TP2011 Q2027, RGB DECODER 11 IN2A SW2 12 Q2007...
  • Page 98 C, NF, NR, U, V C, NF, NR, U, V LAMP (PANEL DRIVE,CPU) +13.5V +15.5V PROT SW IC5106 IC5005 IC5305 CN5304 TP5103 TP5106 TP5107 CN4101 GAMMER CONTROL R LCD DRIVER VVDD CN5023 IC5104 R MIX R OUT LAMP COVER CN5101 RGB AMP,OSD MIX HVDD 19 I-LAMP-C...
  • Page 99 H, QA, QC H, QA, QC (AUDIO) (CONTROL PANEL) IC1008 IC1007 AUDIO SW/PROCESSOR AUDIO AMP CN1001 CN6002 CN6003 CN1003 L SUB SP+ L SUB SP+ L SUB SP+ L-VIDEO 40 IN13 REO1 23 12 IN-L L-OUT 19 L SUB SP- L SUB SP- L SUB SP- 41 IN12...
  • Page 100 F, GA, GB, GBA F, GA, GB, GBA BALLAST LAMP CN8002 (POWER-FACTOR REGULATING CONTROL) C BOARD GND1 GND1 FLAG CN5006 L80005 CN8001 D8001 D8002 AC(N) RECT RECT AC(L) T7001 Q8001, Q8002 (SET POWER SUPPLY) IC7002 D7007 +5V REG CN8003 CN7001 SWITCTING RECT GND1...

  • Page 101: Diagrams

    FRAME FRAME SECTION 9 DIAGRAMS 9-1. FRAME SCHEMATIC DIAGRAM CN5020 CN6001 CN1501 CN2007 CN2003 CN3005 CN3001 CN5101 A +5V A +5V KEY 0 KEY 0 A +5V A +5V KEY 1 KEY 1 SUB 5V SUB 5V CN6002 SUB 5V SUB 5V CN6003 (VIDEO INPUT)

  • Page 102: Schematic Diagrams And Printed Wiring Boards

    9-2. SCHEMATIC DIAGRAMS AND PRINTED WIRING BOARDS Reference information NOTE: . All capacitors are in µF unless otherwise noted. pF: RESISTOR : RN METAL FILM µµF : RC SOLID . Capacitors without voltage indication are all 50V. : FPRD NONFRAMMABLE .
  • Page 103 C1068 C1063 C1064 C1065 0.047 0.0022 0.0022 B:CHIP B:CHIP B:CHIP B:CHIP (AUDIO) C1069 C1066 C1084 R1104 :CHIP :AL-CP :AL-CP :AL-CP C1005 R1002 R1103 470k :CHIP :AL-CP :CHIP L-INPUT-A R1102 L1003 C1082 R1101 D1002 GAIN12 FNTO1 BLm21B03 :CHIP R1109 R1110 RD9.1SB2 GAIN11 REO1 B:CHIP...
  • Page 104 QB, QC QB, QC -A SIDE- -B SIDE- 1-668-130-12 1-668-130-12 VPL-X600U/X600M VPL-X600U/X600M -A SIDE- -B SIDE- 1-668-131-12 1-668-131-12 VPL-X600...
  • Page 105 QB, QC QB, QC D1600 RB501V-40TE-17 CN1501 Q1600 D1601 D1602 WHEN MOUSE PORT R1600 :SMD 1SS355 1SS355 CONNECTED:+5V CN1600 J1501 C1600 :CHIP D1603 C1601 R1610 :AL-CP 0 :CHIP F:CHIP IC1600 R1603 10-75253 R1602 JL1626 R1601 5.6k IC1601 Z86C3012SSU2 100 :CHIP :CHIP TO BA(2/3) BOARD 10-46547...

  • Page 106: Ba (1/3) Board

    BA BOARD *: B SIDE * D2001 IC2001 C-3 IC2002 B-4 * D2002 * D2003 IC2003 C-4 * D2004 IC2004 A-4 * D2005 * IC2005 A-2 * IC2006 A-3 * D2006 * D2007 * IC2007 A-3 * D2008 * IC2008 B-3 * D2009 IC2012 G-2 * D2010...
  • Page 107 -B SIDE- 1-668-128-12 VPL-X600...
  • Page 108 BA (1/3) BA (1/3) C2185 6.3V :AL-CP CN2003 C2186 C2228 R2230 6.3V :AL-CP TP2001 TP2002 TP2006 C2187 :SMD 6.3V :AL-CP C2050 C2188 R2049 0.1 25V B:CHIP 6.3V :AL-CP 75 :RN-CP S2001 C2033 L2011 L2012 C2039 C2051 Hm102 Hm102 0.1 25V B:CHIP C2229 R2231 :CHIP...

  • Page 109: Ba (2/3) Board

    BA (2/3) BA (2/3) (TO P1) (2/3) (TO P3) (DIGITAL COMB FILTER) PAL/NTSC ≠≠≠≠ ≠≠≠ (FROM P3) C2306 R2308 C2312 L2301 R2305 0.01 10µ B:CHIP :CHIP B:CHIP :CHIP C2303 C2315 R2309 3.3k CH:CHIP :AL-CP :CHIP Q2302 DTA144EKA 4FSC ADJ R2301 CN2005 Q2301 :CHIP...
  • Page 110 BA (3/3) BA (3/3) (3/3) (CHROMA DEC,RGB DECODER) (FROM P2) R2188 :CHIP Q2035 C2221 IC2026 2SC2712 MM1111XFBE BUFF VIDEO Y/CV SW :AL-CP RGB C-S (FROM P1) C2220 R2186 4.7k :AL-CP :RN-CP (FROM P1) INPUTAB/VIDEO ≠≠≠≠≠ ≠≠≠≠ R2187 R2189 C2219 :RN-CP :CHIP :AL-CP (FROM P2)

  • Page 111: Ba (3/3) Board

    BA (3/3) NF, NR, U, V BA(3/3) BOARD IC2016 TDA4665T DIGITAL SUPPLY IC4001 GP1U26X (R-Y)IN IC4801 – RECEIVER GP1U26X CN4001 (RECEIVER) (RECEIVER) RECEIVER CN4801 WHT-L R4001 :S-MICRO RED-L R4801 :CHIP :S-MICRO SUB+5V SIGNAL :CHIP SIRCS-NF SUB+5V CLAMPING SAMPLE SIRCS-NR LINE R4002 AND- MEMORY...
  • Page 112 D6006 D6007 D6001 D6009 D6010 D6004 D6003 D6008 (CONTROL PANEL) SEC1901C SEC1901C SEC1401C SEC1801C DAN202K DAN202K DAN202K DAN202K SUB+5V LAMP-LED TEMP-LED POWER POWER-SAVE PROTECT PROTECT PROTECT PROTECT CN6001 R6009 R6016 Q6001 :SMD :CHIP :CHIP DTA144EKA S6001 S6002 S6003 S6004 S6005 S6006 S6007 S6008...
  • Page 113 C (1/5) C (1/5) CN5009 :SMD R5029 R5514 5V -1 TEMP L CONT OUT IC5018(1/2) SUB+5V 1/16W 4.7k JL5018 MPC393G2-T2 1/16W :CHIP FUSE L CONT IN LAMP ON LAMP TEMP DET :CHIP JL5002 IC5012(1/2) R5019 FB5031 5V-2 TC7W08FU(TE12) D5002 R5091 R5508 R5516 BK1608HM601T...
  • Page 114 C (2/5) C (2/5) TO BB CN5101 :SMD 5V-3 R5138 JL5111 :CHIP C (2/5) BOARD TO P3,4 5V-3 R5135 WAVE PATTERN FL5101 R5132 C5131 NFM61R472 :CHIP C5146 5V-3 :CHIP TP5101 JL5112 :AL-CP TP5103 TP5102 R5130 R5133 R5136 IC5104 C5130 C5149 C5114 M52337SP 1/10W...

  • Page 115: C (3/5) Board

    C (3/5) C (3/5) 5V-2 5V-3 15.5V IC5212 M62399FP R5277 D/A CONVERTER 1/16W 15.5V-2 :CHIP L5201 4.7µH R5276 100 1/16W :CHIP (3/5) R5275 100 1/16W :CHIP C5222 C5223 RB5204 (PANEL DRIVE) SCEN F:CHIP :AL-CP :CHIP JL5210 B VCOM RB5205 VREFL R5282 4.7k VREF1...
  • Page 116 C (4/5) C (4/5) 15.5V 15.5V L5302 (4/5) L5301 15.5V-3 4.7µH 15.5V-4 4.7µH (PANEL DRIVE) C5306 C5307 C5322 C5323 F:CHIP :AL-CP F:CHIP :AL-CP SCEN SCEN B VCOM R VCOM B OUT R OUT TO P3 R-SID IN B-SID IN TO P3 15.5V 15.5V TP5301...
  • Page 117 C (5/5) C (5/5) IC5404 TC7SH04F(T ENB1 ≠≠≠≠ ≠≠≠ E85R) (5/5) R5456 ENB2 ≠≠≠≠ ≠≠≠ 1/16W (PANEL DRIVE) :CHIP C5406 5V-2 R5414 R5434 1/16W 1/16W F:CHIP R5420 R5428 :CHIP :CHIP 1/16W 1/16W :CHIP :CHIP FB5402 R5417 R5430 BK1608HM601T IC5403 1/16W 1/16W :CHIP TC74VHC04FS...
  • Page 118 C BOARD *: B SIDE * IC5001 B-5 IC5002 G-1 * IC5003 C-2 IC5004 H-1 IC5005 B-3 IC5006 B-4 IC5007 C-2 * IC5008 A-2 IC5009 B-2 IC5011 E-5 IC5012 A-2 IC5013 F-1 * IC5014 B-5 * IC5015 A-5 * IC5016 B-4 IC5017 E-4 * IC5018 F-3 IC5103 B-5...
  • Page 119 -B SIDE- 1-668-133-11 VPL-X600 9-19 9-19...
  • Page 120 F, GA F, GA -A SIDE- -B SIDE- 1-668-121-12 1-668-121-12 -A SIDE- -B SIDE- 1-668-120-12 1-668-120-12 9-20 9-20 VPL-X600...
  • Page 121 F, GA F, GA LAMP CN8002 R8004 R8005 CN8001 :VH-B D8001 D8006 :VH-B D6SB80 TF861S L8005 3.3A 800V,6A 800V,6A AC(N) R8003 GND 1 GND 1 FLAG 1.5k R8001 R8002 Q8001 Q8002 D8002 D8007 2SK3013F D8008 2SK3013F FSF10A60 D1FS4A SWITCHING D1FS4A SWITCHING 600V,10A TO C(1/5) BOARD...
  • Page 122 -A SIDE- -B SIDE- 1-668-122-12 1-668-122-12 9-22 9-22 VPL-X600...
  • Page 123 R7001 IC7002 R7083 0.47 CN7001 PQ05SZ1U CN7003 T7001 1/2W 1/4W D7007 5V REG (SET POWER SUPPLY) PS7003 :FPRD :VH-B D7001 D2S4M :B-TO-B SUB+5V P6KE200A 40V,2A SUB+5V D7002 C7065 RGP10J SUB+5V 100p 600V,1A GND 1 GND 2 D7004 C7005 C7006 TO GA BOARD GND 2 1S2836 POWER CONT...
  • Page 124 -A SIDE- -B SIDE- 1-668-123-12 1-668-123-12 9-24 9-24 VPL-X600...
  • Page 125 SUB+5V CN7101 SUB+5V :B-TO-B CN7103 GND 2 SUB+5V GND 2 SUB+5V :S-MICRO POWER CONT GND 2 TO C(1/5) BOARD FAN PROT CN5003 GND 2 FAN CONT POWER CONT FAN PROT CN7110 FAN+B FAN CONT :S-MICRO FAN GND FAN+B FAN PROT FAN+B FAN GND CN7104...
  • Page 126 BB (1/6) BB (1/6) R3038 :RN-CP 5V-3 R3040 TP3008 :RN-CP R3036 :CHIP AN RED GREEN IC3029 RA3035 RA3034 CLAMP EL4093C R3067 BLUE 1/16W C3071 R3037 :CHIP 0.0022 R3039 C3073 C3068 C3074 :RN-CP C3072 C3069 CN3005 F:CHIP C3070 C3092 F:CHIP F:CHIP F:CHIP C3167 F:CHIP...
  • Page 127 BB (2/6) BB (2/6) D3011 CN3004 5V-3 5V-3 3.3V 1SS354 L3001 R3099 IC3027 R3098 nL322522T-100J SN74CBT3306 C3110 C3111 1/16W PB20 FL3018 1/16W :CHIP SGM32C1V222-2A :CHIP -PIHSEN PB21 C3095 C3094 C3138 PB22 R3013 R3011 R3009 R3007 PB23 -PIHS :CHIP :CHIP :CHIP :CHIP F:CHIP C3097...
  • Page 128 BB (3/6) BB (3/6) RA3016 RA3015 RA3018 C3152 1044 F:CHIP ROLD1 POD09 ROLD2 ≠≠≠ ≠≠ POD10 ROLD3 ≠≠≠ ≠≠ POD11 ROLD4 IC3024 POD12 µPD485506 ROLD5 POD13 FIFO ROLD6 ≠≠≠ ≠≠ POD14 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 ROLD7 POD15 MA11...
  • Page 129 BB (4/6) BB (4/6) RA3002 RA3001 RA3004 C3153 1044 F:CHIP GOLD1 POD09 GOLD2 ≠≠≠ ≠≠ POD10 GOLD3 ≠≠≠ ≠≠ POD11 GOLD4 IC3002 POD12 µPD485506 GOLD5 POD13 FIFO GOLD6 ≠≠≠ ≠≠ POD14 9 10 11 12 13 14 15 16 17 18 19 20 21 22 GOLD7 POD15 MA11...
  • Page 130 BB (5/6) BB (5/6) RA3007 RA3008 RA3014 C3017 1044 F:CHIP BOLD1 POD09 BOLD2 ≠≠≠ ≠≠ POD10 BOLD3 ≠≠≠ ≠≠ POD11 BOLD4 R3071 IC3016 POD12 :CHIP µPD485506 BOLD5 POD13 FIFO BOLD6 ≠≠≠ ≠≠ POD14 9 10 11 12 13 14 15 16 17 18 19 20 21 22 BOLD7 POD15 MA11...
  • Page 131 BB (6/6) BB (6/6) 3.3V C3131 R3080 4.7k F:CHIP 1/16W C3132 :CHIP 2B10 CLKEN1B F:CHIP RED NEW3 RED NEW2 RED NEW4 RED NEW1 RED NEW5 RED NEW0 RA3009 RED NEW6 RED NEW7 5V-4 BLUE NEW0 CLKENA2 BLUE NEW1 C3158 R3129 RA3010 BLUE NEW2 IC3022...
  • Page 134 English 98BZ24129-1 Sony Corporation Printed in Japan 9-922-689-01 Broardcasting & Professional Systems Company ©1998. 2 Published by Global Support Promotion Dept.
