[eHELP] (Built-in Operating Instructions). How to use [eHELP] (p. 16) Thank you for purchasing this Panasonic product. Please read these instructions carefully before operating this product and retain them for future reference. Please carefully read the “Safety Precautions” of this manual before use.
For information about the trademarks, refer to [eHELP] (Support > Licence). The illustration for TX-40DS503E is used in this manual unless otherwise mentioned. Illustrations shown may be different depending on the model. Contents Be Sure to Read Important Notice··················································· 3 Safety Precautions ···············································...
Additional fees may be charged depending on the service provider. Compatibility with future services is not guaranteed. Panasonic does not guarantee operation and performance of peripheral devices made by other manufacturers; and we disclaim any liability or damage arising from operation and/or performance from usage of such other maker’s peripheral devices.
If you detect anything unusual, Do not use an unapproved pedestal / mounting immediately remove the mains equipment. Be sure to ask your local Panasonic plug. dealer to perform the setup or installation of approved wall-hanging brackets. Do not apply any strong force or impact to the display...
Page 5
TV. Do not use the pedestal if it becomes warped or physically damaged. If this occurs, contact your nearest Panasonic dealer immediately. (cm) During setup, make sure that all screws are securely tightened.
49-inch model 55-inch model Declaration of Conformity (DoC) “Hereby, Panasonic Corporation declares that this TV is in compliance with the essential requirements and other relevant provisions of the Directive 1999/5/EC.” If you want to get a copy of the original DoC of this TV,...
Page 7
Assembling / Removing the pedestal 40-inch model 49-inch model 55-inch model 32-inch model Assembly screw (4) Assembly screw (3) M5 × 10 M3 × 14 Assembly screw (4) Assembly screw (4) M4 × 12 M4 × 15 Bracket (2) Bracket Base Base Assembling the pedestal...
Connections External equipment and cables shown are not supplied with this TV. Please ensure that the unit is disconnected from the mains socket before attaching or disconnecting any cables. Check the terminal type and cable plugs are correct for connection. Use a fully wired HDMI compliant cable.
Page 9
6 Satellite terminal (p. 9) Satellite dish 7 Terrestrial / cable terminal (p. 9) DVB-S 8 AV2 (COMPONENT / VIDEO) (p. 10, 11) 9 ETHERNET terminal (p. 10) 10 AV1 (SCART) (p. 10) Basic connections Mains lead Satellite cable Satellite dish To ensure your satellite dish is correctly installed, AC 220-240 V please consult your local dealer.
Page 10
For information about the connections, read the Network manual of the DVB-via-IP server. A broadband network environment is required to be able For details, refer to [eHELP] (Functions > DVB-via- to use internet services. IP). If you do not have any broadband network services, please consult your retailer for assistance.
Page 11
Common Interface Camcorder / Game equipment Turn the TV off with Mains Power On / Off switch (VIDEO equipment) whenever inserting or removing the CI module. If a smart card and a CI module come as a set, first insert the CI module, then insert the smart card into the CI module.
When pushed with a finger, the display panel moves FAQs slightly and makes a noise There is a little gap around the panel to prevent damage to the panel. This is not a malfunction. Before requesting service or assistance, please follow these simple guides to solve the problem.
Maintenance Specifications First, remove the mains plug from the mains socket. Model No. : TX-32DS503E 32-inch model Display panel, Cabinet, Pedestal : TX-40DS503E 40-inch model Regular care: : TX-49DS503E 49-inch model Gently wipe the surface of the display panel, cabinet,...
Page 19
PAL B, G, H, I Connection terminals SECAM B, G AV1 input / output SECAM L, L’ SCART (Audio/Video in, Audio/Video out, RGB in) VHF E2 - E12 VHF A - H (ITALY) AV2 input (COMPONENT / VIDEO) CATV (S01 - S05) VIDEO CATV S11 - S20 (U1 - U10) RCA PIN Type ×...
Page 20
Handle the TV carefully during installation since When using the wall-hanging bracket subjecting it to impact or other forces may cause Please contact your local Panasonic dealer to purchase product damage. the recommended wall-hanging bracket. Take care when fixing wall brackets to the wall.
