Panasonic ES-WU11 Service Manual
Hide thumbs
Also See for ES-WU11:
- Operating instructions manual (75 pages) ,
- Operating instructions manual (29 pages)
Advertisement
Quick Links
Please file and use this manual together with the service manual for Model No. ES2013-E2, Order No.
PCD0606E33AE.
TABLE OF CONTENTS
1 Warning -------------------------------------------------------------- 2
2 Specifications ----------------------------------------------------- 2
3 Exploded View and Replacement Parts List ------------ 3
Model No.
Europe
CIS
PAGE
© Panasonic Corporation, 2012. All rights reserved.
Unauthorized copying and distribution is a violation
of law.
Order Number PCD1201X31AE
ES-WU11
ES-WU31
ES-WU41
Epilator
PAGE
Advertisement
Related Manuals for Panasonic ES-WU11
Summary of Contents for Panasonic ES-WU11
- Page 1 Please file and use this manual together with the service manual for Model No. ES2013-E2, Order No. PCD0606E33AE. TABLE OF CONTENTS PAGE PAGE 1 Warning -------------------------------------------------------------- 2 2 Specifications ----------------------------------------------------- 2 3 Exploded View and Replacement Parts List ------------ 3 © Panasonic Corporation, 2012. All rights reserved. Unauthorized copying and distribution is a violation of law.
- Page 2 1 Warning Caution: • Pb free solder has a higher melting point that standard solder; Typicall the melting point is 50 - 70°F (30 - 40°C) higher. Please use a soldering iron with temperature control and adjust it to 750 ± 20°F (400 ± 10°C). In case of using high temperature solder- ing iron, please be careful not to heat too long.
- Page 3 3 Exploded View and Replacement Parts List Model No. : ES-WU41 EXPLODED VIEW...
- Page 4 Model No. : ES-WU41 Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks ES-WU41 WESWU41P7158 PROTECTIVE CAP WESWS10W3008 EPILATION FRAME FOR LEGS/ARMS WESWS20W1068 EPILATION HEAD FOR LEGS/ARMS WESWU31W3128 EPILATION FRAME FOR UNDERARMS WESWU31W1078 EPILATION HEAD FOR UNDERARMS WES331B9257 TAPPING SCREW 3 K2-8...
- Page 5 Model No. : ES-WU31 EXPLODED VIEW...
- Page 6 Model No. : ES-WU31 Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks ES-WU31 WESWU31D7158 PROTECTION CAP WESWS10W3008 EPILATION FRAME FOR LEGS/ARMS WESWS20W1068 EPILATION HEAD FOR LEGS/ARMS WESWU31W3128 EPILATION FRAME FOR UNDERARMS WESWU31W1078 EPILATION HEAD FOR UNDERARMS WES331B9257 TAPPING SCREW 3 K2-8...
- Page 7 Model No. : ES-WU11 EXPLODED VIEW...
- Page 8 Model No. : ES-WU11 Parts List Ref. Safety Part No. Part Name & Description Q'ty Remarks ES-WU11 WESWU11G7158 PROTECTION CAP 1 for GREEN MODEL WESWU11P7158 PROTECTION CAP 1 for PINK MODEL WESWS10W3008 EPILATION FRAME FOR LEGS/ARMS WESWS20W1068 EPILATION HEAD FOR LEGS/ARMS...
