Sony UWP-D11 Quick Start Manual

UWP-D11
CHASSIS & DISPLAY OVERVIEW - TRANSMITTER
BODY-PACK TRANSMITTER (UTX-B03)
POWER/MUTING Button -
5
USB Connector -
You can power the unit using a USB cable (either portable power supply or connected to the mains.
6
Battery Compartment
7
+ or - Button -
Use these to operate the menu
8
Display Section
9
SET Button -
Use this to set values/functions in the menu
10
Infrared Detector -
Receives the frequency and compander mode set on the tuner
11
TRANSMITTER DISPLAY
Antenna
1
Power Indicator -
2
Indicator Display
ON (Green)
Flashing
Off
AUDIO Indicator
3
Indicator Display
ON (Red)
ON (Green)
Off
Flashing
Audio Input Connector -
4
Turns the power on/off. You can also use this button to turn the muting function on/off.
RF Transmission Indicator -
A
RF Transmission Power Indicator -
B
sion power setting.
Audio Input Level Meter -
C
Peak Indicator -
D
el at which distortion begins as a warning of excessive input level.
Input Level Indicator -
E
Battery Level Indicator -
F
Menu Display Section -
G
buttons to switch functions.
Displays the battery level
Status
Sufficient battery level
(Green) Battery is getting low
Power is off or battery is empty
Status
Audio input level is too high
Audio input level is appropriate
There is no audio input or the input level is too low
(Orange) Audio is muted (i.e. disabled)
Connect the supplied lavalier microphone
Displays the current transmission status
Displays the audio input level.
Lights up when the audio signal is 3dB below the lev-
Displays the input level status (MIC or LINE)
Displays the battery level.
Displays various functions. Press the + and -
Indicates the current transmis-
