Summary of Contents for Bosch DWB097A50B/01
- Page 1 Extractor hood [en] Instructions for installation and use...
-
Page 2: Table Of Contents
Accessories for circulating-air mode..........8 INSTRUCTION MANUAL Produktinfo Additional information on products, accessories, replacement parts and services can be found at www.bosch-home.com and in the online shop www.bosch-eshop.com : Important safety information Read these instructions carefully. Only then Children must not play with, on, or around will you be able to operate your appliance the appliance. - Page 3 Risk of fire! Grease deposits in the grease filter may ■ catch fire. Clean the grease filter at least every 2 months. Never operate the appliance without the Room air-dependent heat-producing grease filter. appliances (e.g. gas, oil, wood or coal- operated heaters, continuous flow heaters Grease deposits in the grease filter may Risk of fire!
-
Page 4: Environmental Protection
Risk of electric shock! Causes of damage A defective appliance may cause electric Caution! ■ shock. Never switch on a defective Risk of damage due to corrosion. Always switch on the appliance. Unplug the appliance from the appliance while cooking to avoid condensation. Condensate can produce corrosion damage. -
Page 5: Operation
Operation Setting the fan These instructions apply to several appliance variants. It is possible that individual features are described which do not Switching on apply to your appliance. Press button 1, 2 or 3. Note: Switch on the extractor hood when you start cooking and Switching off switch it off again several minutes after you have finished cooking. - Page 6 Removing metal grease filter Area Cleaning agents Open the lock and fold down the metal grease filter. While Stainless steel Hot soapy water: doing this, place the other hand under the metal grease filter. Clean with a dish cloth and dry with a soft cloth.
-
Page 7: Trouble Shooting
Trouble shooting Replacing bulbs Malfunctions often have simple explanations. Please read the following notes before calling the after-sales service. Risk of electric shock! Risk of electric shock! When changing the bulbs, the bulb socket contacts are live. Incorrect repairs are dangerous. Repairs may only be carried Before changing the bulb, unplug the appliance from the mains out and damaged power cables replaced by one of our trained or switch off the circuit breaker in the fuse box. -
Page 8: After-Sales Service
After-sales service Our after-sales service is there for you if your appliance needs Basic equipment: Starter set for circulating-air mode - wide to be repaired. We will always find the right solution in order to avoid unnecessary visits from a service technician. When calling us, please give the product number (E no.) and the production number (FD no.) so that we can provide you with the correct advice. -
Page 9: Installation Instructions
INSTALLATION INSTRUCTIONS Installation instructions This appliance is installed on the wall. ■ Follow the enclosed installation instructions for additional ■ special accessories (e.g. for circulating-air mode). The surfaces of the appliance are sensitive. Avoid damaging ■ them during installation. : Important safety information Read these instructions carefully. - Page 10 Danger of death! Risk of poisoning from flue gases that are drawn back in. If installing a ventilation system in a room with a heat-producing appliance connected to a chimney/flue, the electricity supply to the hood must be Room air-dependent heat-producing equipped with a suitable safety switch.
-
Page 11: General Information
General information Exhaust air mode Checking the wall The wall must be level, vertical and adequately load-bearing. ■ Risk of death! The depth of the bore holes must be the same length as the Risk of poisoning from flue gases that are drawn back in. The ■... -
Page 12: Installation
Installation Attaching and aligning the appliance Screw on the fixing bracket for the flue duct. Initially remove the protective foil from the back of the ¨ appliance and, following installation, remove the foil completely. When attaching the appliance, ensure that it engages firmly with the brackets. -
Page 13: Attaching The Flue Duct
Attaching the flue duct Removing the safety caps If the safety caps must be removed, use a flat screwdriver. Risk of injury! From sharp edges during installation. Always wear protective gloves while installing the appliance. Separate the flue ducts. To do this, remove the adhesive tape. Remove the protective foil from both flue ducts. - Page 16 Robert Bosch Hausgeräte GmbH Carl-Wery-Straße 34 81739 München Germany www.bosch-home.com *9000852624* 940611 9000852624...
