ABB Thomas & Betts 300W Instruction Manual

THIS UNIT CONTAINS A
RECHARGEABLE VALVE-REGULATED
LEAD ACID BATTERY. PLEASE
RECYCLE OR DISPOSE OF
PROPERLY.
When using electrical equipment, basic safety precautions should always be followed, including the following:
READ THIS MANUAL AND FOLLOW ALL SAFETY INSTRUCTIONS
THOROUGHLY BEFORE OPERATING THE INVERTER SYSTEM
BEFORE CONTACTING TECHNICAL SUPPORT PLEASE REFER TO THE TROUBLESHOOTING GUIDE INCLUDED IN
THIS MANUAL.
1. DO NOT USE OUTDOORS.
2. All unused wires must be insulated to prevent shorting.
3. Do not mount near gas or electric heaters.
4. Do not let power supply cords touch hot surfaces.
5. Do not use this equipment for other than its intended use.
6. The Mini Inverter should be mounted securely and in locations and at heights where it will not be readily subjected to tampering by
unauthorized personnel.
7. The use of accessory equipment and replacement parts not recommended by manufacturer may cause an unsafe condition and
void the warranty.
8. The AC voltage rating of this equipment is specified on the product label. Do not connect the Mini Inverter equipment to any other
voltage.
9. Replacement fuse is supplied.
10. The Mini Inverter uses sealed valve regulated lead acid batteries. Batteries can be punctured if not handled properly, therefore use
caution when servicing batteries. In the event battery acid comes in contact with eyes or skin, flush with fresh water and consult a
physician immediately.
11. Install in accordance with the National Electrical Code and local regulations.
12. The Mini Inverter contains potentially hazardous voltages. Installation, maintenance and service work should be performed by
qualified and trained personnel.
13. Electricians and end-users need to ensure product system compatibility before final installation.
14. Units to be installed only as per configuration described in this instruction manual.
MODEL
NUMBER
300 120 Vac, 60Hz
120 Vac, 60Hz
600
347 Vac, 60Hz
IMPORTANT: Do not exceed the total rating of the Mini Inverter. Unit is rated at maximum Watt and maximum VA, where Max.W
= Max.VA. Total load (W) must be derated when load power factor (PF) is less than 0.9 (for maximum performance)
All Thomas & Betts inverter products receive 100% quality inspection before shipment to ensure proper and satisfactory operation.
When operated under normal conditions, Thomas & Betts inverter products will provide years of dependable service. This unit is backed
by a 1-9 year warranty. The unit is covered by a complete 1-year warranty against defects in material or workmanship, and a 9-year pro-
rata battery warranty.
Tel: (888) 552-6467
IMPORTANT SAFEGUARDS
SAVE THESE INSTRUCTIONS
AC SPECS
3.10 Amps
6.00 Amps
2.30 Amps
Fax: (800) 316-4515
300/600W Mini Inverter
INTERRUPTIBLE EMERGENCY LIGHTING
UNIT INVERTER INSTRUCTION MANUAL
EMERGENCY POWER AVAILABLE FOR LOAD
30 MIN 1H 1H 30MIN
300W 240W 175W
600W 410W 300W
600W 410W 300W
WARRANTY
www.tnb.com
300/600W Mini Inverter
APPROX.
2H 4H WEIGHT
140W 80W 70LBS.
240W 125W 120LBS.
240W 125W 120LBS.
.
06/18 750.1781_Rev. H
