- Page 1 Solar Water Heater Models: QBJ1-130A QBJ1-150A QBJ1-175A QBJ1-200A Please read this manual before usage Retain it for future reference Instruction for use...
- Page 2 The international star service of Haier Group will always accompany you.No matter what kind of problems you meet in usage,please contact with the local after-sales service agent.We are at your service all the time.Thanks again for choosing Haier Product. The water heater you purchased may not full comply with the figure in the manual due to the improvement of product.We apologize for the inconvenience occurred...
-
Page 3: Table Of Contents
Content Technical data Features Appearance and parts Technical parameter Precautions Before use Notice Assembly Instruction The location Exterior and installation dimension Tank assembly Frame assembly Frame fastness Glass tube assembly Extraventricular plumbing instructions Indoor plumbing instructions Installation notice Using Instruction The operation method Troubles treatment Packing list... -
Page 4: Features
Technical data Features 1. Inner cylinder: SUS 304 stainless steel, food grade. 2. Insulation: Polyurethane foam, thickness-45 mm, good heat preservation effect. 3. Outer shell: Aluminium / zinc coated steel sheet. 4. Frame: Steady structure, shapely and durable . Appearance and parts Outer shell Evacuated tubes Base support... -
Page 5: Precautions
Precautions Precautions 1. Avoiding irradiation without water after installation, it can't be used immediately, it should be sheltered. 2. Supply water in the evening or in the next morning when the solar water heater is being used at the first time or has been shined for a long time without water in the manifold, doing so can avoid the breakage of tubes with thermal shock. -
Page 6: Before Use
Before use Notice Please take time to read this manual and familiarize yourself with the function of this production. 1. Please check out the packing list. 2. To avoid the scald, please mix the hot and the cold water before use it. 3. -
Page 7: Assembly Instruction
Assembly Instruction The location: 1. Please install the solar water heater in the area that avoid the thunder. 2. Solar water heater angle range: east to south for 10 , west to south for 15 . 3. There shouldn't be any hindrance in front of the heater ,or the distance should over L, L=H/tg(66.5 H:height of the hindrance;... -
Page 8: Tank Assembly
Assembly Instruction ank assembly 1. Unpacking the tank, rip off the protection film. Uninstall the nut and cushion. 2. Place tank onto tank bracket cradle, inserting protruding bolts into holes. fasten with nuts. Notice: 1. Rip off the protection film after the installation to avoid the destroy of the tank, and please don't use the sharp tool. -
Page 9: Glass Tube Assembly
Assembly Instruction Glass tube assembly 1. Keep tubes out of the irradiation while assembling the unit or a scald may be caused. 2. Place the rounded side of rubber seal downwards on the open end of tubes.(A) 3. Insert the tube into base support of locating hole with gentle pressure and twisting motion. -
Page 10: Extraventricular Plumbing Instructions
Assembly Instruction Extraventricular plumbing instructions Air supply pipe Air supply hole(1/2 ) forbidden to stem Remarks: The permitted error limit of above parameters is Indoor plumbing instructions Solar water heater Tap water Hot water Over flow pipe Over flow pipe Over flow hole ( conect to the room Inlet/outlet hole (1/2 ), conect... -
Page 11: Installation Notice
6. The installation project should be confirmed by our professional service personnel when install several sets of these series. Other water heaters Tap water Illustration of connect the solar tank with other tanks Contact to the water tank... -
Page 12: Using Instruction
Using Instruction The operation method 1.K1 K2 and K3 keep closed before use the water; 2. Open k1 to supply the water ,if the water's flowing out of the overflow pipe indicate that the tank is full of water, close K1 at this time. 3. -
Page 13: Troubles Treatment
Using Instruction Troubles treatment Possible reason Phenomenon The tank is empty No water supply The pipeline or the connection is impeded The controller The evacuated tubes have can't reach the damaged programmed The water supply is paused or low level or there is water pressure no water The pipeline or the connection is... - Page 16 Rev. 01 Specific Number 0040500680A...
