- Page 1 3-865-632-12 (1) LCD Data Projector Operating Instructions VPL-X1000U VPL-X1000E VPL-X1000M...
- Page 2 • When the Remote Commander causes mulfunction, consult You are cautioned that any changes or modifications not with qualified Sony personnel. We change the Remote expressly approved in this manual could void your authority Commander as new one according to the guarantee.
- Page 3 For the customers in Canada This Class A digital apparatus complies with Canadian ICES- 003. For the customers in the United Kingdom WARNING THIS APPARATUS MUST BE EARTHED IMPORTANT The wires in this mains lead are coloured in accordance with the following code: Green-and-Yellow: Earth Blue:...
- Page 4 (EN)
-
Page 5: Table Of Contents
Table of Contents Overview Precautions ..............6 (EN) Features ..............8 (EN) Location and Function of Controls ......9 (EN) Front ................9 (EN) Rear ................. 13 (EN) Remote Commander ..........15 (EN) Setting up and projecting Installing the Projector ..........17 (EN) Connecting ............... -
Page 6: Precautions
• Do not place your hand or objects near the ventilation holes — the air coming out is hot. • When the projector is mounted on the ceiling, the Sony PSS-600 Projector Suspension Support must be used for installation. • Be careful not to catch your fingers by the adjusters when you lift up the projector. - Page 7 On cleaning • To keep the cabinet looking new, periodically clean it with a soft cloth. Stubborn stains may be removed with a cloth lightly dampened with a mild detergent solution. Never use strong solvents, such as thinner, benzene, or abrasive cleansers, since these will damage the cabinet. •...
-
Page 8: Features
1024 × 768 dots for RGB input and 750 horizontal TV lines for video input. Simple setup • Sony original APA (Auto Pixel Alignment) function You can get the clearest picture automatically by simply pressing the APA key when the signal is input from a computer. -
Page 9: Location And Function Of Controls
Location and Function of Controls Front !∞ !¢ !£ !¡ !™ 1 Front cover 9 Ventilation holes (exhaust) Installs the Remote Commander in the back of the Notes front cover. • Do not place anything near the ventilation holes as it 2 Front adjuster button may cause internal heat build-up. - Page 10 Location and Function of Controls !£ Speakers How to remove the front cover !¢ Control panel Remove the front cover from the front cabinet by For details, see “Control panel” on page 11 (EN). stretching out both right and left sides on the front cover.
- Page 11 As for the rear adjusters, turn them for adjustment. How to use the adjusters While lifting the projector, adjust the height so that the projector becomes level. There are one adjuster at the front and two at the rear of the projector. As for the front adjuster, press the front adjuster button while lifting the projector to adjust the height.
- Page 12 Location and Function of Controls 5 ENTER key !¡ Indicators Enters the settings of items in the menu system. ON: Lights in green when the power is turned on. Flashes in green while the cooling fan runs after 6 RESET key turning off the power with the I / u key.
-
Page 13: Rear
MOUSE AUDIO MOUSE AUDIO IN/OUT The illustration above is the VPL-X1000U/M model. 1 Rear remote control detector 2 AC IN socket Connects the supplied AC power cord. 3 Rear adjusters Used to keep the projector level if it is installed on an uneven surface. - Page 14 AUDIO MOUSE AUDIO IN/OUT The illustration above is the VPL-X1000U/M model. 1 VIDEO IN jacks RGB input (INPUT A) / RGB IN/OUT (INPUT B) Connect to external video equipment such as a VCR. (HD D-sub 15-pin, female): Connects to the...
-
Page 15: Remote Commander
Remote Commander For details, see “Connecting with a Computer” on page The Remote Commander can be used as a wireless or 18 (EN). wired Remote Commander. The keys which have the same names as on the control Notes on laser beam panel function identically. - Page 16 Location and Function of Controls !º CONTROL S OUT jack (stereo minijack) Install the two size AA (R6) batteries (supplied) Connects to the CONTROL S IN jack on the projector with the correct polarity. with the connecting cable (not supplied) when using the Remote Commander as a wired one.
-
Page 17: Installing The Projector
Installing the Projector This section describes the installation arrangements for installing the projector on a table. For ceiling installation, consult with qualified Sony personnel (see page 34 (EN)). Adjust the vertical and horizontal positioning of the projector. Vertical positioning (side view) -
Page 18: Connecting
Connecting Note on the VPL-X1000E model The optional IFB-X600E Interface Board is required for the VIDEO IN and AUDIO IN jacks. Connecting with a Computer This section describes how to connect the projector with a computer. For details on how to connect VCR or other equipment, see page 20 (EN). When the projector is connected to a computer, you can control the mouse of a computer by the Remote Commander. - Page 19 Notes • Connect all the connecting cables to the INPUT A connector when you input a signal from the INPUT A connector. Connect all the cables to the INPUT B connector when you input a signal from the INPUT B connector as well. •...
-
Page 20: Connecting With A Vcr, 15K Rgb/Component Equipment
When pulling out a cable, be sure to pull it out from the plug, not the cable itself. to S video to audio/video output outputs Audio/video cable S-Video cable (VPL-X1000U/M: supplied (not supplied) VPL-X1000E: supplied with the IFB-X600E Interface Board) Set this switch to IN. VIDEO IN AUDIO IN Rear (MONO) -
Page 21: Using The Rgb In/Out Connector On Input B As A Monitor Output Connector
Using the RGB IN/OUT connector on INPUT B as a monitor output connector This section describes connections when using the RGB IN/OUT connector on INPUT B as a monitor output connector. When making connections, be sure to: • turn off all equipment before making any connections. •... -
Page 22: Projecting
Projecting Rear remote control detector Front remote control detector 4, 6 STANDBY indicator COMMAND I / u ON indicator MUTING INPUT AUDIO PICTURE POWER LAMP/COVER TEMP/FAN STANDBY SAVING APA key MENU LASER LIGHT I / u VOLUME – PATTERN INPUT ENTER R CLICK MENU... - Page 23 Press the PATTERN key on the control panel to display the H pattern, and turn the focus ring to adjust the focus. H H H H H H H H H H H H H H H H H H H H H H H H H H H H H H H H...
- Page 24 Projecting To turn off the power Press the I / u key on the Remote Commander or on the control panel. The following message appears to confirm if you want to turn off the power. P OW E R O F F ? P l e a s e p r e s s k e y...
-
Page 25: Using The Menu
Using the MENU The projector is equipped with an on-screen menu for To clear the menu display making various adjustments and settings. To select the language used in the menu, see page Press the MENU key. 32 (EN). The menu display disappears automatically if no key is pressed for one minute. -
Page 26: The Picture Ctrl Menu
The PICTURE CTRL Menu The PICTURE CTRL (control) menu is used for CONTRAST adjusting the picture. Unadjustable items depending on the input signal are Adjusts the picture contrast. not displayed in the menu. Note on the VPL-X1000E model The optional IFB-X600E Interface Board is required C O N T R A S T : 8 0 for inputting the video signal. - Page 27 SHARP COLOR TEMP Adjusts the picture sharpness. Adjusts the color temperature. V I D E O P I C T U R E C T R L C O N T R A S T : 8 0 B R I G H T : 5 0 S H A R P : 5 0 C O L O R : 5 0 H U E : 5 0...
-
Page 28: The Input Setting Menu
The INPUT SETTING Menu The INPUT SETTING menu is used to adjust the input DOT PHASE signal. Unadjustable items depending on the input signal are Adjusts the dot phase of the LCD panel and the signal not displayed in the menu. input from the INPUT A/B connectors. - Page 29 ASPECT Input signals and adjustable/setting items Sets the aspect ratio of the picture. Item Input signal When inputting 16:9 (squeezed) signal from Video or 15k RGB B&W equipment such as a DVD player, set to 16:9. S video Component (Y/C) DOT PHASE –...
- Page 30 Macintosh 19” 1328 Macintosh 21” 1456 VGA VESA 85 Hz 37.861 85.080 H-pos V-neg 832 640 × 400 PC-9801 Sony News 1708 Normal 24.823 56.416 H-neg V-neg 848 PC-9821 1600 VGA mode 2 31.469 70.086 H-neg V-pos 800 1280 × 1024 VGA VESA 85 Hz 37.861 85.080 H-neg V-pos 832...
-
Page 31: The Set Setting Menu
The SET SETTING Menu The SET SETTING menu is used for changing the STATUS (on-screen display) settings of the projector. Sets up the on-screen display. I N P U T – A I N P U T – A S E T S E T T I N G S T A T U S : O N S E T... - Page 32 The SET SETTING Menu LANGUAGE POWER SAVING Selects the language used in the menu and on-screen When set to ON, the projector goes into the power displays. saving mode if no signal is input for 10 minutes. I N P U T – A I N P U T –...
-
Page 33: Installation Examples
Installation Examples Floor Installation a: Distance between the screen and the center of the lens b: Distance from the floor to the center of the lens Wall c: Distance from the floor to the foot of the projector Center of the screen x: Free Distance from the front of the cabinet and the center... -
Page 34: Ceiling Installation
Installation Examples Ceiling Installation When installing the projector on the ceiling, use the For ceiling installation, consult with qualified Sony PSS-600 Projector Suspension Support. personnel. PSS-600 Projector Suspension Support a: Distance between the screen and the center of lens (not supplied) -
Page 35: Unsuitable Installation
Unsuitable Installation Do not install the projector in the following situations. These installations may cause mulfunction or damage to the projector. Poorly ventilated • Allow adequate air circulation to prevent internal heat build-up. Do not place the unit on surfaces (rugs, blankets, etc.) or near materials (curtains, draperies) that may block the ventilation holes. -
Page 36: Notes On Installation
U V W _ ` a J K L M N Notes on Installation Carry out the followings. No toppling of the unit Avoid using as the unit topples over on its side. It may cause malfunction. Use to be level Avoid using as the unit tilts more than 20 degrees. -
Page 37: Maintenance
Maintenance Note on the Time to Replace the Cleaning the Air Filter Lamp The air filter should be cleaned every 300 hours. When it becomes difficult to remove the dust from the filter, When it is time to replace the lamp, replace the lamp replace the filter with a new one. -
Page 38: Troubleshooting
Troubleshooting If the projector appears to be operating erratically, try to diagnose and correct the problem, using the following guide. If the problem still persists, consult with qualified Sony personnel. Symptom Cause Remedy The power is not turned on. The power has been turned off and on Wait for about one minute before turning on the with the I / u key at a short interval. - Page 39 Replace the lamp (see page 37 (EN)) . The LAMP/COVER indicator lights up. The fan is broken. The TEMP/FAN indicator Consult with qualified Sony personnel. flashes. The internal temperature is unusually The TEMP/FAN indicator Check to see if nothing is blocking the ventilation high.
-
Page 40: Specifications
(786, 432 pixels × 3) burst 0.3 Vp-p ±2 dB (PAL) (75 ohms terminated) Lens 1.3 times zoom lens AUDIO IN (only for VPL-X1000U/M) f 54 to 70 mm/F 2.0 to 2.4 Phono type × 2 Lamp 120 W UHP... - Page 41 Some of the items may not be available in some areas. For Signal Adapter (for Macintosh) (1) details, please consult your nearest Sony office........................................... (EN) 1) LMP-600 and VLC-600 may not be available in some areas. For details, please consult your nearest Sony office.
- Page 42 Specifications Pin assignment Mouse cable pin assignment SIC-S20 RGB input (INPUT A)/RGB IN/OUT (INPUT B) connector (HD D-sub 15-pin, female) 13-pin mini DIN 4-pin R/R-Y N.C. 98/AT/TXD +5V/DTR B/B-Y CLOCK N.C. N.C. DATA HD/C.Sync GND (R) L/PS GND (G) N.C. GND (B) SIC-S21 13-pin...
- Page 43 Switch position for signal adapter to Macintosh DIP switch ON (upper position) OFF (lower position) = 0 to Projector DIP switch Mode 12345678 VGA/S VGA 31.5 kHz/37.8 kHz 0 0 1 1 1 0 0 1 Macintosh 13” 35.0 kHz 1 1 0 0 1 0 0 1 Macintosh 16”...
- Page 44 Specifications Dimensions Rear Front Center of the unit Center of the unit 57.5 (2 ⁄ ) 27.5 (1 ⁄ 48.8 35 (1 ⁄ 222.7 (8 ⁄ ⁄ 92.3 (3 ⁄ Center of projection 2.5 ( ⁄ balance 35 (1 ⁄ 128 (5 ⁄...
- Page 45 Top (with the front cover) 353 (13 ⁄ Unit: mm (inches) (EN)
- Page 46 (EN)
