- Page 1 Preface Introduction Installing the Subscriber Unit RUGGEDCOM WIN5137-V Device Management Technical Specifications Certification Installation Guide 11/2018 RC1265-EN-04...
- Page 2 Warranty Siemens warrants this product for a period of five (5) years from the date of purchase, conditional upon the return to factory for maintenance during the warranty term. This product contains no user-serviceable parts. Attempted service by unauthorized personnel shall render all warranties null and void.
-
Page 3: Table Of Contents
RUGGEDCOM WIN5137-V Installation Guide Table of Contents Table of Contents Preface ......................Alerts ..............................v Related Documents ..........................vi Training .............................. vi Customer Support ..........................vi Chapter 1 Introduction ..................... 1.1 Feature Highlights ........................2 1.2 Description ........................... 2 1.3 Required Tools and Materials ...................... - Page 4 RUGGEDCOM WIN5137-V Table of Contents Installation Guide 4.2 Power Consumption ........................19 4.3 Radio and Modem Specifications ....................19 4.4 Operating Environment ....................... 20 4.5 Mechanical Specifications ......................20 4.6 Dimension Drawings ........................21 Chapter 5 Certification ....................5.1 Approvals ........................... 23 5.1.1 CSA ..........................23 5.1.2 European Union (EU) .......................
-
Page 5: Preface
Preface Preface This guide describes the RUGGEDCOM WIN5137-V. It describes the major features of the subscriber unit, installation, commissioning and important technical specifications. It is intended for use by subscriber unit installers and operators, and assumes readers have a working knowledge of WiMAX technologies and procedures. -
Page 6: Related Documents
Siemens Sales representative. Customer Support Customer support is available 24 hours, 7 days a week for all Siemens customers. For technical support or general information, contact Siemens Customer Support through any of the following methods: Online Visit http://www.siemens.com/automation/support-request... -
Page 7: Introduction
Introduction Introduction The RUGGEDCOM WIN5137-V subscriber unit is part of the RUGGEDCOM WIN family, a line of mobile WiMAX broadband wireless access systems based on the IEEE 802.16e mobile WiMAX standard. The RUGGEDCOM WIN5137-V is a high-performance, self-learning subscriber. It automatically detects the base station on the best signal available, allowing for plug-and-play installation and maintenance free operation. -
Page 8: Feature Highlights
The subscriber unit supports both IP convergence sublayer for wireless Internet service providers or Ethernet Convergence Sublayer, ideal for mission critical private networks. Section 1.2 Description The RUGGEDCOM WIN5137-V features various ports, controls and indicator LEDs on the bottom panel for connecting, configuring and troubleshooting the subscriber unit. Feature Highlights... - Page 9 RUGGEDCOM WIN5137-V Chapter 1 Installation Guide Introduction RSSI W.LINK PWR Figure 1: RUGGEDCOM WIN5137-V 1. ETH Port 2. PWR Port 3. ANT 1 Port 4. ANT 2 Port 5. RSSI LEDs 6. W.LINK LED 7. PWR LED 8. Chassis Ground 12VDC Port A 4-pin, female, D-Coded M12 port for power. For more information about connecting data and power, refer to Section 2.7, “Connecting Power and...
-
Page 10: Required Tools And Materials
Section 2.6, “Grounding the Subscriber Unit”. Section 1.3 Required Tools and Materials The following tools and materials are required to install the RUGGEDCOM WIN5137-V: Tools Greases • Wrench or socket set • Marine grease (for marine applications only) • Phillips screwdriver Tapes •... -
Page 11: Installing The Subscriber Unit
WARNING! Safety hazard – risk of serious personal injury and/or damage to equipment. Installing the RUGGEDCOM WIN5137-V can pose a serious safety hazard. Be sure to take precautions to avoid the following: • Exposure to high voltage lines during installation •... -
Page 12: General Procedure
Chapter 2 RUGGEDCOM WIN5137-V Installing the Subscriber Unit Installation Guide IMPORTANT! This product should be installed in a restricted access location where access can only be gained by authorized personnel who have been informed of the restrictions and any precautions that must be taken. -
Page 13: Unpacking The Subscriber Unit
Configure the subscriber unit. For more information, refer to Section 3.1, “Configuring the Subscriber Unit”. Section 2.2 Unpacking the Subscriber Unit The following items are included in the RUGGEDCOM WIN5137-V package: Item Quantity RUGGEDCOM WIN5137-V Subscriber Unit Radio Frequency (RF) antenna cables, 5 m (16.4 ft) long... -
Page 14: Mounting The Subscriber Unit
Do not attempt to touch or remove the component. Section 2.4 Mounting the Subscriber Unit The RUGGEDCOM WIN5137-V is designed for maximum mounting and display flexibility. It can be secured to a bracket and then mounted to a pole, wall or tower. NOTE For detailed dimensions of the subscriber unit, refer to Section 4.6, “Dimension... -
Page 15: Mounting The Subscriber Unit To A Wall Or Tower
RUGGEDCOM WIN5137-V Chapter 2 Installation Guide Installing the Subscriber Unit When choosing the mounting location for the unit, consider the available mounting structures and antenna clearance. Site Survey Most wireless networks include many subscriber/base stations installed in various locations in an overlapping radio-cell pattern. -
Page 16: Mounting The Subscriber Unit To A Pole
Chapter 2 RUGGEDCOM WIN5137-V Installing the Subscriber Unit Installation Guide Figure 2: Mounting the Subscriber Unit to a Wall or Tower 1. Subscriber Unit 2. Mounting Kit 3. Wall Holder/Pole Mount 4. M8 × 25 mm Hex Screw 5. M8 Spring Washer 6. M8 Flat Washer 7. M8 Nut 8. M5 Flat Washer 9. NS 1/4" × 1/2" HEX Chipboard Screw 10. Wall Anchor Liberally apply an anti-corrosion spray to all galvanized steel components, including mounting brackets, washers and screws. - Page 17 RUGGEDCOM WIN5137-V Chapter 2 Installation Guide Installing the Subscriber Unit Attach the subscriber unit to the mounting bracket. Figure 3: Mounting the Subscriber Unit to a Large Pole 1. Subscriber Unit 2. Pole 3. Clamping Bracket 4. Mounting Bracket 5. M8-25 Hex Screw 6. M8 Spring Washer 7. M8 Flat Washer ...
-
Page 18: Installing The Antennas
14 N·m (10 lbf-ft). Section 2.5 Installing the Antennas The RUGGEDCOM WIN5137-V supports N-Connect female antennas. To install an antenna, do the following: WARNING! Radiation hazard – risk of Radio Frequency (RF) exposure. This subscriber unit is compliant with the requirements set forth in FCC CFR 47, section 1.1307, addressing Radio Frequency (RF) exposure from... -
Page 19: Grounding The Subscriber Unit
Switch-Mode Power Supplies (SMPS). Figure 5: Antenna and Lightning Protector Assembly 1. Drain Wire 2. RUGGEDCOM WIN5137-V 3. Shielded Coaxial Cable 4. Lightning Protector 5. Ground Wire 6. Antenna Make sure the PWR LED on the subscriber unit is on. -
Page 20: Connecting Power And Data
Section 2.7 Connecting Power and Data The RUGGEDCOM WIN5137-V requires a 9 to 36 VDC Class 2 power supply. IMPORTANT! When connecting a DC battery power supply, make sure to use a 36 VDC, 3 A, double-pole circuit breaker as the main disconnecting device. -
Page 21: Weatherproofing A Cable
RUGGEDCOM WIN5137-V Chapter 2 Installation Guide Installing the Subscriber Unit • Section 2.8.2, “Applying Cold Shrink Tubing” • Section 2.8.3, “Applying Self-Amalgamating Tape” Section 2.8.1 Weatherproofing a Cable To weatherproof a cable, do the following: IMPORTANT! PVC tape, silicon sealant and glue are not recommended for weatherproofing, as these materials are difficult to apply accurately and are difficult to remove. -
Page 22: Applying Self-Amalgamating Tape
Chapter 2 RUGGEDCOM WIN5137-V Installing the Subscriber Unit Installation Guide Section 2.8.3 Applying Self-Amalgamating Tape To apply self-amalgamating (or self-fusing) tape to a cable end, do the following: IMPORTANT! When applying self-amalgamating tape, make sure to stretch it to 2/3 of its original width to form a tight seal. -
Page 23: Device Management
RUGGEDCOM WIN5137-V Chapter 3 Installation Guide Device Management Device Management This section describes how to connect to and manage the subscriber unit. CONTENTS • Section 3.1, “Configuring the Subscriber Unit” Section 3.1 Configuring the Subscriber Unit Once the subscriber unit is installed and connected to the network, it must be configured. The RUGGEDCOM WIN5137-V features a Web-based User Interface (UI) for all configuration management. - Page 24 Chapter 3 RUGGEDCOM WIN5137-V Device Management Installation Guide Configuring the Subscriber Unit...
-
Page 25: Technical Specifications
Section 4.4, “Operating Environment” • Section 4.5, “Mechanical Specifications” • Section 4.6, “Dimension Drawings” Section 4.1 Power Supply Requirements The RUGGEDCOM WIN5137-V requires an external power supply that meets the following requirements: Power Supply Type Class 2 Input Range 10 to 36 VDC Section 4.2 Power Consumption... -
Page 26: Operating Environment
-20 to 100 dBm Dynamic Range (Transmitter) -20 to 27 dBm Section 4.4 Operating Environment The RUGGEDCOM WIN5137-V is rated to operate under the following environmental conditions. Ambient Operating -40 to 75 °C (-40 to 167 °F) Temperature Ambient Storage Temperature -40 to 75 °C (-40 to 167 °F) -
Page 27: Dimension Drawings
RUGGEDCOM WIN5137-V Chapter 4 Installation Guide Technical Specifications Section 4.6 Dimension Drawings NOTE All dimensions are in millimeters, unless otherwise stated. 44.2 37.0 92.2 106.8 Figure 6: Overall Dimensions Dimension Drawings... - Page 28 Chapter 4 RUGGEDCOM WIN5137-V Technical Specifications Installation Guide Dimension Drawings...
-
Page 29: Certification
RUGGEDCOM WIN5137-V Chapter 5 Installation Guide Certification Certification The RUGGEDCOM WIN5137-V ODU SU has been thoroughly tested to guarantee its conformance with recognized standards and has received approval from recognized regulatory agencies. CONTENTS • Section 5.1, “Approvals” • Section 5.2, “Environmental Type Tests”... -
Page 30: European Union (Eu)
Installation Guide Section 5.1.2 European Union (EU) This subscriber unit is declared by Siemens Canada Ltd to comply with essential requirements and other relevant provisions of the following EU directives: • IEC/EN 60950-1 Information Technology Equipment – Safety – Part 1: General Requirements •... -
Page 31: Ised
Installation Guide Certification Section 5.1.4 ISED This subscriber unit is declared by Siemens Canada Ltd to meet the requirements of the following ISED (Innovation Science and Economic Development Canada) standard: • RSS-197 Wireless Broadband Access Equipment Operating in the Band 3650–3700 MHz Section 5.1.5... -
Page 32: Environmental Type Tests
Administrative Measure on the Control of Pollution Caused by Electronic Information Products A copy of the Material Declaration is available online at https://support.industry.siemens.com/cs/ww/en/ view/109738831. Section 5.2 Environmental Type Tests The RUGGEDCOM WIN5137-V has passed the following environmental tests. Test Description Test Levels IEC 60068-2-1 Low Temperature -25 °C for 72 hours... - Page 33 RUGGEDCOM WIN5137-V Chapter 5 Installation Guide Certification Test Description Test Levels Accelerator: 180 m/s² 100 shocks in each direction IEC 60068-2-32 Free Fall Height: 1 m (3.3 ft) Nebs: GR63 One fall on 3 faces, 3 edges and 4 corners...
- Page 34 Chapter 5 RUGGEDCOM WIN5137-V Certification Installation Guide Environmental Type Tests...
