For the customers in the USA This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
Installing the Driver Software Overview The ESBK-7051 SCSI Option is an expansion board that installs in an ISA slot of the ES-7 EditStation™ to enable connection of MO drives and other external SCSI devices to the ES-7. You can use MO drives to exchange ES-7 data with other equipment.
Installing the Expansion Board For installation, refer to “Installing Expansion Boards in ISA Slots” in Chapter 3 “Connections and Settings” in the Operating Instructions supplied with the ES-7 EditStation. Note Be sure to power the ES-7 off before installing this board. Installing the Driver Software To use the expansion board, you will need to start the system and install the driver software.
Page 14
Installing the Driver Software Click the Start button on the taskbar, point to Settings, then click Control Panel. The Control Panel window appears.
Page 15
Double click the SCSI Adapters icon in the Control Panel window. The SCSI Adapters dialog box appears. Click the Drivers tab. (Continued)
Page 16
Installing the Driver Software Click the Add button. After a few moments, the following dialog box appears. Select Adaptec from the Manufacturers drop-down list. The following dialog box appears..................................1) Adaptec is a registered trademark of Adaptec, Inc.
Page 17
Select “Adaptec AHA-152X/AHA-1510 SCSI HOST Adapter” from the SCSI Adapters drop-down list, and clik the OK button. Installation starts. After a few moments, the following dialog box appears. Remove the Windows NT Workstation Version 4.0 CD- ROM, and click the Yes button.
Specifications Installing the Driver Software General Dimensions (w/h/d) 176 × 121 × 22 mm (7 × 4 × inches) Mass 80 g (2 oz) Input and output connectors SCSI connector 50-pin high-density SCSI-2 Accessories supplied Operating Instructions (1) Design and specifications are subject to change without notice.
Page 19
Table des matières Aperçu ................20 Emplacement et fonction des organes ......20 Installation de la carte d’extension ......21 Installation du logiciel de pilotage ....... 21 Spécifications ..............26...
Aperçu La carte SCSI Option ESBK-7051 est une carte d’extension qui s’installe dans un logement ISA de l’ EditStation ES-7 pour permettre le raccordement d’unités MO et d’autres périphériques SCSI à l’ES-7. Les unités MO peuvent être employées pour échanger des données ES-7 avec d’autres appareils.
Installation de la carte d’extension Voir “Installation de cartes d’extension dans les logements ISA” dans le Chapitre 3 “Raccordements et réglages” du mode d’emploi fourni avec l’EditStation ES-7 pour l’installation. Remarque Ne pas oublier de mettre l’ES-7 hors tension avant d’installer cette carte.
Page 22
Installation du logiciel de pilotage Cliquer sur le bouton Start sur la Taskbar, pointer Settings, puis cliquer sur Control Panel. La fenêtre Control Panel apparaît.
Page 23
Cliquer deux fois sur l’icône SCSI Adapters dans la fenêtre Control Panel. La boîte de dialogue SCSI Adapters apparaît. Cliquer sur l’onglet Drivers. (à suivre)
Page 24
Installation du logiciel de pilotage Cliquer sur le bouton Add. Au bout d’un instant, la boîte de dialogue suivante apparaît. Sélectionner Adaptec dans la liste déroulante Manufacturers. La boîte de dialogue suivante apparaît..................................1) Adaptec est une marque de fabrique déposée d’Adaptec, Inc.
Page 25
Sélectionner “Adaptec AHA-152X/AHA-1510 SCSI HOST Adapter” dans la liste déroulante SCSI Adapters, puis cliquer sur le bouton OK. L’installation commence. Au bout d’un instant, la boîte de dialogue suivante apparaît. Retirer le CD-ROM Windows NT Workstation Version 4.0, et cliquer sur le bouton Yes.
Spécifications Généralités Dimensions (l/h/p) 176 × 121 × 22 mm (7 × 4 × pouces) Poids 80 g (2 onces) Connecteurs d’entrée/sortie Connecteur SCSI SCSI-2 haute densité 50 broches Accessoires fournis Mode d’emploi (1) La conception et les spécifications sont sujettes à modification sans préavis.
Page 27
Für Kunden in Deutschland Dieses Produkt kann im kommerziellen und in begrenztem Maße auch im industriellen Bereich eingesetzt werden. Dies ist eine Einrichtung, welche die Funk-Entstörung nach Klasse B besitzt. Inhaltsverzeichnis Kurzbeschreibung ............28 Lage und Funktion der Teile ........28 Installieren der Erweiterungskarte ......
Kurzbeschreibung Die SCSI Option ESBK-7051 ist eine Erweiterungskarte für die Installierung in einen ISA-Steckschlitz in der EditStation™ ES-7 für den Anschluß von MO-Laufwerken und anderen SCSI-Ausrüstungen an die ES-7 für bequemen Datenaustausch mit anderen Geräten über MO-Disks. Lage und Funktion der Teile...
Installieren der Erweiterungskarte Zur Installierung lesen Sie bitte „Installieren in ISA- Steckschlitze“ in Kapitel 3 „Anschlüsse und Einstellungen“ in der Bedienungsanleitung der EditStation ES-7. Hinweis Denken Sie daran, die ES-7 vor dem Einbauen der Karte auszuschalten. Installieren der Treiber-Software Für das Arbeiten mit der Erweiterungskarte ist die Installierung der mitgelieferten Treiber-Software erforderlich.
Page 30
Installieren der Treiber-Software Klicken Sie in der Taskleiste auf Start, gehen Sie mit dem Cursor auf Einstellungen (Settings), und klicken Sie auf Systemsteuerung (Control Panel). Das Systemsteuerung-Fenster (Control Panel) wird geöffnet.
Page 31
Doppelklicken Sie im Systemsteuerung-Fenster (Control Panel) auf das SCSI Adapters-Symbol. Die SCSI Adapters-Dialogbox erscheint. Klicken Sie auf die Treiber-Taste (Drivers). (bitte wenden)
Page 32
Installieren der Treiber-Software Klicken Sie auf die Taste „Add“ (Hinzufügen). Kurz darauf erscheint die folgende Dialogbox. Wählen Sie Adaptec aus der Drop-down-Liste der Hersteller. Die folgende Dialogbox erscheint..................................1) Adaptec ist ein eingetragenes Warenzeichen von Adaptec, Inc.
Page 33
Wählen Sie „Adaptec AHA-152X/AHA-1510 SCSI HOST Adapter“ aus der Drop-down-Liste SCSI Adapters, und klicken Sie auf OK. Der Installationsvorgang beginnt. Kurz darauf erscheint die folgende Dialogbox. Entnehmen Sie die Windows NT Workstation Version 4.0 CD-ROM-Disc, und klicken Sie auf Yes (Ja).
